- Page 1 Owner’s Manual Ceiling Fan Installation Instructions For 5OBR52XXD Series Fans READ AND SAVE THESE INSTRUCTIONS Total fan weight with light...
- Page 2 Installation AFETY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70- 1999), including fire-rated construction.
- Page 3 Align hole in downrod with hole in Install keeper into cross pin. Install downrod into yoke. yoke and install cross pin. Remote Transmitter Dip swtiches Remote Receiver Dip switches Set dip switches on the Remote T ransmitter and Remote Receiver to the same settings. This must be Raise fan with downrod assembled to the done so the units will communcate properly .
- Page 4 Take the plate with glass and place over the 2 screws and twist to hold Place floating brackets onto blades Tighten all 3 screws securely. in place. Replace screw removed. aligning holes in the blade with the floating bracket. Check the motor for plastic shipping stabilizer tabs and remove if present.
- Page 5 Place the light kit over the screws Attach glass by locating dimples in and twist light kit with the key slots Install the 100 watt halogen bulb. Do the light kit with the grooves in the into place. Replace screw removed not touch the bulb surface, as oily glass and by twisting clockwise till and then tighten all 3 screws secure-...
- Page 6 Remote Control Transmitter Features: FAN REVERSE LED LIGHT (Press once to change direction of MEDIUM SPEED the fan)Fanmust be running to reverse. LOW SPEED HIGH SPEED FAN OFF SETTING UPLIGHT ON/OFF SET- (Turns fan off only) TING AND DIMMER (Press and hold to dim light infinitively) DOWNLIGHT ON/OFF SETTING AND DIMMER...
- Page 7 Trouble Shooting If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet.
