Summary of Contents for Omcan FW-CN-0066-C
- Page 1 Display Warmers Models FW-CN-0066-C, 0100-C Items 43120, 43121 Instruction Manual Revised - 06/19/2023 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model FW-CN-0066-C / Model FW-CN-0100-C Section Page General Information ---------------------------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 5 Technical Specifications -------------------------------------------------------------------------- 6 Installation --------------------------------------------------------------------------------------- 6 - 7 Operation --------------------------------------------------------------------------------------------- 7 Maintenance ------------------------------------------------------------------------------------ 7 - 8... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 1 YEAR PARTS AND LABOUR BENCH WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the equipment.
-
Page 6: Technical Specifications
Technical Specifications Model FW-CN-0066-C FW-CN-0100-C Temperature Range 30 - 85°C / 86 - 185°F Storage Volume 66 L / 2.33 cu.ft. 100 L / 3.53 cu.ft. Rated Current 4.5A 4.7A Rated Input Power 520 W 550 W Grade of Waterproof... -
Page 7: Installation
Installation • You must not position the device near open fireplaces, electric ovens or any other heat sources. • Position the device in such a way that the plug is easily accessible. Operation • Before first use, clean the inner sides and the shelves with a soft cloth and a mild cleaning agent. Afterwards, dry the device thoroughly. -
Page 8: Maintenance
Maintenance • Make sure the device has been cleaned properly before storing it. MAINTENANCE • Check the plug from time to time to ensure it is not damaged in any way. Never use the device if the plug or cables are damaged. If damaged, they must be replaced by a qualified electrician. •... -
Page 9: Parts Breakdown
Parts Breakdown Model FW-CN-0066-C 43120... - Page 10 Parts Breakdown Model FW-CN-0066-C 43120 Item No. Description Position Item No. Description Position Item No. Description Position 60101 Decorating Gasket of Nut for 43120 65439 Wire Supporter for 43120 65448 Heating Tube for 43120 60102 Nut Decorating Parts for 43120...
- Page 11 Parts Breakdown Model FW-CN-0100-C 43121...
- Page 12 Parts Breakdown Model FW-CN-0100-C 43121 Item No. Description Position Item No. Description Position Item No. Description Position 60101 Decorating Gasket of Nut for 43121 71662 Thermostat 125 Degree for 43121 65465 Heating Tube Bracket for 43121 60102 Nut Decorating Parts for 43121 60497 Thermostat 95 Degree for 43121 60735...
-
Page 13: Electrical Schematics
Electrical Schematics Model FW-CN-0066-C 43120... - Page 14 Electrical Schematics Model FW-CN-0100-C 43121...
-
Page 15: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 16 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
