- Page 1 Clean Water Made Easy www.cleanwaterstore.com Air Charger Sulfur Filter 5900BT-AIR Installation & Maintenance Guide Rev-010423...
- Page 2 Thank you for purchasing a Clean Water System! With proper installation and a little routine maintenance your system will be providing odor-free water for many years. Please review this start-up guide entirely before beginning to install your system and follow the steps outlined for best results.
- Page 3 Table of Contents Packing Lists Pre-Installation Best Practices for Piping & Drain Installation How the Bypass Valve Works Installation of Your System in Copper or Metal Piping Systems How Your Sulfur Air Filter Works Diagram of Typical Installation Tank Assembly and Installation Instructions Programming Your Valve Set Time of Day Set Date...
- Page 4 Packing Lists 1.0 Cubic Foot Size System Air Charger Sulfur Filter 5900BT-AIR control valve w/ bypass assembly and 1” pipe connector kit 9” x 48” standard filter tank with distributor tube Media funnel for adding Air Charger Sulfur Filter media 1.0 cubic feet of Catalytic Carbon media...
- Page 5 Air Sulfur Filter 5900BT-AIR Installation & Maintenance Guide How Your Air Charger Sulfur Filter 5900BT-AIR Works The Air Charger Sulfur Filter 5900BT-AIR, when properly applied, is an efficient and cost effective system for the removal of sulfur odors. The Air Charger Sulfur Filter 5900BT-AIR control valve maintains a compressed “air pocket”...
- Page 6 2. Fill tank with clean water. Allow to soak for at least 1 hour, but up to 24 hours is OK. 3. Make the plumbing connections from your existing system to the bypass assembly, installing extra valves, unions, pressure gauges and hose bibs as needed.
- Page 7 Air Sulfur Filter 5900BT-AIR Installation & Maintenance Guide Best Practices for Piping & Drain Installation 1. See typical installation (Fig 2). The Air Charger Sulfur filter is installed after pressure tank. 2. Install on a level floor or surface. 3. Filter system must be installed at least 10 feet ahead of inlet to water heater to prevent damage due to back-up hot water or use a check valve to prevent hot water back-up.
- Page 8 Air Sulfur Filter 5900BT-AIR Installation & Maintenance Guide Diagram of Typical Installation Well Water Diagram of Typical Installation City Water Rev-010423 www.cleanwaterstore.com...
- Page 9 Air Sulfur Filter 5900BT-AIR Installation & Maintenance Guide Installation of Your System into Copper or Metal Piping Systems If your new filter system is to be installed in a metal (conductive) plumbing system, i.e. copper or galvanized steel pipe, the plastic components (bypass and connectors) will interrupt the electrical continuity of the plumbing system.
- Page 10 Air Sulfur Filter 5900BT-AIR Installation & Maintenance Guide 6. Add the filter gravel that came with your order. The gravel should cover the bottom distributor screen before adding the carbon filter media. 7. Next, add the filter media. 8. The tank should be about 2/3 full of media, do not fill much more than 2/3 full, even if there is media left over.
- Page 11 Air Sulfur Filter 5900BT-AIR Installation & Maintenance Guide Attach the Bypass Make sure there is lubricant on all three sets of O-rings and insert and screw bypass onto end connectors (O-rings are already on valve, with the Inlet Air Check Valve on the left, Inlet side).
- Page 12 Air Sulfur Filter 5900BT-AIR Installation & Maintenance Guide Install 9V Battery (not included) DO NOT INSTALL BATTERY UNTIL AFTER INITIAL BACKWASH! Connect 9V battery to battery cable under control panel. Battery cable and battery will sit under control panel. Control panel can be easily removed to access battery cable if needed, no tools are required.
- Page 13 Air Sulfur Filter 5900BT-AIR Installation & Maintenance Guide 5. You do not need unions to install your 5900-BT control valve. If you need to remove it, the 5900-BT control valve has quick-release couplings that make easy to put the 5900-BT on by-pass and remove the filter system from the piping.
- Page 14 8. Once A.M./P.M. is accepted the next menu item will flash 9. To Set Regeneration Frequency Press the Set/Change Button 10. The recommended initial setting for a Sulfur 5900BT-AIR filter is every 3 to 4 days 11. To Set the Number of Days between Air-Draw Cycles, Press the Set/Change Button 12.
- Page 15 Air Sulfur Filter 5900BT-AIR Installation & Maintenance Guide Each display is used to set the duration time in minutes for that specific step in a regeneration cycle. A step # will turn on for the regeneration cycle step being programmed. Regeneration steps are skipped by setting the display to 0 as shown below: For initial start-up, Set the chem draw “J”...
- Page 16 Air Sulfur Filter 5900BT-AIR Installation & Maintenance Guide Detailed Steps to Starting Up Sulfur Air Filter System 1. New activated carbon filter media has a lot of black carbon fines or dust, and must be rinsed free by backwashing and rinse, which may take several backwashes.
- Page 17 Air Sulfur Filter 5900BT-AIR Installation & Maintenance Guide 15. Next, open the outlet on the bypass valve and then open the hose bib after the system and allow the water to run until it is clear. Run water in the home using a bathtub, laundry sink, or other fixture that does not have an aerator screen as any remaining residue may get caught in the screen.
