Removing Processed Foods ..................17 CARE AND CLEANING ....................18 TIPS FOR GREAT RESULTS Using the Multipurpose Blade .................18 Using a Slicing or Shredding Disc................19 Using the Dough Blade ....................20 Helpful Hints......................20 TROUBLESHOOTING ....................22 For more information, visit our website at: KitchenAid.com.au...
FOOD PROCESSOR SAFETY IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed, including the following: 1. Read all instructions. Misuse of appliance may result in personal injury. 2. To protect against risk of electrical shock, do not put Food Processor in water or other liquid.
Page 4
8. The use of attachments not recommended or sold by KitchenAid may cause fire, electric shock, or injury. 9. Do not use outdoors. 10. Do not let cord hang over edge of table or counter.
FOOD PROCESSOR SAFETY Electrical Requirements- Plastic Models Volts: 220-240 Volts VAC Hertz: 50/60 Hz NOTE: This Food Processor is equipped with a polarized plug (one blade is wider than the other). To reduce the risk of electrical shock, this plug will fit in a polarized outlet only one way.
PARTS AND FEATURES Julienne Disc (select models only) Reversible (2 mm and 4 mm) Shredding Disc Externally Adjustable Slicing Disc Thin to Thick Chef’s Accessory Case Disc Slicing Drive Adapter Adapter Adapter 3-Piece Food Pusher Work Bowl Cover with 3-in-1 Feed Tube 945 ml (4-Cup) Mini-Bowl and...
Food Processor as well as optional accessories you can order separately (some optional accessories included with select models). Externally Adjustable Slicing Control 3-Piece Food Pusher KitchenAid brand’s exclusive externally Three pushers are nested inside of each adjustable slicing disc allows you to adjust other. Remove the medium pusher from the...
ACCESSORIES Disc Assembly Overview There are two different disc adapters included with the food processor. One is used exclusively with the adjustable slicing disc. The other is used with all other discs. Adjustable Reversible Slicing Disc Shredding Disc Slicing Adapter Disc Adapter Drive...
ACCESSORIES Accessories selection guide Not all accessories shown are included with all models. Action Setting Food Accessory Cheese Multipurpose Stainless Steel Blade Chocolate Fruit Chop Fresh herbs Nuts Tofu Mini-bowl and Mini Multipurpose Vegetables Puree Stainless Steel Blade Mince Pasta Sauce Pesto Salsa Sauces...
PREPARING THE FOOD PROCESSOR FOR FIRST USE 2. Lift out the mini-bowl. Before First Use Before using your Food Processor for the first time, wash the work bowl, work bowl cover, mini-bowl, feed tube pushers, discs, and blades either by hand or in the dishwasher (see “Cleaning the Food Processor”).
SETTING UP YOUR FOOD PROCESSOR Attaching the Work Bowl Attaching the Work Bowl Cover 1. Place the Food Processor on a dry, level countertop with the controls NOTE: Be sure to install the desired facing forward. Do not plug in the Food accessory before attaching the work Processor until it is completely assembled.
SETTING UP YOUR FOOD PROCESSOR Installing the Adjustable TIP: You may need to turn the disc/drive Slicing Disc adapter until it drops down into place. 4. Install the work bowl cover, being sure it IMPORTANT: The adjustable slicing disc locks into place. can only be installed in one direction.
SETTING UP YOUR FOOD PROCESSOR Installing Other Slicing or 3. With the work bowl installed, slide the drive adapter onto the power shaft. Shredding Discs TIP: You may need to turn the disc/drive IMPORTANT: The optional julienne and adapter until it drops down into place. plane/shave discs can only be installed in one direction.
SETTING UP YOUR FOOD PROCESSOR Installing the Multipurpose Installing the Mini-Bowl and Blade or Dough Blade Mini-Blade 1. Place the mini-bowl inside the work bowl IMPORTANT: The multipurpose blade over the power shaft. Rotate the mini- and dough blade can only be used with the bowl until the tabs on the top edge of the work bowl.
SETTING UP YOUR FOOD PROCESSOR Using the 3-in-1 Feed Tube The 3-in-1 feed tube features a 3-piece food pusher. Use the entire food pusher to process large items, or use the inner portions to create medium-sized or small feed tubes to process smaller items. To slice or shred small items, insert the 3-piece food pusher into the feed tube, then lift out the small pusher to remove.
USING YOUR FOOD PROCESSOR Using the Speed 1/Speed 2 Control 1. To turn on the Food Processor, press the Speed 1 or Speed 2 button. The Food Processor will run continuously and the indicator light will glow. 2. To stop the Food Processor, press the “O”...
USING YOUR FOOD PROCESSOR Removing Processed Foods 5. If using the mini-bowl, grasp and remove the bowl using the finger grips located along the top edge of the bowl. 1. Press the “O” (OFF) Button. 2. Unplug the Food Processor before disassembling.
