H3C MSR3600-28-X1 Quick Start

H3C MSR3600-28-X1[28-X1-DP][51-X1][51-X1-DP] Routers Installation Quick Start-AP100
H3C MSR3600-28-X1[28-X1-DP][51-X1][51-X1-DP]路由器 快速安装指南-AP100
Tool list 工具参考
The installation tools are not provided with the device. Prepare them yourself as required.
设备不随机提供安装工具，请用户根据实际安装需求自己准备安装工具。
Flat-head screwdriver Phillips screwdriver
一字螺丝刀 十字螺丝刀
ESD wrist strap Network cable tester
防静电腕带 测线仪
Accessories 安装附件介绍
Wear an ESD wrist strap. Make sure the strap makes good skin contact and is reliably grounded.
!
操作者需佩戴防静电腕带，确保防静电腕带与皮肤良好接触，并确认防静电腕带已经良好接地。
M4 screw
Mounting brackets
M4 挂耳螺钉
挂耳
Console cable Power cord
配置电缆
电源线
Airflow design of the device 设备的风向设计
Needle-nose pliers Wire-stripping pliers
尖嘴钳 剥线钳
Heat gun Multimeter
热风枪 万用表
Grounding cable Rubber feet
地线 脚垫
M6 screw (user supplied) Cage nut (user supplied)
M6 机柜螺钉(用户自备) 浮动螺母(用户自备)
ThisdocumentusestheMSR3600-28-X1-DProuterasanexample.
本手册仅以MSR3600-28-X1-DP为例进行介绍。
Mounting the device on a workbench 安装设备到工作台
Diagonal pliers
斜口钳
Marker
记号笔
Mounting the device in a rack 安装设备到机柜
Install cage nuts 安装浮动螺母
Baillatch
电源线卡钩
Attach the mounting brackets to the device 安装挂耳到设备
1RU
BOM:3104A0X1
