Manufactured for Rooms To Go
SOFA
TOOLS REQUIRED:NO NEED
NO
Description
Sofa Assembly
A
B
Wood Leg
Central
C
Support Leg
3778E-SF
3778E-LS
3778E-CH
3778E-OT
SOFA
CHAIR
LIST OF PARTS
Item
HNCL
SOFA
LOVESEAT
CHAIR
OTTOMAN
QTY
1
4
A
1
1
SKU#14137815,14137827
SKU#14237817,14237829
SKU#14337819,14337821
SKU#14437811,14437823
LOVESEAT
OTTOMAN
Legs are located inside of the zip porket
Advertisement
Table of Contents
Related Manuals for ROOMS TO GO HNCL 3778E-SF
Summary of Contents for ROOMS TO GO HNCL 3778E-SF
- Page 1 3778E-SF SOFA SKU#14137815,14137827 3778E-LS LOVESEAT SKU#14237817,14237829 3778E-CH CHAIR SKU#14337819,14337821 3778E-OT OTTOMAN SKU#14437811,14437823 Manufactured for Rooms To Go LOVESEAT SOFA OTTOMAN CHAIR LIST OF PARTS SOFA TOOLS REQUIRED:NO NEED Description Item Sofa Assembly Wood Leg Legs are located inside of the zip porket...
- Page 2 LIST OF PARTS LOVESEAT TOOLS REQUIRED:NO NEED Description Item Loveseat Assembly Legs are located inside of the zip porket Wood Leg CHAIR TOOLS REQUIRED:NO NEED Description Item Chair Assembly Wood Leg Legs are located inside of the zip porket LOVESEAT TOOLS REQUIRED:NO NEED Item Description...
- Page 3 ASSEMBLY INSTRUCTION 3778E-SF SOFA SKU#14137815,14137827 Turn the sofa on its back and place on a soft surface to prevent scratching the leather.Take off the legs B,C from the zip pocket at the bottom of sofa. Align wood leg B bolt to the pre-drilled hole at the corner and turn the leg clockwise until it is tightened. Intall 4 legs in same way.
- Page 4 ASSEMBLY INSTRUCTION 3778E-CH CHAIR SKU#14337819,14337821 Turn the chair on its back and place on a soft surface to prevent scratching the leather.Take off the legs B from the zip pocket at the bottom of chair. Align wood leg B bolt to the pre-drilled hole at the corner and turn the leg clockwise until it is tightened. Intall 4 legs in same way.