CARE AND CLEANING 6. To prevent damage to the locking system, always store the work bowl and work bowl cover in the 1. Press the “O”(OFF) Button. unlocked 2. Unplug the Food Processor position before Cleaning. when not in use. 3.
TIPS FOR GREAT RESULTS To finely chop citrus peel: With sharp knife, peel colored portion (without white membrane) from citrus. Cut peel in small strips. Process until finely chopped. To mince garlic or to chop fresh herbs or small quantities of vegetables: With processor running, add food through the feed tube.
TIPS FOR GREAT RESULTS To slice or shred fruits and vegetables To cut julienne, or match that are small, such as strawberries, stick, strips of vegetables mushrooms, and radishes: and fruits using the julienne disc (on select models): Position food vertically or horizontally in layers within the feed tube.
Page 21
TIPS FOR GREAT RESULTS • To capitalize on the speed of the • A few larger pieces of food may remain on processor, drop ingredients to be top of the disc after slicing or shredding. chopped through the feed tube while If desired, cut these by hand and add to the processor is running.
TROUBLESHOOTING If your Food Processor should malfunction or fail to operate, check the following: Food Processor not shredding or slicing Food Processor doesn’t run: properly: • Make sure that the bowl and lid are properly aligned and locked in place and •...
Page 23
Índice AVISOS DE SEGURANÇA Instruções Importantes de Segurança ..............24 Condições Elétricas ....................26 ALIMENTOS E CARACTERÍSTICAS .................27 ACESSÓRIOS Acessórios Inclusos ....................28 Vista da Montagem dos Discos ................29 Guia para Seleção de Acessórios ................30 PREPARANDO O PROCESSADOR DE ALIMENTOS PARA USO Antes da Primeira Utilização ...................31 Retirando a Tampa da Tigela ...................31 Guardando as Peças ....................31 MONTANDO SEU PROCESSADOR DE ALIMENTOS...
AVISOS DE SEGURANÇA INSTRUÇÕES IMPORTANTES DE SEGURANÇA Quando utilizar eletroportáteis, precauções básicas de segurança sempre devem ser seguidas, incluindo as que seguem: 1. Leia todas as instruções. O uso incorreto pode resultar em acidentes. 2. Para evitar o risco de choque elétrico, não coloque o processador de alimentos dentro da água ou de outros líquidos.
Page 25
8. O uso de acessórios não recomendados ou não vendidos pela KitchenAid pode causar incêndio, choque elétrico ou ferimentos. 9. Não use em ambientes externos.
• Se o cabo de alimentação estiver Se não tiver, providencie a instalação danificado, ele deve ser substituído. de uma por um eletricista habilitado. Entre em contato com a Central de Relacionamento KitchenAid.
ALIMENTOS E CARACTERÍSTICAS Disco Juliana (Vendido separadamente) Disco reversível para picar (2 mm e 4 mm) Disco fatiador ajustável externamente (de fino para grosso) Estojo dos acessórios do chefe Adaptador Adaptador Adaptador de do disco acionamento fatiador Socador com 3 peças Tampa da tigela com bocal 3 em 1...
Os três socadores estão inseridos um dentro O disco fatiador rápido, ajustável do outro. Remova o socador médio do socador externamente, exclusivo da KitchenAid permite grande para revelar um bocal de tamanho ajustar a espessura da fatia, de fina para grossa, médio para processamento contínuo.
ACESSÓRIOS Vista da Montagem dos Discos Há dois adaptadores diferentes de disco inclusos no processador de alimentos. Um é usado exclusivamente com o disco fatiador ajustável. O outro é usado com os demais discos. Disco fatiador ajustável Disco reversível para Picar Adaptador Adaptador do fatiador...
ACESSÓRIOS Guia para Seleção de Acessórios Nem todos os acessórios mostrados estão inclusos em todos os modelos. Ação Ajuste Alimento Acessório Lâmina multiuso de aço inoxidável Queijo Chocolate Frutas Picar Ervas frescas Nozes Tofu Vegetais Mini-tigela e mini-lâmina multiuso Purê de aço inoxidável Moer Molho de massas...
PREPARANDO O PROCESSADOR DE ALIMENTOS PARA USO 2. Erga e tire a mini-tigela. Antes da Primeira Utilização Antes de utilizar o seu processador de alimentos pela primeira vez, lave a tigela, a tampa da tigela, a mini-tigela, os socadores do bocal, os discos e as lâminas, à mão ou na lavadora de louças (veja “Limpeza do Guardando as Peças Processador de Alimentos”).
