- Page 1 USER MANUAL ITV101P English Español Email service@rainpointus.com WhatsApp +1 626-780-5952 Free Hotline US: +1833-381-5659 (EN) EU: +44 800-808-5337 (EN DE) Save the user manual for future reference If you have any questions, please contact us to get support...
- Page 2 WARM TIPS PLEASE READ BEFORE USING Don’t use the water timer when the temperature is below 37℉(3℃), and please store the timer indoors to avoid potential freezing damage. The filter traps dirt particles, preventing them from entering the timer and causing clogging. Please clean the filter regularly and replace it if worn.
-
Page 3: Product Overview
PRODUCT OVERVIEW At A GLANCE FILTER HOSE TAP CONNECTION BIG LCD SCREEN OK/MANUAL BUTTON DIAL OUTLET +/DELAY BUTTON BUTTON FUNCTION DIAL Rotate the dial to set your watering schedule. OK /MANUAL Use "OK" to confirm the time. When the dial is BUTTON turned to "ON", press and hold "MANUAL"... - Page 4 SPECIFICATION Min/Max Operating 0.5bar-8bar (7.25 psi-116 psi) Pressure Max Flow Rate 10 Gal/Min (35L/Min) Working Temperature 37.4℉-122.4℉( 3℃-50℃ ) Waterproof IP54 Power By 2 AA (1.5V) alkaline batteries (not included) Thread NH(US) for 3/4" faucet / hose BSP(EU) for 3/4" or 1" faucet / hose Watering Times 1 to 3 times a day Per Day...
- Page 5 LCD ICON FUNCTION Low battery indicator Flashing during watering The selected day of the week Every _ Days Interval watering days Next The time left to the next watering Start Time The start time of watering P1/P2/P3 Watering plans for one day DIAL POSITION FUNCTION SET CLOCK Set your local current time...
-
Page 6: Product Installation
PRODUCT INSTALLATION INSTALLING THE BATTERIES 1. Remove the battery tray on the back of the timer. 2. Insert 2 new AA (1.5V) alkaline batteries (not included). 3. Put the battery tray back on the timer and press firmly to make sure it is completely sealed. Note: 1. -
Page 7: Installing The Timer
INSTALLING THE TIMER 1) Turn off the garden faucet. 2) Wrap Teflon Tape around the faucet threads. 3) Screw the timer to the garden faucet and make the display as vertical as Inlet possible to the ground to prevent rainwater from accumulating and leaking into the interior. - Page 8 If yes, the timer valve is normal, please use it with confidence! If not, please repeat the above steps several times or contact RAINPOINT support team immediately. Note: When testing, please keep away from the water timer outlet to avoid being splashed and wet.
-
Page 9: Set Clock
PROGRAMMING YOUR TIMER STEP 1: SET CLOCK 1. Turn dial to "SET CLOCK". 2. " " flashing: Use the "+" button to select the day of the week, then press "OK" to confirm. 3. " " flashing: Use the "+" button to set hour and press "OK" to confirm.Press and hold the "OK"... -
Page 10: Start Time
STEP 2: START TIME 1. Turn dial to "START TIME". 2. Use the "+" button to set the start time and press the "OK" button to confirm.(If you choose 12-hour mode, please note AM and PM) 3. After confirming this plan, press the "OK" button again to switch to the next plan. - Page 11 STEP 3: HOW LONG 1. Turn dial to "HOW LONG". ( will display on the screen.) 2. Use the "+" button to set the watering duration and press the "OK" button to confirm.(The watering duration is from 1 minute to 3 hours 59 minutes) 3.
-
Page 12: How Often
STEP 4: HOW OFTEN 1. Turn the dial to "HOW OFTEN". 2. There are 2 setting modes for watering frequency. a. Day of the Week Mode (Watering plans will run every Sunday, Wednesday, Thursday, and Friday) b. Every 2/3/4/5/6 Days Mode (Watering plans will run every 2 days) Examples of watering frequency of every 2 day, every 3 days and every 5 days：... - Page 13 3. Set the Day of the Week Mode a. Use the "+" button to select the day of the week, press "OK" to confirm. means the "Sunday" has been selected. Press "OK" again can cancel the selection. c. Turn the dial clockwise to save the changes in this STEP and go to next STEP.
- Page 14 STEP 5: VIEW SET 1. Turn the dial to "VIEW SET". 2. Press "OK" button to check the START TIME, HOW LONG and HOW OFTEN settings of the 3 watering plans. (The start time of P1) (The watering duration of P1) (Watering frequency) STEP 6: ATUO WATERING...
- Page 15 3) When not watering: a. If there is no watering plans being set, it will only display the current day and time. b. If there are plans being set but not running yet, it will display the current day and time, and followed by how much time is left to the next watering plan.
-
Page 16: Additional Features
ADDITIONAL FEATURES MANUAL / HAND WATERING This feature allows you to water without interrupting your set watering schedule. Please follow the steps below to start manual watering. 1. Turn the dial to "ON". 2. Press and hold the "MANUAL" button for 3-5s to enter the Manual Watering Mode. -
Page 17: Product Features
PRODUCT FEATURES RAIN DELAY WATERING Rain delay time Current time Rain delay allows you to postpone watering for a set period of time, and it will not interrupt your original schedule. To access the rain delay, follow the steps below. 1. -
Page 18: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Possible Solution The water inlet 1. No filter or not be 1. Add a filter and make leakage placed horizontally sure it's placed 2. The faucet is not horizontally in the inlet. the standard 3/4" 2. Make sure the faucet is a standard 3/4"... - Page 19 PROBLEM Possible Cause Possible Solution 1. Filter blockage Low water 1. Check if the filter is 2. Inlet pressure not clogged, if so, clean pressure sufficient to or replace the filter. support 2. Make sure the timer is watering needs installed properly and not cross-threaded.
- Page 20 CLEANING YOUR TIMER After a period of use, impurities or dirt in the water may accumulate in the timer. Therefore, the timer should be cleaned regularly to ensure its proper operation. Please follow these steps to clean the timer. 1. Turn off the garden faucet and remove the timer. Check whether the filter at the timer water inlet has accumulated impurities.
- Page 21 WARNINGS 1) For outdoor use only. Placing the timer in the sheltered outdoors will prolong its lifetime. 2) To avoid damage, please tighten it without using tools. 3) The filter should be placed horizontally in the water inlet to prevent leakage.
-
Page 22: Warranty
To place a warranty request, please email us with your order ID at service@rainpointus.com and we'll respond within 24 hours. CUSTOMER SERVICE Still have trouble with setup, please search for "RainPoint" on YouTube for installation videos! If the user manual doesn't have what you're looking for or you need other help, please contact us before returning the product to the store and let us know the LOT NO. - Page 23 Scan the QR code to get fast support Need Help? Please contact us US Free Hotline: +1 833-381-5659 (MON-FRI: 09:30 AM-5:30 PM PST) EU Free Hotline: +44 800-808-5337 (MON-FRI: 09:00 AM-5:00 PM CET) Email: service@rainpointus.com WhatsApp: +1 626-780-5952...
