- Page 1 Installer manual HRV unit NIBE ERS 30-600 IHB EN 2306-1 731443...
- Page 2 S-series F-series S1255...
-
Page 3: Table Of Contents
5 Electrical connection Overview accessory board (AA5) Supply Connecting to main product 6 Commissioning and adjusting Preparations Filling Start-up and inspection 7 Activating ERS 30 Start guide Menu system 8 Disturbances in comfort Troubleshooting 9 Accessories NIBE ERS 30-600 Chapter |... -
Page 4: Important Information
To access the separate components, refer to the section If the supply cable is damaged, only NIBE, that shows the construction of the product. No special tools its service representative or similar author- are required for access. -
Page 5: Inspection Of The Installation
In addition, fill in the page for the installation data in the User Manual. Description Notes Signature Date ✔ Electricity (page 12) Connections Main voltage Fuses property Earth circuit-breaker NIBE ERS 30-600 Chapter 1 | Important information... -
Page 6: Delivery And Handling
SMO S40 • S1255 • VVM S325 Removing the covers Open the filter cover as illustrated. Pull out the filters. 3. Unscrew the screws as illustrated and pull out the front panel. Chapter 2 | Delivery and handling NIBE ERS 30-600... -
Page 7: Assembly
-25 °C and max. 50 °C. INSTALLATION AREA Leave a free space of 600 mm in front of the product. NOTE Ensure that there is sufficient space (300 mm) for connecting ventilation ducts. NIBE ERS 30-600 Chapter 2 | Delivery and handling... -
Page 8: Design Of The Hrv Unit
Design of the HRV unit XL34 BT23 QN37 HQ11 BT20 XL31 HQ10 BT22 XL32 W101 W102 XL40 BT21 EP26 XL33 Chapter 3 | Design of the HRV unit NIBE ERS 30-600... -
Page 9: Pipe Connections
Exhaust air fan Supply air fan HQ10 Exhaust air filter HQ11 Supply air filter QN37 Bypass damper Miscellaneous Type plate Condensation water trough Designations according to standard EN 81346-2. NIBE ERS 30-600 Chapter 3 | Design of the HRV unit... -
Page 10: Ventilation Connections
Clean, if necessary. NOTE During operation, negative pressure arises in the HRV unit, which means that a water column of at least 100 mm must be guaranteed in the water seal. Chapter 4 | Ventilation connections NIBE ERS 30-600... -
Page 11: General Ventilation Connections
The supply air flow must be lower than the exhaust air flow to prevent over pressure in the house. Set the ventilation capacity in the main product’s menu system (menu 7.1.4 - "Ventilation"). NIBE ERS 30-600 Chapter 4 | Ventilation connections... -
Page 12: Electrical Connection
NOTE Because there can be different connections for accessories If the supply cable is damaged, only NIBE, its ser- with accessory board (AA5), you should always read the in- vice representative or similar authorised person structions in the manual for the accessory that is to be in- may replace it to prevent any danger and damage. - Page 13 ERS 30 no. 2 +12V Accessory 1 AA5-X4 ERS 30 no. 3 ERS 30 no. 4 Accessory 2 AA5-X4 ERS 30 no. 5 ERS 30 no. 6 ERS 30 no. 7 ERS 30 no. 8 NIBE ERS 30-600 Chapter 5 | Electrical connection...
-
Page 14: Commissioning And Adjusting
100 120 140 160 180 200 220 NOTE Airflow Flöde (l/s) Order a ventilation adjustment to complete the The diagram shows the power consumption per fan. setting. Chapter 6 | Commissioning and adjusting NIBE ERS 30-600... -
Page 15: Activating Ers 30
If necessary, the different return times can be changed in regularly, although how often depends of factors such as menu 1.2.5. the amount of particles in the ventilation air. Test to find out what is most appropriate for your installation. NIBE ERS 30-600 Chapter 7 | Activating ERS 30... - Page 16 St temp sup air cooled by exh air: Here, you set the outdoor temperature at which cooling recovery will start. Chapter 7 | Activating ERS 30 NIBE ERS 30-600...
-
Page 17: Disturbances In Comfort
The exhaust air filter (HQ10) and/or the supply air filter (HQ11) is clogged. – Replace the filters. • The ventilation is not adjusted. – Order/implement ventilation adjustment. • Closed, too much choke or blocked ventilation device. NIBE ERS 30-600 Chapter 8 | Disturbances in comfort... -
Page 18: Accessories
Accessories Detailed information about the accessories and complete accessories list available at nibe.eu. Not all accessories are available on all markets. ELECTRICAL AIR HEATER EAH 20 In cold weather, EAH heats the incoming outdoor air slightly to prevent the condensation in ERS 30 from freezing to form ice. -
Page 19: Technical Data
Technical data Dimensions 1280 Ø160 Ø200 NIBE ERS 30-600 Chapter 10 | Technical data... -
Page 20: Technical Specifications
3 Scale for efficiency class: A+ to G. Dry temperature efficiency according to EN Temperature efficiency Temperaturverkningsgrad enligt EN308 Airflow Luftflöde (m³/h) (m³/h) Outdoor air: 5 °C Exhaust air 25 °C RH exhaust air: <27.7 % Chapter 10 | Technical data NIBE ERS 30-600... -
Page 21: Energy Labelling
Information about supply/exhaust grilles in the See the "Ventilation connections" section. facade Information about pre-/disassembly See the "Recovery" section. This installer manual can also be accessed at nibe.eu. The annual electricity consumption kWh/year Annual heating saved, kWh primary energy per year Average: 4,332... -
Page 22: Electrical Circuit Diagram
Electrical circuit diagram Chapter 10 | Technical data NIBE ERS 30-600... - Page 23 15 Electrical connection Overview accessory board (AA5) Supply Connecting to main product 16 Commissioning and adjusting Preparations Filling Start-up and inspection 17 Activating ERS 30 Start guide Menu system 18 Disturbances in comfort Troubleshooting 19 Accessories NIBE ERS 30-600 Chapter |...
