Sigma Controls MYRIAD DPC Instruction Manual page 31

MYRIAD DPC RS485 MODBUS CONNECTIONS
NOTE: MYRIAD MUST BE ORDERED WITH RJ45 MODBUS CONNECTOR
ADDRESS DESCRIPTION
40001 PROCESS [MAIN DISPLAY]
40002 SPEED OUTPUT
40003 HMI BAR
40004 ALARM CODE
40005 MILLIAMP OUTPUT 1
40006 MILLIAMP OUTPUT 2
40007 MILLIAMP OUTPUT 3
40008 MILLIAMP OUTPUT 4
40009 MILLIAMP INPUT 1
40010 MILLIAMP INPUT 2
40011 MILLIAMP INPUT 3
40012 MILLIAMP INPUT 4
40013 N/A
40014 N/A
40015 N/A
40016 N/A
40017 HIGH ALARM SETPOINT
40018 HIGH ALARM RE-SETPOINT
40019 LOW ALARM SETPOINT
40020 LOW ALARM RE-SETPOINT
40021 LEAD ON SETPOINT
40022 LEAD OFF SETPOINT
40023 LAG ON SETPOINT
40024 LAG OFF SETPOINT
40025 MIN SPEED OUTPUT
40026 MAX SPEED OUTPUT
40027 MIN SPEED AT PROCESS
VALUE
40028 MAX SPEED AT PROCESS
VALUE
40029 ALTERNATON MODE
APPENDIX 'D'
06/06/17
VARIABLES
RANGE
0-999
0-1000
0-31
0-8
0-2000
0-2000
0-2000
0-2000
0-2000
0-2000
0-2000
0-2000
0-999
0-999
0-999
0-999
0-999
0-999
0-999
0-999
0-1000
0-1000
0-999
0-999
0-2
DISPLAY AS
XXX - XX.X - X.XX - .XXX
XXX.X%
COARSE BAR GRAPH
SEE ALARM CODE
XX.XX ma
XX.XX ma
XX.XX ma
XX.XX ma
XX.XX ma
XX.XX ma
XX.XX ma
XX.XX ma
XXX - XX.X - X.XX - .XXX
XXX - XX.X - X.XX - .XXX
XXX - XX.X - X.XX - .XXX
XXX - XX.X - X.XX - .XXX
XXX - XX.X - X.XX - .XXX
XXX - XX.X - X.XX - .XXX
XXX - XX.X - X.XX - .XXX
XXX - XX.X - X.XX - .XXX
XXX.X%
XXX.X%
XXX - XX.X - X.XX - .XXX
XXX - XX.X - X.XX - .XXX
0=OFF, 1=PUMPS OFF, 2-TIMED
31
READ ONLY
READ ONLY
READ ONLY
READ ONLY
READ ONLY
READ ONLY
READ ONLY
READ ONLY
READ ONLY
READ ONLY
READ ONLY
READ ONLY
READ ONLY
READ ONLY
READ ONLY
READ ONLY
READ ONLY
READ WRITE
READ WRITE
READ WRITE
READ WRITE
READ WRITE
READ WRITE
READ WRITE
READ WRITE
READ WRITE
READ WRITE
READ WRITE
READ WRITE
READ WRITE
