Schaffner Group
I
Product Marketing
T +41 32 681 66 26
I
F +41 32 681 66 30
dv/dt Filter Series FN 5060
Mounting and Installation Guidelines
Please read and follow the safety, application and installation notes.
Important safety notes
Filter installation, start-up, operation and maintenance (if any) has to be carried out by a
trained and certified electrician or technician, who is familiar with safety procedures in
electrical systems.
Danger of electrical shock! High voltage potentials are involved in the operation of this
product. Always remove power before handling energized parts of the filter, and let ample
time elapse for the capacitors to discharge to safe levels (<42 V). Residual voltages are to be
measured both line to line and line to earth.
Always connect the filter to protective earth (PE) first, then continue with the wiring of phase
terminals. When decommissioning the filter, remove the PE connection at the end. The sine
wave filter must not be operating without connected motor.
Follow the general installation notes closely. Ensure that cooling slots, openings or grids (if
any) are free from obstructions that could inhibit efficient air circulation. Operate the filter
within its electrical, mechanical, thermal and ambient specifications at all times.
For safety reasons, dv/dt filters must be installed in a way to prevent access of non-qualified
persons to the filters.
dv/dt filters are lossy electrical components. Filter surfaces and terminals may get hot under
full load operating conditions and can exceed surface temperature >70 °C.
Always practice the safety procedures defined by your company and by applicable national
electric codes when handling, installing, operating or maintaining electrical equipment.
In case of uncertainty and questions please contact your local Schaffner partner for
assistance.
INS 143824 B
I
Nordstrasse 11
I
4542 Luterbach
I
www.schaffner.com
CN50006398 02.06.2015 EJE
I
Switzerland
1I4
Advertisement
Table of Contents
Related Manuals for Schaffner FN 5060 Series
Summary of Contents for Schaffner FN 5060 Series
- Page 1 Always practice the safety procedures defined by your company and by applicable national electric codes when handling, installing, operating or maintaining electrical equipment. In case of uncertainty and questions please contact your local Schaffner partner for assistance. INS 143824 B...
- Page 2 Special attention should be paid to cable dimensioning, fuses, grounding, shutdown, disconnection, and overcurrent protection. In order to get the maximum benefit out of the Schaffner filters, please also consult “Basics in EMC and Power Quality”, published in the download section of www.schaffner.com. These additional guidelines provide helpful hints for HF-grounding, shielding, proper cable routing, etc.
- Page 3 Schaffner Group dv/dt Filter FN 5060 Mounting and Installation Guidelines Filter placement and mounting Lift the heavy IP00-filters of series FN 5060 which do have lifting eyes with appropriate lifting aids – smaller types may be lifted manually by two persons (no lifting eye bolt applicable).
- Page 4 In many applications a shielded motor cable may not be required. Anyhow, due to other possible influences of common mode disturbances Schaffner does recommend to use shielded motor cables. This is to avoid back-coupling of radiated interferences to the mains cable at the frequency range from 1–30 MHz.
