- Page 1 Drawer Warmer Models FW-CN-0001, 0002, 0003 Items 47546, 48884, 47547 Instruction Manual Revised - 02/28/2023 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model FW-CN-0001 / Mode FW-CN-0002 / Model FW-CN-0003 Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 6 Technical Specifications -------------------------------------------------------------------------- 7 Operation --------------------------------------------------------------------------------------------- 7 Maintenance ----------------------------------------------------------------------------------------- 8 Troubleshooting ------------------------------------------------------------------------------------- 9 Parts Breakdown... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 Safety and Warranty Do not operate this equipment unless you have read and understand the content of this manual! This manual contains important safety information concerning the maintenance, use and operation of this product. Keep this manual in a safe location for future reference. SAFETY INFORMATION Warmer drawers are designed, built and sold for commercial use and should be operated by trained personnel only.
- Page 6 1 YEAR PARTS AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally. Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not improper use.
-
Page 7: Technical Specifications
Technical Specifications Model FW-CN-0001 FW-CN-0002 FW-CN-0003 Number of Drawers Temperature Range 26.7 - 104.4°C / 80 - 220°F Power 450 W 900 W 1350 W Current 3.75A 7.5A 11.25A Electrical 110-120V / 60Hz / 1 Full Size Pan Size 12” x 20” x 6” / 305 x 508 x 152mm 20.3”... -
Page 8: Maintenance
Maintenance CLEANING GENERAL CLEANING INSTRUCTIONS: 1. Never clean any electrical unit by immersing it in water. Turn off before surface cleaning. 2. Always clean equipment thoroughly before first use. Clean unit daily except where noted on charts: Use warm, soapy water. Mild cleansers and PLASTIC souring pads may be used to remove baked-on food and water scale. -
Page 9: Troubleshooting
Troubleshooting Always ask and check the following: 1. Is the unit connected to a live power source of the proper voltage? 2. Check the circuit breaker. 3. Is power switch “ON” and pilot light glowing? 4. Check the rating label. Is the unit connected to the correct power source. SYMPTOMS POSSIBLE CAUSES REMEDY... -
Page 10: Parts Breakdown
Parts Breakdown Model FW-CN-0001 47546 Model FW-CN-0002 48884 Model FW-CN-0003 47547... - Page 11 Parts Breakdown Model FW-CN-0001 47546 Item No. Description Position Item No. Description Position Item No. Description Position AL997 Body Assembly for 47546 AM005 Gasket for 47546 AM013 Control Panel for 47546 AL998 Element Bracket for 47546 AM006 Drawer Inner Frame Weldment for 47546...
-
Page 12: Electrical Schematics
Electrical Schematics Model FW-CN-0001 47546... - Page 13 Electrical Schematics Model FW-CN-0002 48884...
- Page 14 Electrical Schematics Model FW-CN-0003 47547...
-
Page 15: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 16 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
