Hold Poly Body (1) on side as shown. Insert Hex Bolts (25 &26) as shown.
2
Flip Poly Body (1) to expose bolts.
Tape
Tape
TIP: Bolt heads can be secured with tape to aid in assembly.
3
Install Undercarriage (2) over top of Hex Bolts. Install Lockwasher (27) and
tighten Hex Nuts (28) onto Hex Bolts.
28
27
Assembly Instructions
26
Tape
25
1
26
28
27
2
