Operating Instructions • Warning Information
Parts Breakdown
™
SE75
Touch Up Gravity Feed
HVLP Spray Gun
SPECIFICATIONS
Fluid Orifice . . . . . . . . . . . . . . . 0.8mm
Air Inlet. . . . . . . . . . . . . . . . . . 1/4 NPT
Rec. Max. Inlet Pressure . . . . . . . . 43 PSI
Nozzle Pressure. . . . . . . . . . . . . . 10 PSI
CFM. . . . . . . . . . . . . . . . 3.03 @ 43 PSI
Cup Size. . . . . . . . . . . . . . . . . . . 150cc
Copyright © Professional Tool Products, 2005
All rights reserved.
SE75
1
Rev. 04/25/05
SE75_OpMan_051605.indd 1
5/16/05 4:38:40 PM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Matco Tools SE75
Summary of Contents for Matco Tools SE75
- Page 1 Operating Instructions • Warning Information Parts Breakdown ™ SE75 Touch Up Gravity Feed HVLP Spray Gun SPECIFICATIONS Fluid Orifice ....0.8mm Air Inlet....1/4 NPT Rec.
- Page 2 Protect yourself from a chance of inhaling sprayed materials. The noise. Noise levels vary with work mask must be compatible with the material being sprayed surface. Wear ear protectors. and its concentration. SE75 Rev. 04/25/05 SE75_OpMan_051605.indd 2 5/16/05 4:38:41 PM...
- Page 3 GRAVITY FEED CUP HOOKUP For fine finishing with limited spraying. Air pressure for atomization is regulated at extractor. Amount of fluid is adjusted by fluid control screw on gun, viscosity of paint, and air pressure. SE75 Rev. 04/25/05 SE75_OpMan_051605.indd 3 5/16/05 4:38:42 PM...
- Page 4 If the spray is too thick, close the fluid finished. control screw. Regulate the pattern width and repeat adjustment of spray as needed. Spray pattern may be infinitely adjusted from round to flat. SE75 Rev. 04/25/05 SE75_OpMan_051605.indd 4 5/16/05 4:38:43 PM...
- Page 5 If the parts can not easily be turned by hand, be sure you have the correct parts, unscrew, realign, and try again. NEVER use excessive force in matching parts. SE75 Rev. 04/25/05 SE75_OpMan_051605.indd 5 5/16/05 4:38:44 PM...
- Page 6 A.) Gun held too far from surface. Thin, sandy coarse finish. B.) Atomization pressure set B.) Adjust atomization pressure. too high. Thick, dimpled finish Gun held too close to surface. Move gun farther from surface. resembling orange peel. SE75 Rev. 04/25/05 SE75_OpMan_051605.indd 6 5/16/05 4:38:45 PM...
- Page 7 PARTS BREAKDOWN - SE75 �� � � � � � � � � � �� �� �� �� �� �� �� �� �� �� �� �� �� �� �� �� �� �� �� �� Optional nozzle kits available: RS82805NK 0.5mm RS82808NKR 0.8mm (color coded red)
- Page 8 PARTS LIST - SE75 ™ Index # Part # Description Qty. Index # Part # Description Qty. RS2601A Air Cap (0.8mm) - red RS1931 Air Inlet Fitting RS2006 Fluid Nozzle (0.8mm) RS2041A Air Valve Assembly RS2007 Air Distribution Ring RS2013...
