Controls and Operation

CONTROLS AND OPERATION
USER INTERFACE MODULE (UIM)
Input operations, including temperature regulation, user
options, and settings; see possible issues; and enter service
functions for the electronic control system through the touch
sensitive UIM.
Boot-Up Screen
The Boot-Up screen appears when power is first supplied to the
unit.
Power Screen
The Power screen appears after initial boot-up. To turn on the
unit, touch and hold Power for 3 seconds.
Home Screen
After turning the unit on, the Home screen with Automatic
Display Lock icon appears. Current temperatures appear on the
display. The automatic display lock is on by default.
7041810 REVA
03/2019
To unlock the automatic display lock, touch and hold the lock
icon for 3 seconds. The Unlocked screen is shown. Then the
Home screen is shown.
After unlocking the automatic display lock, the Home screen
appears. The Setting icon is in the center of the display.
Temperature and ice maker functions can be changed directly.
Temperature Setpoint Adjustment
Tap a temperature reading on the Home screen to access the
Temperature Setpoint Adjustment screen. The zone being
adjusted is shown.
Tap the + or - icon to adjust the temperature.
The freezer temperature range is -5°F to 5°F.
The refrigerator temperature range is 34°F to 42°F.
After adjustment, tap the temperature again or wait 10
seconds to return to the home screen.
Ice Maker Screen
The ice maker status is to the right of the feezer temperature
display. With the display unlocked, the ice maker function can
be changed. When the ice icon is gray, the ice maker is off.
Tap the ice icon to turn the ice maker on.
3
PRO36
service.subzero.com
