- Page 1 SD2 Aluminium Wheelchair (SD2SP16BLK, SD2SP18BLK, SD2SP20BLK, SD2SP22BLK, SD2TS16BLK, SD2TS18BLK, SD2TS20BLK, SD2TS22BLK) Instructions for use...
- Page 2 Introduction Intended purpose To provide manually propelled mobility to an individual who has a walking related disability and/or who does not have the full capacity to walk. Intended user group The wheelchair is intended for an individual who has a walking related disability and/or who does not have the full capacity to walk and has a weight of up to 135kg (21 stone).
-
Page 3: Parts Description
Parts description BRAKE QUICK 1/2 FOLD PUSH PUSH LEVER HANDLE REST RELEASE BACK HANDLE SIDE MECHANISM PANEL ARM REST SIDE PANEL 12.5" LAP BELT WHEEL 24" WHEEL & HANDRIM FOOTREST FOOT FRONT REST CASTOR FRONT STEPPER CASTOR TUBE Self Propel models Transit models 16”... - Page 4 (see disassembly and storage), remove screws and nyloc nuts, reposition, then reattach the fasteners and adjust the brakes (as detailed below). Drive DeVilbiss Healthcare Ltd recommends approved service personnel do this. Upholstery This wheelchair features a cushioned seat and back, and a tension- adjustable back canvas.
- Page 5 Armpad Position The armrests and side panels can be moved away from the seat to increase space or aid transferring occupants (as shown in Adjusting the armrest image). To swing the side panels away, push the small paddle levers (A) at the front. Adjusting The armrests can also be repositioned the armrest...
-
Page 6: Footrest Adjustment
Footrest adjustment To fit the footrests, align approximately 45º outwards, push down firmly into the frame (1) then rotate inwards (2) until they lock into place. Pull the handle / lever and rotate to release. For optimum comfort it is important to attain the correct leg position. -
Page 7: General Warnings
General warnings Before using the wheelchair, read the safety notices below; • Do not exceed the 10º maximum gradient. Use slow speeds and do not reverse down a gradient. • Do not use on escalators. • The wheelchair is only suitable for single occupancy. •... -
Page 8: Calf Straps
Transfer and use Transfer: When transferring in and out of the seat, move the seats as close as possible to each other. Attendants should engage parking brakes and fold away footrests. If users need to be lifted out of a seat, attendants are responsible for being suitably trained and competent to lift occupants with minimal risk of harm. - Page 9 Steep terrain, kerbs and steps Steep terrain: These wheelchairs are not designed for use on gradients beyond 10°. When on a slope, avoid swerving or sudden changes in movement. Over kerbs: Attendants push down on the stepper tube with a foot to raise the front castors (when mounting a kerb for example).
-
Page 10: Brake Operation
Brake operation Parking Brakes To apply the parking brakes, push the handle on the brake unit (in the parking brakes image) until locked in place. To release the brake, pull the handle in the opposite direction. The brakes should always be Parking applied when the wheelchair is stationary. -
Page 11: Backrest Adjustment
Backrest adjustment The height and angle of the backrest can be adjusted if necessary from the posts towards the back of the seat. To access the bolts, the armrests should Removing armrests in disassembly and be tipped back or removed (see storage). -
Page 12: Disassembly And Storage
Disassembly and storage This wheelchair has a number of quick release components and the wheelchair frame is easily foldable. This facilitates a light carry weight and minimises storage space required. To disassemble for storage, transport or maintenance, follow the steps below. To reassemble components, reverse these instructions. -
Page 13: Care And Maintenance
Do not use a damaged or badly worn wheelchair. Users should routinely check for any malfunctions or changes in performance. See Accessories and Spare Parts section for approved parts available from Drive DeVilbiss Healthcare Ltd. • Before each use of the wheelchair, the brakes should be checked and tyres inflated to no more than their rated pressure;... -
Page 14: Specification
Specification Model SD2SP16BLK SD2SP18BLK SD2SP20BLK SD2SP22BLK Maximum occupant mass 135 kg 135 kg 135 kg 135 kg Overall length with footrest 105 cm 105 cm 105 cm 105 cm Overall width 61 cm 66 cm 71 cm 76 cm Folded length 80 cm 80 cm 80 cm... -
Page 15: Warranty
If you have any queries or require full warranty conditions, please contact your provider. Accessories and spare parts Drive DeVilbiss Healthcare Ltd provide a range of accessories for the wheelchairs in the SD2 range. Spare parts are also available for maintaining your wheelchair. - Page 16 Sidhil Business Park, Holmfield, Halifax 4 Trench Road, Mallusk, Newtownabbey BT36 4TY, Northern Ireland West Yorkshire, HX2 9TN, GB Drive DeVilbiss Healthcare Ltd provide these instructions for use and product markings. info@drivedevilbiss.co.uk | www.drivedevilbiss.co.uk Service & Maintenance Spares Customer Service...
