- Page 1 IHB EN 1925-1 INSTALLATION MANUAL 531281 Exhaust air module NIBE S135...
-
Page 3: Table Of Contents
Installation exhaust air General ventilation connections Dimension and ventilation connections Ventilation flow (exhaust air) Adjusting ventilation (exhaust air) 5 Electrical connections General Connections Optional connections 6 Commissioning and adjusting Preparations Filling and venting Start-up and inspection NIBE S135 Table of Contents... -
Page 4: Important Information
You need the product's (14 digit) serial number for servicing and support. Caution This symbol indicates important information about what you should consider when installing or servicing the installation. This symbol indicates tips on how to facilitate using the product. Chapter 1 | Important information NIBE S135... -
Page 5: Recovery
It must be disposed of at a special waste station or dealer who provides this type of service. Improper disposal of the product by the user results in administrative penalties in accordance with current le- gislation. NIBE S135 Chapter 1 | Important information... -
Page 6: Inspection Of The Installation
✔ Ventilation, exhaust air (page Setting the ventilation flow Exhaust air filter Heating medium (page 22) System flushed System vented Circulation pump setting System pressure Electricity (page Supply connected 230 V Circuit fuses Chapter 1 | Important information NIBE S135... -
Page 7: Delivery And Handling
20-55 mm 30 - 50 mm • S135 must be positioned with the back towards a wall. Install the brackets or position S135 against an outside wall, ideally in a room where noise does not matter, in order to eliminate noise problems. If this is not possible, avoid placing it against a wall behind a bed- room or other room where noise may be a problem. -
Page 8: Supplied Components
6 x nuts cable must be disconnected. 6 x screws 4 x washers 1 Only for VVM 310 / VVM 500 LOCATION The kit of supplied items is placed on top of the product. Chapter 2 | Delivery and handling NIBE S135... - Page 9 SIDE PANELS Undo the screws at the edge. Twist the cover slightly outward. Move the side cover outwards and backwards. Assembly takes place in the reverse order. L E K NIBE S135 Chapter 2 | Delivery and handling...
-
Page 10: The Exhaust Air Module Design
3 The exhaust air module design Component positions XL43 BT77 XL44 QM25 BT12 GQ10 EB10 BT76 BT16 QN20 BT13 Chapter 3 | The exhaust air module design NIBE S135... -
Page 11: List Of Components
BT16 Temperature sensor, evaporator BT76 Temperature sensor, defrosting MISCELLANEOUS BT77 Temperature sensor, incoming air Rating plate Serial number plate Not visible in the image Designations according to standard EN 81346-2. NIBE S135 Chapter 3 | The exhaust air module design... -
Page 12: Pipe And Air Connections
Shut-off valve Pipe installation must be carried out in accordance with Non-return valve current norms and directives. Circulation pump S135 is only designed for upright installation. All connec- Expansion valve tions are equipped with smooth pipe for compression ring couplings. Compressor A safety valve must be installed in the system where S135 is present. -
Page 13: Dimensions And Pipe Connections
SYSTEM DIAGRAM Dimensions and pipe S135 is an exhaust air module. connections When the air passes through the evaporator, the refri- gerant evaporates because of its low boiling point. In this way the energy in the air is transferred to the refri- gerant. -
Page 14: Mounting
Screw S135 into place in the brackets using the M5 Mounting screws and nuts supplied. The exhaust air module is wall-mounted using the brackets enclosed. The exhaust air module can also be placed on a suitable flat surface. NOTE Check that the mountings are located in the intended grooves on the exhaust air module. -
Page 15: Connection To Indoor Module And Air/Water Heat Pump
(XL9) are connected to the return line between the indoor module and the air/water heat pump. The particle filter must be installed before S135 to prevent dirt from depositing in S135. Install the shut-off valves outside S135 to facilitate any future ser- vicing. - Page 16 DOCKING NIBE AIR/WATER HEAT PUMP DOCKING S135, NIBE HWM, AIR/WATER HEAT PUMP, POOL, COOLING The demand on S135 is controlled by the indoor module in the system. The pump and fan speed are also con- S135 connected in air/water system with 4-pipe cooling.
-
Page 17: General Ventilation Connections
Exhaust air duct (kitchen fan) must not be connected to S135. ventilation To prevent food vapour being transferred to S135 the distance between the kitchen fan and the exhaust air connections device must be considered. The distance should not be less than 1.5 m, but this can vary between different in-... -
Page 18: Ventilation Flow (Exhaust Air)
Ventilation flow (exhaust air) Connect S135 so that all the exhaust air, except kitchen duct air (kitchen fan), passes through the evaporator (EP1) in the exhaust air module. The ventilation flow must comply with the applicable national standards. For the optimum exhaust air module performance, the ventilation flow should not be less than 20 l/s (72 m³/h) -
Page 19: Electrical Connections
• Disconnect S135 before insulation testing the house wiring. S135 is connected to an earthed socket with the factory- • For electrical wiring diagram for S135, see page installed connection cable (length approx. 2.8 m), which is fitted with a plug. - Page 20 COMMUNICATION VVM S S135 S135 is connected to the indoor module/control module AA2-X30 and circulation pump via the connectors (XF10) and (XF11), which are placed underneath S135. AA2-XF11 CONTROL MODULE Connect the control module’s joint board (AA100-X9) to the supplied 4-pin connector (X11) according to the table.
