- Page 1 Mr. Beam 120 W moving head user manual...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 26.11.2021, ID: 528923...
-
Page 3: Table Of Contents
Table of contents Table of contents General information......................4 1.1 Further information......................4 1.2 Notational conventions....................4 1.3 Symbols and signal words................... 5 Safety instructions......................... 6 Features............................8 Installation..........................9 Starting up..........................11 Connections and operating elements................ 12 Operating..........................14 7.1 Starting the device....................... -
Page 4: General Information
1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. -
Page 5: Symbols And Signal Words
General information 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. -
Page 6: Safety Instructions
Safety instructions Safety instructions Intended use This device is intended for use as a freely moving multifunctional spotlight. The device is designed for professional use and is not suitable for use in households. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. - Page 7 Safety instructions CAUTION! Risk of injury due to movements of the device The head of the device can move quickly (pan, tilt) and can produce very bright light. This is also valid immediately after you turn on the device, when the device operates in automatic mode or under remote control and when you turn off a DMX controller that is connected to the device.
-
Page 8: Features
Features Features The device is particularly suitable for professional lighting tasks, for example at events, on rock stages, in theatres and musicals, in nightclubs as well as for mobile DJ's and entertainers. Special features of the device: Bar with four individually controllable beam moving heads 4 ×... -
Page 9: Installation
Installation Installation Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. Lift the device only at the base. - Page 10 Installation NOTICE! Possible damage caused by movements of the device Always ensure that enough space is free around the device for the movements of the head (pan, tilt). NOTICE! Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordinary microphone cables.
-
Page 11: Starting Up
Starting up Starting up Create all connections while the device is off. Use the shortest possible high-quality cables for all connections. Take care when running the cables to prevent tripping hazards. Connections in DMX mode Connect the DMX input of the device to the DMX output of a DMX controller or another DMX device. -
Page 12: Connections And Operating Elements
Connections and operating elements Connections and operating elements ö PUSH & + , - 1 Light aperture 2 Tripod mount 3 [Power In] Lockable input socket (Power Twist) for mains power supply 4 [DMX In] DMX input, designed as XLR panel plug, 3-pin 5 Fuse holder 6 Display 7 [MODE]... - Page 13 Connections and operating elements 13 [Power Out] Lockable output socket (Power Twist) for powering a connected device 14 [DMX Out] DMX output, designed as XLR panel socket, 3-pin Mr. Beam 120 W...
-
Page 14: Operating
Operating Operating 7.1 Starting the device CAUTION! Risk of injury due to movements of the device The head of the device can move quickly (pan, tilt) and can produce very bright light. This is also valid immediately after you turn on the device, when the device operates in automatic mode or under remote control and when you turn off a DMX controller that is connected to the device. - Page 15 Operating Main menu Menu level 2 Menu level 3 Menu level 4 Meaning ‘DMX menu’ ‘DMX Addr’ Setting the DMX address ‘001…512’ ‘Channels Select’ Selecting a DMX mode ‘15CH ’ 15-channel DMX mode ‘16CH ’ 16-channel DMX mode ‘26CH’ 26-channel DMX mode ‘46CH’...
- Page 16 Operating Main menu Menu level 2 Menu level 3 Menu level 4 Meaning ‘Key Lock’ Key lock 30 seconds after last keystroke ‘ON’ Switching on When the key lock is activated, press successively [MODE], [DOWN], [UP] and [ENTER] to unlock the keys.
- Page 17 Operating Main menu Menu level 2 Menu level 3 Menu level 4 Meaning ‘Test’ Test run prism ‘Reset’ New calibration prism ‘Reverse’ Reverse of the prism ‘Record Scene’ Recording scenes ‘ShowMode’ ‘Yes ’ Recording a running scene. ‘No ’ Not recording a running scene. ‘RDM’...
-
Page 18: Functions In 15-Channel Dmx Mode
Operating 7.3 Functions in 15-channel DMX mode Channel Value Function 0…255 Master dimmer 0 %…100…% Stroboscope 0…9 No function (open) 10…255 Strobe effect (1 Hz…25 Hz), increasing speed 0…255 Rotation (pan) (0° up to the maximum value of the Pan range of 540°) 0…255 Inclination (tilt) (0°... - Page 19 Operating Channel Value Function 145…159 Colour effect 10 160…174 Colour effect 11 175…189 Colour effect 12 190…204 Colour effect 13 205…219 Colour effect 14 220…255 No function 0…255 Increasing running speed colour effect Mr. Beam 120 W...
