IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Tools Needed
Helpline
If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is
found to be faulty. Should you need to return the unassembled product, please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step
instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of 2 persons is required to assemble this product.
PRODUCT INFORMATION
• Made from Pine with lacquer finish.
• Made in China.
• Natural features ensure that each piece is individual. Every effort is made to ensure colour continuity between
pieces, however this is a natural product, slight colour variations and natural grain markings may occur.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Always use a non-silicone based furniture polish. Silicone in furniture polishes can break down the lacquer finish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent
scratching or damage.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration
or warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if
necessary.
872404 HIGHBURY CHEST
ASSEMBLY INSTRUCTIONS.
Page 1 of 8
Advertisement
Table of Contents
Related Manuals for Next HIGHBURY 872404
Summary of Contents for Next HIGHBURY 872404
- Page 1 872404 HIGHBURY CHEST ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
- Page 2 FITTINGS A×34 B×34 C×4 D×4 (75×18×0.3mm) PARTS 1×1 2×1 3×1 4×3 5×4 6×2 7×2 8×2 9×2 Page 2 of 8...
- Page 3 STEP ONE 1. Insert 18 x cambolts (A) to panel 2 & panel 3, and tighten with a screwdriver. 2. Insert 4 x wood dowels(E) & 8 x wood dowels (F) on panel 2 & panel 3. 3. Insert 6 x wood dowel (E) to 3 x rails 17. 4.
- Page 4 STEP TWO 1. Attach panel 2 to panel 20 by 3 x screws (G), tighten with a screwdriver. STEP THREE 1. Attach panel 3 to panel 20 by 3 x screws (G), tighten with a screwdriver. STEP FOUR STEP FOUR 1.
- Page 5 STEP SIX 1. Attach panel 3 onto assembled unit. 2. Insert 9 x camlock (B) into rail 15,16, 3x17, 3x18 & rail 21 and tighten with a screwdriver. Ensure the arrow indicators on the camlocks are pointing towards the panel edges and ensure the assembly bolts locate properly into the camlocks before turning clockwise with a screwdriver to STEP SEVEN...
- Page 6 STEP NINE 1. Attach 1 x wall attachment strap (O) to the back of the top panel with 1 x washer (M) and 1 x screw (N). STEP TEN 1. Attach panel 8,9 & 14 to panel 6. k(B) t l 8&9 ti ht 2.
- Page 7 STEP ELEVEN 1. Attach panel 12,13 & 14 to panel 10. 2. Insert 4 x camlock(B) to panel 12&13, tighten with a screwdriver. 3. Insert 1 x camlock(D) to panel 14, tighten with a screwdriver. Ensure the arrow indicators on the camlocks are pointing towards the panel edges and ensure the assembly bolts locate properly into the camlocks before turning clockwise with a screwdriver to...
- Page 8 3. NOTE: Wall fixings are not included, please source suitable fixings for your wall type. If in doubt, please consult a qualified tradesman. Next Retail Ltd, Desford Road, Enderby, Leicester, LE19 4AT Page 8 of 8...
