Nova 4081BW5 Instruction Manual

ASSEMBLE YOUR
Folding Walker with
Bag
Item # 4081BW5
Capacity not to exceed 300 lb
a.
Rear
Front
1
Swing out both sides of the walker as shown
in (Figure 1) until they click into place. Walker
assembly should feel sturdy.
NOTE: To close walker, depress the black
rubber tips of the folding mechanism before
swinging side back into closed position.
Levels
3
Figure 4
Adjust the height to appropriate level by
positioning the push buttons at numbered
holes (Figure 4). All legs must be at the
same level. Adjust the walker so that when
the arm is extended the walker handle is at
wrist height. Elbow should be flexed at 20 to
30 degress
HOW TO
a. (1) Walker Assembly
b. (2) Front leg assemblies
c. (2) Rear leg assemblies
b.
Folding
Mechanisms
Figure 1
WHAT'S IN THE BOX
d. (1) Storage Bag
e. (1) Black Mobility Bag
c.
Figure 2
2
Depress brass push button and insert front
leg assemby into front receiver (Figure 2).
Ensure the button clicks into place and is
securely engaged (Figure 3). Insert rear leg
assembly into rear receiver. Repeat step 2 for
other side of walker.
4
Ensure wheels face outside the walker and
the glide skis on rear leg assemblies face
toward front of walker. Mobility bag may
be attached to front of walker using velcro
straps.
To store walker (Figure 5): Detach leg
assemblies and adjust to shortest length.
Place legs into storage bag. Collapse walker
assembly before storing.
NO tools required
Quick assembly
Easy to follow
step-by-step
instructions
d.
Figure 3
e.
Figure 5
