- Page 1 Clean Water Made Easy www.cleanwaterstore.com 7500-REV2.5 Air Charger Sulfur Air Filter Installation Guide Rev-122822...
- Page 2 Thank you for purchasing a Clean Water System! With proper installation and a little routine maintenance your system will be providing chlorine free water for many years. Please review this start up guide entirely before beginning to install your system, and follow the steps outlined for best results.
-
Page 3: Table Of Contents
Diagram of Typical Installation Tank Assembly and Installation Instructions Programming Your Valve Set Time of Day Set Date Start the First Backwash Advanced Programming Mode Advanced Program Default Settings Maintenance Troubleshooting the 7500-REV2.5 Sulfur AIR Backwash Filter 7500-REV2.5 Water Filters Limited Warranty Rev-122822... -
Page 4: Packing Lists
7500-REV2.5 Sulfur Air Filter Installation & Startup Guide Packing Lists All systems include: 7500-REV2.5 control valve, bypass valve, power supply, funnel for adding media, top screen, start-up guide, and items included in one of the following options: Find Your Size System to See What is Included: Sulfur Air Filter 1.0 cubic foot size... -
Page 5: Pre-Installation
7500-REV2.5 Sulfur Air Filter Installation & Startup Guide Pre-Installation 1. Review your packing list and make sure you have received all the parts before installation. 2. If you are going to be turning off the water to the house and you have an electric water heater, shut off the power to the water heater before beginning installation in case water heater is accidentally drained. -
Page 6: How The Bypass Valve Works
7500-REV2.5 Sulfur Air Filter Installation & Startup Guide How the Bypass Valve Works Turn knob so the valve is bypassed when installing. When you go to start up system turn the bypass SLOWLY to let water in and put in service. -
Page 7: How Your Sulfur Air Filter Works
7500-REV2.5 Sulfur Air Filter Installation & Startup Guide How Your Sulfur Air Filter Works The 7500-REV2.5 control valve maintains a compressed “air pocket” in the top of the tank while the system is in service. As the water passes through the air pocket, the sulfur is oxidized and dissolved oxygen is added to the water. -
Page 8: Tank Assembly And Installation Instructions
7500-REV2.5 Sulfur Air Filter Installation & Startup Guide Tank Assembly and Installation Instructions 1. Wrap the top of distributor tube with electrical or duct tape so that no gravel or Carbon media will go down the distributor tube when adding the media. - Page 9 7500-REV2.5 Sulfur Air Filter Installation & Startup Guide 9. Lubricate the main tank O-ring with silicone grease and screw on the 7500-REV2.5 control valve carefully. Do not use pipe-joint compound, vegetable oil, Teflon tape, or Vaseline or other greases to lubricate tank threads.
-
Page 10: Programming Your Valve
7500-REV2.5 Sulfur Air Filter Installation & Startup Guide Programming Your Valve How to Start a Manual Backwash: Press the Back / Regen button Pressing “Back Regen” at any time results in an immediate manual regeneration. Pressing and holding for 3 seconds, when system is locked, results in a delayed regeneration at the preselected time. -
Page 11: Set Time Of Day
7500-REV2.5 Sulfur Air Filter Installation & Startup Guide Set Time of Day 1. If LOCK icon is lit, press, and hold both UP and DOWN buttons for 3 seconds to unlock keypad. 2. Then press the MENU/CONFIRM button to enter the main menu. -
Page 12: Start The First Backwash
7500-REV2.5 Sulfur Air Filter Installation & Startup Guide Set Regen Time This is the time your system will backwash. Default is 2:00 AM Set Backwash Time Set for 10 minutes. Set Air Draw Time Set for 10 minutes. Set Fast Rinse Time Set for 8 minutes. -
Page 13: Advanced Programming Mode
7500-REV2.5 Sulfur Air Filter Installation & Startup Guide Advanced Programming Mode Skip this for most applications as your filter system has already been set to correct modes. 1. Plug the RevV4 in and immediately press in sequence MENU/CONFIRM, then press BACK/ REGEN button, then press the DOWN button to enter the Advanced Programming Mode. -
Page 14: Advanced Program Default Settings
7500-REV2.5 Sulfur Air Filter Installation & Startup Guide Advanced Program Default Settings Screen View Default Settings Review Company Info CWS 831-462-8500 Set Valve Model 62605 Set Language English Set Company Info CWS 831-462-8500 Set Hour Mode 12 HR Set Time of Day... -
Page 15: Maintenance
7500-REV2.5 Sulfur Air Filter Installation & Startup Guide Maintenance Every 4 to 6 years or if odor returns remove control valve and empty out the catalytic carbon filter media and KDF cubes and replace with new media. Once a year clean the nozzle and throat on the injector. Turn off water pressure to your system and release any pressure by opening up a hose bib or faucet downstream of the filter system. - Page 16 7500-REV2.5 Sulfur Air Filter Installation & Startup Guide Rev-122822 www.cleanwaterstore.com...
- Page 17 7500-REV2.5 Sulfur Air Filter Installation & Startup Guide Exploded Parts View Rev-122822 www.cleanwaterstore.com...
- Page 18 7500-REV2.5 Sulfur Air Filter Installation & Startup Guide Rev-122822 www.cleanwaterstore.com...
-
Page 19: Troubleshooting The 7500-Rev2.5 Sulfur Air Backwash Filter
Carbon Backwash Filter. You can verify the backwash flow rate by running the drain line into a bucket and timing it when the 7500-REV2.5 is in Cycle 1 or backwash. What to Do If Odor Returns If your systems worked at first but then the odor came back, check the following: Check odor at the hose bib directly after the filter system, which is before your household piping. -
Page 20: 7500-Rev2.5 Water Filters Limited Warranty
9. Any product returned to Clean Water Store without a valid return authorization number will be rejected. Any product found to be defective will, at the sole discretion of Clean Water Store be repaired or replaced. Clean Water Store is not responsible for shipping cost to the repair facility.
