The Yealink T57W features a large color touch
screen. There are six on-screen soft keys on
each side of the screen, and four color-coded
icons along the bottom of the screen.
The keys along the side of the screen are
programmable, and change depending on
the configuration of your phone. If the soft
key has not been programmed, it will be
blank. The bottom right "more" soft key
displays 18 additional soft keys in the center
part of the screen.
The four icons along the bottom of the screen
are labeled History, Directory, DND, and Menu.
There are 8 keys on the lower section of the
phone, surrounding the numeric dial pad.
The
key adjusts the volume.
Pressing this key when you are not engaged
in a call adjusts the ringer volume. Pressing
them while you are in a call adjusts the
volume of the handset, speaker, or headset.
LET'S DISCUSS YOUR NEEDS
Yealink T57W
Quick Guide
LSNETWORKS.NET • SALES@LSNETWORKS.NET • 503.294.5300
Line Keys
The larger rectangular
built-in speakerphone. Is the speakerphone
key. Press this key to make or answer a call
using the speakerphone.
The other keys are as follows:
Activates a headset (if connected)
Mutes the microphone
Listen to your voice messages
Place a call on hold
Redial the last call
Transfer a call
Touchscreen
Soft Keys
key the
24/7/365 NOC SUPPORT
Advertisement
Related Manuals for Yealink T57W
Summary of Contents for Yealink T57W
- Page 1 Yealink T57W Quick Guide The Yealink T57W features a large color touch Line Keys screen. There are six on-screen soft keys on Touchscreen each side of the screen, and four color-coded icons along the bottom of the screen. The keys along the side of the screen are programmable, and change depending on the configuration of your phone.
- Page 2 Placing a Call Semi-Attended Transfer sends a call while the destination phone is ringing. Using the Headset Attended Transfer allows you to speak with the destination phone before Pick up the handset. transferring the call. Note that you may Enter the number on the dial pad. use the key or the transfer soft key to transfer calls.
- Page 3 Conference Calling Muting a Call You can conduct conference calls with up to To mute the call, press the key. three parties, including yourself. The button will turn red and the screen will indicate that the microphone is muted. Press the Conference soft key during an Press again to resume the call.
