COMPONENT IDENTIFICATION

■ FRONT VIEW
MECHATROLINK Setting Rotary SW
Station Address Setting
Rotary SW
Status Indicator LED
MECHATROLINK
Connector
■ LEFT SIDE VIEW
SEN TRONIC
1 2 3
X10 X1
PWR ERR RD
RUN SD
STATION ADD. B. RATE
4 5 6 7
1 2 3
Power Supply Terminals
MECHATROLINK Connector
056 222 38 18 mailbox@sentronic.com
AG
Operating Mode Setting DIP SW (SW1)
PC Configurator Jack
4 5 6 7 8
CNFG.
6 7 8 9 10
1 2 3 4 5
Output Terminals
www.sentronic.com
R7ML-YV2
