Summary of Contents for Cub Cadet CC-4048PS-ATV
- Page 1 CC-4048PS-ATV 15 cu ft POLY SWIVEL DUMP CART U.S. Patent No. 8,496,298 & 9,242,588 READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT 6004372 - REV A 08/19...
-
Page 2: Safety Rules
Safety Rules This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Read and understand all safety rules and operating instructions before using this tractor/ATV/UTV attachment. -
Page 3: Warranty
Warranty IF YOU ARE MISSING PARTS DO NOT RETURN TO STORE Email cs@ohiosteel.com or call 1-800-652-2321, ext. 212 Before you call, please email our customer service team at cs@ohiosteel.com with the following: A description of the issue you are having Photos of the issue that include an overall view and detailed view from multiple angles If applicable, a short video showing the issue... -
Page 4: Carton Contents
Carton Contents 2 (x1) 3 (x1) 1 (x1) 4 (x2) 5 (x2) (x1) 23 (x2) (x1) 25 (x4) 26 (x8) 27 (x12) 24 (x2) 31 (x2) 30 (x2) 28 (x12) 32 (x2) 33 (x1) 29 (x4) 34 (x2) 35 (x1) 36 (x2) TOOLS REQUIRED FOR ASSEMBLY: •... - Page 5 Assembly Instructions Hold Poly Body (1) on side as shown. Insert Hex Bolts (25 &26) as shown. Flip Poly Body (1) to expose bolts. Tape Tape Tape TIP: Bolt heads can be secured with tape to aid in assembly. Install Undercarriage (2) over top of Hex Bolts. Install Lockwasher (27) and tighten Hex Nuts (28) onto Hex Bolts.
- Page 6 Assembly Instructions Attach Front Support (3) to Poly Body (1). Install Lockwasher (27) and tighten Hex Nuts (28) onto Hex Bolts. Insert Stub Axles (4) into Undercarriage (2) and secure with Clevis Pins (31) and Hairpin Cotters (32) Slide Washers (29), Spacers (38), and Wheels (5) onto Stub Axles (4). Install Cotter Pins(30).
- Page 7 Assembly Instructions Align holes in Swivel Clevis and Undercarriage and install Clevis Pin (33) as shown. Secure Pin with Hairpin (34). Depress Foot Pedal (11), insert Front Support (3) into Drawbar Assembly. When Drawbar is locked in place, flip cart upright onto wheels. Insert preassembled hybrid hitch assembly into Drawbar.
- Page 8 Operating Instructions Before Using Dump Cart: Apply lithium grease to wheels using grease gun until grease can be seen squeezing out from both sides of the wheel. Check tire pressure and inflate to 24 psi if needed. Read all Safety Rules found on page 1. How to Use Dump Cart: Attach Dump Cart to your tractor, ATV, or UTV as shown below.
- Page 9 Do-It-Yourself Accessories 35.13 31.63 USE 1/2" PLYWOOD 35.25 USE STANDARD 2 X 4 34.00 13.00 45.00 13.00 13.00 USE NOMINAL GRADE C 1 X 3...
-
Page 10: Repair Parts
Repair Parts ITEM PART NO DESCRIPTION QTY ITEM PART NO DESCRIPTION 311161 POLY BODY 21 6000534-B2 HYBRID HITCH 6000320-B2 UNDERCARRIAGE 22 6000379-B2 HITCH BUSHING 6000311-B2 FRONT SUPPORT ASSEMBLY 3/8"-16 X 3" HEX BOLT 6000523 STUB AXLE NYLOCK NUT, 3/8"-16 6000727-C WHEEL (BEARING/BUSHINGS INC.) 5/16"-18 X 1-1/2"... - Page 11 Designed And Tested In Columbus, Ohio Manufactured In The U.S.A. From Domestic And Imported Components MODEL # CC-4048PS-ATV (800) 652-2321 (800) 652-2321...