-
Page 24: Important Information
To access the separate components, refer to the section If the supply cable is damaged, only NIBE, that shows the construction of the product. No special tools its service representative or similar author- are required for access. -
Page 25: Inspection Of The Installation
In addition, fill in the page for the installation data in the User Manual. Description Notes Signature Date ✔ Electricity (page 32) Connections Main voltage Fuses property Earth circuit-breaker NIBE ERS 30-600 Chapter 11 | Important information... -
Page 26: Delivery And Handling
F1345 • F1355 Removing the covers Open the filter cover as illustrated. 4. Unscrew both of the screws at the top and lift off the top panel. Pull out the filters. Chapter 12 | Delivery and handling NIBE ERS 30-600... -
Page 27: Assembly
-25 °C and max. 50 °C. INSTALLATION AREA Leave a free space of 600 mm in front of the product. NOTE Ensure that there is sufficient space (300 mm) for connecting ventilation ducts. NIBE ERS 30-600 Chapter 12 | Delivery and handling... -
Page 28: Design Of The Hrv Unit
Design of the HRV unit XL34 BT23 QN37 HQ11 BT20 XL31 HQ10 BT22 XL32 W101 W102 XL40 BT21 EP26 XL33 Chapter 13 | Design of the HRV unit NIBE ERS 30-600... -
Page 29: Pipe Connections
Exhaust air fan Supply air fan HQ10 Exhaust air filter HQ11 Supply air filter QN37 Bypass damper Miscellaneous Type plate Condensation water trough Designations according to standard EN 81346-2. NIBE ERS 30-600 Chapter 13 | Design of the HRV unit... -
Page 30: Ventilation Connections
Clean, if necessary. NOTE During operation, negative pressure arises in the HRV unit, which means that a water column of at least 100 mm must be guaranteed in the water seal. Chapter 14 | Ventilation connections NIBE ERS 30-600... -
Page 31: General Ventilation Connections
The supply air flow must be lower than the exhaust air flow to prevent over pressure in the house. Set the ventilation capacity in the main product’s menu system (menu 5.1.5). NIBE ERS 30-600 Chapter 14 | Ventilation connections... -
Page 32: Electrical Connection
If several accessories are to be connected, or are already NOTE installed, the boards are connected in series. If the supply cable is damaged, only NIBE, its ser- Because there can be different connections for accessories vice representative or similar authorised person with accessory board (AA5), you should always read the in- may replace it to prevent any danger and damage. - Page 33 ERS 30 no. 3 ERS 30 no. 4 AA5-X4 -X10 Accessory card 2 AA5-X4 AA5-X4 ERS 30 no. 5 ERS 30 no. 6 -X10 ERS 30 no. 7 ERS 30 no. 8 NIBE ERS 30-600 Chapter 15 | Electrical connection...
-
Page 34: Commissioning And Adjusting
100 120 140 160 180 200 220 NOTE Airflow Flöde (l/s) Order a ventilation adjustment to complete the The diagram shows the power consumption per fan. setting. Chapter 16 | Commissioning and adjusting NIBE ERS 30-600... -
Page 35: Activating Ers 30
Factory setting: ERS 20 / ERS 30 action level monitor Setting range: off, blocked, level monitor Default value: level monitor months btwn filter alarms: Set how often the filter alarm is to be displayed. NIBE ERS 30-600 Chapter 17 | Activating ERS 30... -
Page 36: Disturbances In Comfort
The exhaust air filter (HQ10) and/or the supply air filter (HQ11) is clogged. – Replace the filters. • The ventilation is not adjusted. – Order/implement ventilation adjustment. • Closed, too much choke or blocked ventilation device. Chapter 18 | Disturbances in comfort NIBE ERS 30-600... -
Page 37: Accessories
Accessories Detailed information about the accessories and complete accessories list available at nibe.eu. Not all accessories are available on all markets. ELECTRICAL AIR HEATER EAH 20 In cold weather, EAH heats the incoming outdoor air slightly to prevent the condensation in ERS 30 from freezing to form ice. -
Page 38: Technical Data
Technical data Dimensions 1280 Ø160 Ø200 Chapter 20 | Technical data NIBE ERS 30-600... -
Page 39: Technical Specifications
3 Scale for efficiency class: A+ to G. Dry temperature efficiency according to EN Temperature efficiency Temperaturverkningsgrad enligt EN308 Airflow Luftflöde (m³/h) (m³/h) Outdoor air: 5 °C Exhaust air 25 °C RH exhaust air: <27.7 % NIBE ERS 30-600 Chapter 20 | Technical data... -
Page 40: Energy Labelling
Information about supply/exhaust grilles in the See the "Ventilation connections" section. facade Information about pre-/disassembly See the "Recovery" section. This installer manual can also be accessed at nibe.eu. The annual electricity consumption kWh/year Annual heating saved, kWh primary energy per year Average: 4,332... -
Page 41: Electrical Circuit Diagram
Electrical circuit diagram NIBE ERS 30-600 Chapter 20 | Technical data... - Page 42 Serial number, 4, 24 Start guide, 15, 35 Start-up and inspection Setting the ventilation, 14, 34 The design of the exhaust air module List of components, 9, 29 Transport and storage, 6, 26 Troubleshooting, 17, 36 Item register NIBE ERS 30-600...
-
