7.2.6 Connections between outdoor and indoor unit using reducers

4MWXM-A9
R32 Split series
4P708645-1 – 2022.09
a
a Cut exactly at right angles.
b Remove burrs.
3 Remove the flare nut from the stop valve and put the flare nut on the pipe.
4 Flare the pipe. Set exactly at the position as shown in the following figure.
A
Flare tool for R32
(clutch type)
A 0~0.5 mm
5 Check that the flaring is properly made.
a
a Flare's inner surface MUST be flawless.
b The pipe end MUST be evenly flared in a perfect circle.
c Make sure the flare nut is fitted.
Total indoor air conditioning units capacity class that can be connected to this
outdoor unit
Port Dimensions
A Liquid Ø6.4 mm
Gas Ø9.5 mm
B+C Liquid Ø6.4 mm
Gas Ø12.7 mm
To tank Liquid Ø6.4 mm
Gas Ø9.5 mm
(a)
Only in case of connection with FTXM42R.
(b)
Only for connection with FBA71A9. Use option ASYCPIR for liquid (Ø9.5 mm→Ø6.4 mm)
and gas (Ø15.9 mm→Ø12.7 mm) piping.
Ø12.7 mm → Ø9.5 mm
1 2
b
Conventional flare tool
Clutch type
(Ridgid-type)
1.0~1.5 mm
b
c
≤9.0 kW
Class
15, 20, 25, 35, (42)
15, 20, 25, 35, (42)
42, 50, 60
(b)
71
90, 120
7 Piping installation
|
Wing nut type
(Imperial-type)
1.5~2.0 mm
Reducer
(a)
—
(a)
1+2 (accessory)
—
ASYCPIR
—
