Next GATSBY 871891 Assembly Instructions Manual

Bathroom console

Advertisement

Quick Links

IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.

Tools Needed

Helpline

If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0844 844 8999
Should you need to return this product, please repack in the original packaging.

PRODUCT INFORMATION

• Made from MDF board and mirror.
• Made in China.
• We recommend the use of the wall attachment straps for safety reasons. Wall fixings are not included.

CARE INSTRUCTIONS

• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Do not place very hot or cold items against or in close proximity to the glass surface unless adequately thick
insulation material is used to prevent such items from coming into contact with the glass.
• Do not strike the glass with hard or pointed items.
• Clean using a glass cleaner and soft cloth. Do not use cleaning products containing abrasives as these will
scratch the glass.
• Do not sit or stand upon horizontal glass surfaces.
• Care must be taken when cleaning around the product with a vacuum cleaner to prevent damage to the glass
panels.

GLASS INFORMATION

• This item contains glass. Please handle with extreme care.
• BS 7449: 1991.
• Batch No.JJ
• This product contains 4 mm glass that does not conform to BS 6206. If the glass is chipped or broken replace with
glass of the type described. Consult the manufacturer, retailer or agent with regard to obtaining a manufacturing
specification and shape for replacement glass quoting the model number and batch number or date of manufacture.

FITTINGS

GATSBY BATHROOM CONSOLE 871891
ASSEMBLY INSTRUCTIONS.
Page 1 of 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GATSBY 871891 and is the answer not in the manual?

Questions and answers

Summary of Contents for Next GATSBY 871891

  • Page 1 GATSBY BATHROOM CONSOLE 871891 ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Should you need to return this product, please repack in the original packaging. PRODUCT INFORMATION •...
  • Page 2 A. Cam lock B.Cam bolt C. shelf fitting E. Black D. Glass x 12pcs x 12pcs x 4 pcs Screws x 25 clamp x 4pcs J.Plastic cap × I. Allen key G. Nickel H. Handle F. Door x 1 pc 2 pcs Screws x 24 x 2 sets...
  • Page 3 (9). Removable Shelf (10).Left door (11).Right × 1 pc × 1 pc door × 1 pc STEP ONE 1. Assemble Cam bolt (B) x 8 onto Side panel (3)(4), by using Allen Key (I) STEP TWO Attach Base panel (2) and Fixed shelf (8) to both Side panel (3) (4), by inserting Cam bolt (B) x 8 into holes on both ends of shelves, and lock with Cam lock (A) by turning it in colock-wise direction with Allen Key...
  • Page 4 STEP THREE 1, Asssemble the Cam bolt (B) x4 onto Top Panel (1). 2. Attach Top panel(1) to both Side panel (3) (4), by inserting Cam bolt (B) x 4 into holes on the top end of Side panels, and lock with Cam lock (A) by turning it in colock-wise direction with Allen Key (I).
  • Page 5 STEP SIX 1. Put Removable Glass shelf (7) into the Glass clamp (D) 2. Put Removable Shelf (9) onto the Shelf Fittings (C Note: Make sure the Shef Fittings sits in the groove on the bottom of the Removable shelf (9). STEP SEVEN Assemble the Door hinges (F) x 4 onto the doors (10)(11) and the inside of cabinet by using Nickel...
  • Page 6 VERTICAL STEP NINE Assemble the handle to front side of door: (1)the screw head and the black washer go on the inside of the door (2)the metal sleeve goes on the glass side of the door and sits in the pre-drilled hole ,the clear plastic washer then goes onto the screw thread.
  • Page 7 Next Retail Ltd, Desford Road, Leicester, LE19 4AT Page 7 of 7...
