ChipEncoder Series
Installation Manual and Reference Guide
7.0

Appendix

7.1

Specifications

System
Scales
ChipEncoders are compatible with ChipEncoder Linear and
Rotary Glass scales.
Scale Pitch 40 µm
System Resolution
CE300-4
Linear Resolution:
Rotary Resolution:
Interpolation Depth:
Accuracy
Linear Glass: ±5 µm/m
±2 arc-seconds
Rotary Glass:
Sensor Size and Weight
Dimensions (mm)
CE300:
CE:
Weight
CE300: 0.37 g
CE: 0.25 g
1:
Note Excludes eccentricity
Output Signals
IM-ChipEncoder-Series-Rev. 2
CE300-40
10 µm 1 µm
See Sec. 7.3 Linear and Glass Scales
X4 X40
1
Width Length
7.0 11.0
6.1 6.1
Operating and Electrical Specifications
Power Supply:
Current Draw:
Temperature
CE-40GC
1 µm Max Lead-Free
Reflow
Temperature
Humidity
X40
Vibration
Shock
Reliability (MTTF)
Outputs
Signals: CMOS/TTL
Format: Digital – differential quadrature
Height
Output impedance per channel = 60 ohms
3.1
3.9
Page 18
5 V ±0.5 V
DC DC
30 mA, unterminated outputs
Operating: 0°C to 70°C
Storage: -20°C to 85°C (CE300)
-20°C to 100°C (CE)
260°C for<5 seconds
Operating: 10% to 90% RH, non-condensing
30 G @ 20 Hz; EN60068-2-6
300 G (0.40, half sine) CE300
100 G (11 ms, half sine) CE
100,000 Hours
©2022 Celera Motion
Appendix
