CCXGZOS3048SS
12 cu ft STEEL SWIVEL DUMP CART
Copyright 2024. All Rights Reserved.
In a continued commitment to improve quality, the manufacturer
reserves the right to make component changes or design changes
when necessary and without notice. The product in this box may
di er slightly from that pictured. Does not a ect function.
Copyright 2024. Tous droits réservés.
Dans un souci constant d'amélioration de la qualité, le fabricant se
réserve le droit d'apporter des modi cations aux composants ou à
la conception, si nécessaire et sans préavis. Le produit contenu
dans cette boîte peut di érer légèrement de celui illustré. Cela
n'a ecte pas le fonctionnement.
READ AND FOLLOW ALL SAFETY RULES AND OPERATING
U.S. Patent No. 8,496,298 9,056,573 9,242,588
INSTRUCTIONS BEFORE USING THIS EQUIPMENT
Manufactured under license by Ohio Steel
Industries, 2575 Ferris Road, Columbus, OH 43224.
For product service, or warranty information contact
us at: 1-800-652-2321
Fabriqué sous licence par Ohio Steel Industries,
2575 Ferris Road, Columbus, OH 43224.
Pour le service après-vente ou les informations sur la
garantie, contactez-nous au : 1-800-652-2321
U.S. Patent No. 6,675,905
6005753 - REV B - 04/24
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Cub Cadet CCXGZOS3048SS
Summary of Contents for Cub Cadet CCXGZOS3048SS
- Page 1 CCXGZOS3048SS 12 cu ft STEEL SWIVEL DUMP CART U.S. Patent No. 8,496,298 9,056,573 9,242,588 Copyright 2024. All Rights Reserved. Manufactured under license by Ohio Steel In a continued commitment to improve quality, the manufacturer Industries, 2575 Ferris Road, Columbus, OH 43224.
- Page 2 Safety Rules This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Read and understand all safety rules and operating instructions before using this tractor attachment.
- Page 3 Warranty IF YOU ARE MISSING PARTS DO NOT RETURN TO STORE Email cs@ohiosteel.com or call 1-800-652-2321, ext. 212 Before you call, please email our customer service team at cs@ohiosteel.com with the following: A description of the issue you are having Photos of the issue that include an overall view and detailed view from multiple angles If applicable, a short video showing the issue Replacement Parts:...
- Page 4 Carton Contents 1 (x1) 2 (x1) 3 (x1) 4 (x1) 5 (x2) 8 (x1) 6 (x1) 7 (x1) 9 (x1) 11 (x1) 10 (x2) 15 (x2) 14 (x1) 13 (x2) 12 (x4) 32 (x46) (x1) 16 (x1) 33 (x46) TOOLS REQUIRED FOR ASSEMBLY: •...
- Page 5 Assembly Instructions Place Body Halves (1 & 2) on a smooth flat surface so they are square, and fasten together with hardware (32 & 33) as shown. Attach Front Support (16) to Body Halves (1 & 2) and tighten hardware (32 & 33) as shown. Attach Undercarriage (11) to Body Halves (1 &...
- Page 6 Assembly Instructions Attach Front Gate (3) to inside of body as shown and tighten hardware (32 & 33). Align Corner (5) onto lip of Body Halves (1& 2) and Front Gate (3) with hardware (32 & 33) as shown. Insert Axle (9) into Undercarriage (11) halfway as shown. Center Spacer (14) inside Swivel Clevis (21) and align with Axle (9).
- Page 7 Assembly Instructions Slide Axle (9) completely through Undercarriage (11); be sure to catch the Swivel Clevis (21) and Spacer (14) when sliding the Axle (9) through. Align drawbar with the Front Support (16) and press down to latch. Slide Washers (12), Spacers (13), and Wheels (10) onto Axle (9) and secure with Hairpins (15) as shown.
- Page 8 Assembly Instructions Attach Corner Gussets (6 &7) to rear and sides of body and tighten with hardware (32 & 33) as shown. Attach Tailgate (4) to body as shown. No hardware required, Tailgate should move freely up or down. Pull up on Spring Loaded Hitch Bracket (17) for attachment to vehicle.
- Page 9 Operating Instructions Before Using Dump Cart: Check tire pressure. If needed, inflate to displayed PSI on sidewall. Read all Safety Rules found on page 1. How to Use Dump Cart: Attach Dump Cart to your tractor using the supplied hitch pin. Do not exceed 1000 pounds when loading material into the cart body.
- Page 10 Repair Parts ITEM PART NO DESCRIPTION QTY ITEM PART NO DESCRIPTION 401011-Y1 BODY HALF, RIGHT (CC YELLOW) SPRING LOADED HITCH BRACKET (BLACK) 401021-Y1 BODY HALF, LEFT (CC YELLOW) HEX BOLT, 3/8-16 X 3/4" (BLACK) 401031-Y1 GATE, FRONT (CC YELLOW) HEX NUT, 3/8-16 C-LOCK (BLACK) 401041-Y1 TAILGATE (CC YELLOW) DRAWBAR, WELDED (BLACK) 401051-Y1 CORNER (CC YELLOW)
- Page 11 Notes...
- Page 12 Proudly designed and Manufactured in the U.S.A from tested in Columbus, Ohio domestic and imported components 16504 30449 MODEL # CCXGZOS3048SS...