MONTANDO SEU PROCESSADOR DE ALIMENTOS Montagem da Tigela Montagem da Tampa da Tigela NOTA: Certifique-se de instalar o 1. Coloque o processador de alimentos acessório desejado antes de colocar a sobre um balcão seco e nivelado, tampa na tigela. com os controles virados para frente. Não conecte na tomada até...
MONTANDO SEU PROCESSADOR DE ALIMENTOS Montagem do Disco Fatidor DICA: Talvez seja necessário girar o Ajustável disco/adaptador de acionamento até que caia na posição correta. IMPORTANTE: O disco fatiador ajustável somente pode ser instalado em uma 4. Coloque a tampa da tigela, certificando-se direção.
MONTANDO SEU PROCESSADOR DE ALIMENTOS Montando Outros Discos 3. Com a tigela montada, deslize o adaptador de acionamento sobre Fatiadores ou de Picar o eixo de acionamento. IMPORTANTE: O disco Juliana e o DICA: Talvez você necessite girar o disco de raspar/ralar somente podem ser disco/adaptador de acionamento até...
MONTANDO SEU PROCESSADOR DE ALIMENTOS Montando a Lâmina Multiuso Montagem da Mini-Tigela ou Lâmina para Massas e Mini-Lâmina 1. Coloque a mini-tigela dentro da tigela IMPORTANTE: A lâmina multiuso e a maior sobre o eixo de acionamento. lâmina para massas somente podem ser Gire a mini-tigela até...
MONTANDO SEU PROCESSADOR DE ALIMENTOS Usando o Bocal 3 em 1 O bocal 3 em 1 apresenta um socador de alimentos com 3 peças. Use o socador de alimentos inteiro para processar itens grandes, ou use as partes internas para criar bocais de tamanho médio ou pequeno para processar itens menores.
USANDO SEU PROCESSADOR DE ALIMENTOS Usando o Controle Velocidade 1/ Velocidade 2 1. Para ligar o processador de alimentos, pressione o botão Velocidade 1 e Velocidade 2. O processador de alimentos funcionará continuamente e a luz indicadora ficará acesa. 2. Para parar o processador de alimentos, pressione o botão “O”.
USANDO SEU PROCESSADOR DE ALIMENTOS Removendo Alimentos 5. Se estiver usando a mini-tigela, segure e remova a tigela usando as garras para Processados os dedos, localizadas na borda superior da tigela. 1. Pressione o botão “O”. 2. Desconecte o processador de alimentos da tomada antes de desmontá-lo.
CUIDADOS COM O PROCESSADOR DE ALIMENTOS 6. Para prevenir danos ao sistema de travamento, sempre armazene a tigela e sua tampa na posição destravada quando não estiver em uso. 1. Pressione o botão “O”. 2. Desconecte o processador de alimentos da tomada antes de fazer a limpeza.
DICAS PARA BONS RESULTADOS Para picar nozes ou fazer pasta de nozes: Processe até 3 xícaras (710 ml) de nozes até obter a textura desejada, usando pulsos curtos, 1 a 2 segundos por vez. Para uma textura mais grossa, processe pequenas quantidades, pulsando 1 ou 2 vezes, de 1 a 2 segundos por vez.
DICAS PARA BONS RESULTADOS Para fatiar ou picar frutas ou vegetais que são pequenos como morango, cogumelo e rabanete: Coloque os alimentos na vertical ou horizontal, em camadas, dentro do bocal. Encha o bocal para manter os alimentos corretamente posicionados. Processe usando pressão uniforme.
DICAS PARA BONS RESULTADOS Dicas Importantes Para cortar vegetais e frutas à Juliana ou palito, use o • Para evitar danos à lâmina ou ao motor, disco opcional para Juliana não processe alimentos muito duros ou (não incluído): Corte os firmemente congelados que não possam alimentos de forma que caibam ser perfurados com a ponta de uma faca...
Page 43
DICAS PARA BONS RESULTADOS • Queijos macios e médios podem se • Alguns pedaços maiores de alimento espalhar ou acumular no disco de picar. podem permanecer na parte superior Para evitar isto, pique somente queijos do disco depois de fatiar ou picar. bem gelados.
SOLUÇÕES DE PROBLEMAS Se o seu processador de alimentos não funcionar, verifique o seguinte: O processador de alimentos não está O processador de alimentos picando ou fatiando adequadamente: não funciona: • Certifique-se de que a tigela e a tampa • Verifique se o lado em relevo da lâmina estejam adequadamente alinhadas e do disco está...
QUESTÕES AMBIENTAIS 1. Embalagem 2. Produto A KitchenAid procura, em seus novos Este produto foi construído com projetos, usar embalagens cujas partes materiais que podem ser reciclados e/ sejam de fácil separação, bem como de ou reutilizados. Então, ao se desfazer materiais recicláveis.