-
Page 21: Optional Connections
Connecting the shut-off valve (QN44) Connect the shut-off valve’s motor (QN44) to AA5-X9:2 (signal), AA5-X9:1 (N) and AA5-X10:2 (230 V) in the cooling accessory’s unit box. Unit box External AA5-X9 QN44 Black Blue Brown -X10 AA5-X10 NIBE S135 Chapter 5 | Electrical connections... -
Page 22: Commissioning And Adjusting Preparations
There must be water in the climate system before S135 is started. Open the externally mounted filler valves. S135 and the rest of the climate system are filled with water. When the water that exits the vent valve (QM25) is NOTE not mixed with air, close the valve. - Page 23 NOTE Order a ventilation adjustment to complete the setting. Fan capacity Available pressure Tillgängligt tryck (Pa) 100% (l/s) Airflow Luftflöde Power, fan Output Effekt 100% (l/s) Airflow Luftflöde NIBE S135 Chapter 6 | Commissioning and adjusting...
-
Page 24: Control - Menus
Lowest diff., outdoor/exhaust air Setting range: on/off Setting range: 3 – 10 °C Here you can set the charge pump speed for S135. You Activate night cooling here. can also choose to charge hot water with S135 at the When the temperature in the house is high and the same time as the outdoor section is producing cooling. - Page 25 “hot water during cooling” to be activated. MENU 7.1.4.1 - FAN SPEED EXHAUST AIR Normal and Speed 1-4 Setting range: 0 – 100 % Set the speed for the five different selectable speeds for the fan here. NIBE S135 Chapter 7 | Control - Menus...
-
Page 26: Disturbances In Comfort
BASIC ACTIONS – Check and adjust the condensation water hose. Start by checking the following items: • That the feed cable is connected to S135. • Group and main fuses of the accommodation. • The property's earth circuit breaker. LOW OR A LACK OF VENTILATION (EXHAUST AIR INSTALLATION) •... -
Page 27: Accessories
Not all accessories are available on all markets. Some accessories manufactured before 2019 may need to have their circuit board updated in order to be com- patible with S135. For more information, see the Installer Manual for the relevant accessory. Top cabinet TOC 40 Top cabinet, which conceals any pipes/ventilation ducts. -
Page 28: Technical Data
10 Technical data Dimensions and setting-out coordinates Chapter 10 | Technical data NIBE S135... -
Page 29: Technical Specifications
/h), exkl. driveffekt för fläkt The value varies with the fan speed selected. For more detailed sound data, including sound to ducts, visit nibe.eu. The value can vary with the room’s damping capacity. These values apply at a damping of 4 dB. -
Page 30: Energy Labelling
Annual energy consumption space heating, warm cli- 587 / 731 mate Seasonal space heating energy efficiency, cold climate 147 / 117 Seasonal space heating energy efficiency, warm cli- 136 / 110 mate Sound power level L outdoors Chapter 10 | Technical data NIBE S135... - Page 31 Nominal heating medium flow 0.13 Annual energy consumption 1,087 Brine flow brine-water or water-water heat pumps Contact information NIBE Energy Systems – Box 14 – Hannabadsvägen 5 – 285 21 Markaryd – Sweden NIBE S135 Chapter 10 | Technical data...
-
Page 32: Electrical Circuit Diagram
ELECTRICAL CIRCUIT DIAGRAM Chapter 10 | Technical data NIBE S135... -
Page 33: Item Register
Serial number, 4 Electrical connections, 19 Start-up and inspection, 22 Connections, 19 Setting the ventilation, 23 General, 19 Start-up with NIBE Indoor module, 22 Energy labelling, 30 Supplied components, 8 Information sheet, 30 Symbol key, 12 Technical documentation, 31 Symbols, 4... -
Page 35: Contact Information
Tel: +46 (0)433-27 3000 kuzmin@evan.ru info@nibe.se nibe-evan.ru nibe.se SWITZERLAND NIBE Wärmetechnik c/o ait Schweiz Industriepark, CH-6246 Altishofen Tel. +41 (0)58 252 21 00 info@nibe.ch nibe.ch For countries not mentioned in this list, contact NIBE Sweden or check nibe.eu for more information. - Page 36 WS release date: 2019-06-26 07:52 Publish date: 2019-07-04 09:20 This manual is a publication from NIBE Energy Systems. All product illustrations, facts and data are based on the available information at the time of the publication’s approval. NIBE Energy Systems makes reservations for any factual or printing errors in this manual.