-
Page 20: Functions In 16-Channel Dmx Mode
Operating 7.4 Functions in 16-channel DMX mode Channel Value Function 0…255 Master dimmer 0 %…100…% Stroboscope 0…9 No function (open) 10…255 Strobe effect (1 Hz…25 Hz), increasing speed 0…255 Rotation (pan) (0° up to the maximum value of the Pan range of 540°) 0…255 Fine adjustment rotation (pan) 0…255... - Page 21 Operating Channel Value Function 130…144 Colour effect 9 145…159 Colour effect 10 160…174 Colour effect 11 175…189 Colour effect 12 190…204 Colour effect 13 205…219 Colour effect 14 220…255 No function 0…255 Increasing running speed colour effect Mr. Beam 120 W...
-
Page 22: Functions In 26-Channel Dmx Mode
Operating 7.5 Functions in 26-channel DMX mode Channel Value Function 0…255 Master dimmer 0 %…100…% Stroboscope 0…9 No function (open) 10…255 Strobe effect (1 Hz…25 Hz), increasing speed 0…255 Rotation (pan) head 1 (0° up to the maximum value of the pan range of 540°) 0…255 Inclination (tilt) head 1 (0°... - Page 23 Operating Channel Value Function Colour effect 0…9 No function 10…24 Colour effect 1 25…39 Colour effect 2 40…54 Colour effect 3 55…69 Colour effect 4 70…84 Colour effect 5 85…99 Colour effect 6 100…114 Colour effect 7 115…129 Colour effect 8 130…144 Colour effect 9 145…159...
-
Page 24: Functions In 46-Channel Dmx Mode
Operating 7.6 Functions in 46-channel DMX mode Channel Value Function 0…255 Master dimmer 0 %…100…% Stroboscope 0…9 No function (open) 10…255 Strobe effect (1 Hz…25 Hz), increasing speed 0…255 Rotation (pan) head 1 (0° up to the maximum value of the pan range of 540°) 0…255 Fine adjustment rotation (pan) head 1 0…255... - Page 25 Operating Channel Value Function 0…255 Intensity green head 3 0…255 Intensity blue head 3 0…255 Intensity white head 3 0…255 Rotation (pan) head 4 (0° up to the maximum value of the pan range of 540°) 0…255 Fine adjustment rotation (pan) head 4 0…255 Inclination (tilt) head 4 (0°...
- Page 26 Operating Channel Value Function 160…174 Colour effect 11 175…189 Colour effect 12 190…204 Colour effect 13 205…219 Colour effect 14 220…255 No function 0…255 Increasing running speed colour effect moving head...
-
Page 27: Remote Control
Remote control Remote control To use the remote control, point its infrared diode at the infrared sensor on the unit ö and press the desired buttons. The maximum operating distance is about 9 m. The device will only respond to the remote control signals if it is not controlled via DMX. To activate remote control operation, press [STAND BY] on the remote control and STAND BY &... - Page 28 Remote control 9 [SOUND ON] Activates the sound-control. 10 [SHOW] Calls up one of the preprogrammed automatic shows. Then press one of the number buttons [1] - [9] for the desired show. To cancel a show, press [STAND BY]. 11 [SOUND OFF] Deactivates the sound-control.
-
Page 29: Technical Specifications
Technical specifications Technical specifications PUSH 1015 mm Light source 4 × 30 W RGBW LED Optical properties Beam angle 4° Control Buttons and display on the unit Infrared remote control Rotation angle (pan), max. 540° Inclination angle (tilt), max. 230° Number of DMX channels 15, 16, 26 or 46 Control protocol... - Page 30 Technical specifications Further information Illuminant type Colour mixture RGBW Gobo wheel Prism Motorized focus Motorized zoom moving head...
-
Page 31: Plug And Connection Assignments
Plug and connection assignments Plug and connection assignments Introduction This chapter will help you select the right cables and plugs to connect your valuable equipment so that a perfect light experience is guaranteed. Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into a socket, the result of an incorrect connection may be a destroyed DMX controller, a short circuit or ‘just’... -
Page 32: Troubleshooting
4. Check to see if the DMX cables run near or alongside to high voltage cables that may cause damage or interference to DMX interface circuits. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. moving head... -
Page 33: Cleaning
Cleaning Cleaning Optical lenses Clean the optical lenses, that are accessible from the outside, regularly in order to optimize the light output. The frequency of cleaning depends on the operating envi‐ ronment: wet, smoky or particularly dirty surroundings can cause more accumulation of dirt on the optics of the device. -
Page 34: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging material For the packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 36 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
