Torque Specifications for Non-Critical Fasteners (Cont.)
PROPERTY CLASS 8.8 (Cont.)
Size (mm)
30
33
33
36
36
PROPERTY CLASS 9.8
Size (mm)
6
6
8
8
10
10
12
12
14
14
16
16
18
18
20
20
22
22
24
24
27
27
30
30
33
33
36
36
Page 2-12
200 SPECIFICATIONS
Pitch
3.50
2.00
3.50
3.00
4.00
Pitch
0.75
1.00
1.00
1.25
1.25
1.50
1.25
1.75
1.50
2.00
1.50
2.00
1.50
2.50
1.50
2.50
1.50
2.50
2.00
3.00
2.00
3.00
2.00
3.50
2.00
3.50
3.00
4.00
Tightening Torques
Lb-Ft N•m
838 1136
1250 1695
1140 1546
1551 2103
1465 1986
Tightening Torques
Lb-Ft N•m
7 10
6 8
16 22
15 20
33 45
31 42
59 80
54 73
94 127
87 118
144 195
135 183
210 285
187 254
293 397
264 358
395 536
360 488
498 675
456 618
722 979
669 907
1005 1363
908 1231
1355 1837
1235 1674
1681 2279
1587 2152
