Specifications

General

Type of sensor 5 megapixel CMOS sensor
Lens F=2.8
Imaging area 29.7 x 41.9 cm (11.7 x 16.5 inch)
Zoom 10x digital (2x lossless for XGA/WXGA output, 1.9x for
SXGA output)
Output Analog: SXGA/WXGA/XGA
USB: QVGA/VGA/SVGA/SXGA/XGA/UXGA
Composite: NTSC/PAL
Frame rate Up to 30 fps
Memory (internal) 1GB
Memory card SD Card
compatibility

Remote Control

Range Approximately 8 m (26 feet)
Batteries AA x 2

Dimensions

Open (WxDxH) 270 x 326 x 437 mm (10.6 x 12.8 x 17.2 inches)
Folded (WxDxH) 270 x 192 x 244 mm (10.6 x 7.6 x 9.6 inches)
Weight 2.2 kg (1 lb)

Electrical

Power supply 100 - 240V AC ±10% 50/60Hz
Power consumption Standby: 0.46 W
Operating: 14.5 W

AC Adapter

Model DSA - 36 W - 12
Input 100 - 240V AC 50/60Hz 1.0A
Output 12V DC 2A

Environmental

Temperature Operating: 41 to 95˚F (5 to 35˚C)
Storage: 14 to 140˚F (-10 to 60˚C)
Humidity Operating: 20 to 80% RH, non-condensing
Storage: 10 to 90% RH, non-condensing
Operating altitude Up to 2000 meters (6561 feet)

System Requirements

These system requirements are for using the included software:
Windows: Microsoft Windows 7, Windows Vista, Windows XP (Service
Pack 2 or later)
Macintosh: Mac OS X 10.5 to 10.6
This product is also designed for IT power distribution system with phase-
to-phase voltage 230V.
