  • Page 1 Clean Water Made Easy www.cleanwaterstore.com 7500-REV4 Up-Flow Water Softener Installation Guide Rev-032423...
  • Page 2 7500-Rev4 Water Softener Installation & Startup Guide Thank you for purchasing a Clean Water System! Please review this start-up guide entirely before beginning to install your system, and follow the steps outlined for best results. Minimum pressure of 30 PSI recommended.
  • Page 3: Table Of Contents

    7500-Rev4 Water Softener Installation & Startup Guide Table of Contents Packing List Pre-Installation Best Practices for Piping & Drain Installation How the Bypass Valve Works Installation of Your System in Copper or Metal Piping Systems How Your Water Softener Works...
  • Page 4: Packing List

    7500-Rev4 Water Softener Installation & Startup Guide Packing List 7500-REV4 Upflow Softener control valve, small tube of silicone grease, bypass valve, 1” pipe connectors, power supply, funnel for adding softener resin, top screen, start-up guide, brine tank, and items included in one of the following options: Find Your Size System to See What is Included: Water Softener 32K 1.0 cubic foot size...
  • Page 5: Pre-Installation

    7500-Rev4 Water Softener Installation & Startup Guide Pre-Installation 1. Review your packing list and make sure you have received all the parts before installation. 2. If you are going to be turning off the water to the house and you have an electric water heater, shut off the power to the water heater before beginning installation in case water heater is accidentally drained.
  • Page 6: How The Bypass Valve Works

    7500-Rev4 Water Softener Installation & Startup Guide How the Bypass Valve Works Turn knob so the valve is bypassed when installing. When you go to start up system turn the bypass SLOWLY to let water in and put in service.
  • Page 7: How Your Water Softener Works

    This entire automatic process, called ‘regeneration’ takes about 90 minutes. The 7500-Rev4 Control Valve tracks the amount of water that is used and will backwash based on gallons OR every 7 days, whichever comes first.
  • Page 8: Softener Tank Assembly And Installation Instructions

    8. Lubricate the main tank O-ring with silicone grease and screw on the 7500-Rev4 control valve carefully. Do not use pipe-joint compound, vegetable oil, Teflon tape, or Vaseline or other greases to lubricate tank threads.
  • Page 9 7500-Rev4 Water Softener Installation & Startup Guide 12. Connect the black 3/8” brine tubing to the brine tank. 13. If you are in earthquake zone, strap your backwash filter tank to wall with metal strapping. 14. Proceed to programming your 7500-Rev4 control valve timer and backwash frequency.
  • Page 10 7500-Rev4 Water Softener Installation & Startup Guide Programming Your Valve and Setting Time and Days for Backwash How to Start a Manual Backwash: Press the Back / Regen button Pressing “Back Regen” at any time results in an immediate manual regeneration.
  • Page 11: Set Date

    7500-Rev4 Water Softener Installation & Startup Guide Set Time of Day 1. If LOCK icon is lit, press, and hold both UP and DOWN buttons for 3 seconds to unlock keypad. 2. Then press the MENU/CONFIRM button to enter the main menu.
  • Page 12: Start The First Regeneration Before Using

    7500-Rev4 Water Softener Installation & Startup Guide Set Total Capacity This is the total capacity of your softener (32K etc) Total Capacity Set Water Hardness This is your water hardness in grains per gallon. 1.0 CF Set Number of People Number of persons in your home.
  • Page 13 7500-Rev4 Water Softener Installation & Startup Guide Advanced Programming Screen View Default Settings Mode View Company Info CWS 831-462-8500 Set Valve Model 62605 The Advanced Programming Mode allows you to set the Regen Cycle and Regen Mode. Set Language English...
  • Page 14: 7500-Rev4 Water Conditioners Limited Warranty

    9. Any product returned to Clean Water Store without a valid return authorization number will be rejected. Any product found to be defective will, at the sole discretion of Clean Water Store be repaired or replaced. Clean Water Store is not responsible for shipping cost to the repair facility.
