- Page 1 Clean Water Made Easy www.cleanwaterstore.com 7500-REV4 Arsenic Filter Installation Guide Rev-011823...
- Page 2 Thank you for purchasing a Clean Water System! Please review this start-up guide entirely before beginning to install your system, and follow the steps outlined for best results. Minimum pressure of 30 PSI recommended. Maximum pressure recommended 80 PSI. For indoor installation only.
-
Page 3: Table Of Contents
Table of Contents Packing Lists Pre-Installation Best Practices for Piping & Drain Installation How the Bypass Valve Works Installation of Your System in Copper or Metal Piping Systems How Your Carbon Filter Works Diagram of Typical Installation Well Water Tank Assembly and Installation Instructions Programming Your Valve and Setting Time and Days for Backwash Set Time of Day Set Date... -
Page 4: Packing Lists
Packing Lists All systems include: 7500-REV4 control valve, bypass valve, small tube of silicone grease, power supply, funnel for adding media, top screen, start-up guide, and items included in one of the following options: Find Your Size System to See What is Included: Arsenic Filter 1.0 cubic foot size... -
Page 5: Pre-Installation
4. If you will be using copper piping, do not sweat the copper pipe directly on to the 7500-REV4 control valve. 5. To connect drain line to drain, use an air-gap connection, so that if your sewer or septic tank backs up, it cannot cross connect with the drain tubing. -
Page 6: How The Bypass Valve Works
7500-REV4 Arsenic Filter Installation Guide How the Bypass Valve Works Turn knob so the valve is bypassed when installing. When you go to start up system turn the bypass SLOWLY to let water in and put in service. Installation of Your System in Copper or Metal Piping Systems If your new filter system is to be installed in a metal (conductive) plumbing system, i.e.,... -
Page 7: How Your Carbon Filter Works
Metsorb arsenic media does not need frequent backwashing and once a month is sufficient. The 7500-Rev4 Control Valve is set to Filter Meter Type which means it counts or tracks the amount of water that is used and will backwash every 6000 gallons OR 30 days, whichever comes first. -
Page 8: Tank Assembly And Installation Instructions
8. Lubricate the main tank O-ring with silicone grease and screw on the 7500-Rev4 control valve carefully. Do not use pipe-joint compound, vegetable oil, Teflon tape, or Vaseline or other greases to lubricate tank threads. - Page 9 7500-REV4 Arsenic Filter Installation Guide 13. If you are in earthquake zone, strap your backwash filter tank to wall with metal strapping 14. Proceed to programming your 7500-Rev4 control valve timer and backwash frequency. IMPORTANT: you must program the time and then start a backwash and rinse.
-
Page 10: Programming Your Valve And Setting Time And Days For Backwash
7500-REV4 Arsenic Filter Installation Guide Programming Your Valve and Setting Time and Days for Backwash How to Start a Manual Backwash: Press the Back / Regen button Pressing “Back Regen” at any time results in an immediate manual regeneration. Pressing and holding for 3 seconds, when system is locked, results in a delayed regeneration at the preselected time. -
Page 11: Set Time Of Day
7500-REV4 Arsenic Filter Installation Guide Set Time of Day 1. If LOCK icon is lit, press, and hold both UP and DOWN buttons for 3 seconds to unlock keypad. 2. Then press the MENU/CONFIRM button to enter the main menu. -
Page 12: Set Capacity
7500-REV4 Arsenic Filter Installation Guide Set Capacity This refers to the number of gallons your 7500-Rev4 is set to backwash. Default is 6000 Gallons. This means that your filter will backwash every 6000 gallons of water used, OR every 30 days, whichever comes first, since your Maximum Days for Regen. -
Page 13: Advanced Programming Mode
7500-REV4 Arsenic Filter Installation Guide 6. If possible, verify that the backwash flow corresponds with the size of your system below. You can easily run the drain hose to a bucket and using a watch verify the flow rate in gallons per minute. -
Page 14: Advanced Program Recommended Settings
7500-REV4 Arsenic Filter Installation Guide Advanced Program Recommended Settings Review Company Info CWS 831-462-8500 Set Valve Model 62605 Set Language English Set Company Info CWS 831-462-8500 Set Hour Mode 12 HR Set Time of Day Current time of day Set Date... -
Page 15: Maintenance
7500-REV4 Arsenic Filter Installation Guide Maintenance Every 4 to 6 years (in some cases it can last longer) remove control valve and empty the Arsenic filter media and replace with new media. There is no routine maintenance required for the control valve or filter media, other than making sure the system is set to backwash frequently enough to keep the filter media clean. -
Page 16: 7500-Rev2.5 Water Filters Limited Warranty
9. Any product returned to Clean Water Store without a valid return authorization number will be rejected. Any product found to be defective will, at the sole discretion of Clean Water Store be repaired or replaced. Clean Water Store is not responsible for shipping cost to the repair facility.
