IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.

Tools Needed

Helpline

If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0844 844 8999
Should you need to return this product, please repack in the original packaging.

PRODUCT INFORMATION

• Made from MDF board and smoked glass.
• Made in China.
• We recommend the use of the wall attachment straps for safety reasons. Wall fixings are not included.

CARE INSTRUCTIONS

• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Do not place very hot or cold items against or in close proximity to the glass surface unless adequately thick
insulation material is used to prevent such items from coming into contact with the glass.
• Do not strike the glass with hard or pointed items.
• Clean using a glass cleaner and soft cloth. Do not use cleaning products containing abrasives as these will
scratch the glass.
• Do not sit or stand upon horizontal glass surfaces.
• Care must be taken when cleaning around the product with a vacuum cleaner to prevent damage to the glass
panels.
GLASS INFORMATION
• This item contains glass. Please handle with extreme care.
• BS 7449: 1991.
• Batch No.JJ
• This product contains 4 mm glass that does not conform to BS 6206. If the glass is chipped or broken replace with
glass of the type described. Consult the manufacturer, retailer or agent with regard to obtaining a manufacturing
specification and shape for replacement glass quoting the model number and batch number or date of manufacture.
GATSBY BATHROOM CONSOLE 871891
ASSEMBLY INSTRUCTIONS.
Page 1 of 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GATSBY BATHROOM CONSOLE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Next GATSBY BATHROOM CONSOLE

  • Page 1 GATSBY BATHROOM CONSOLE 871891 ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Should you need to return this product, please repack in the original packaging.
  • Page 2 FITTINGS E. Black A. Cambolts D. Glass C. shelf fitting Screws x 3 pcs x 12pcs Camlocks x clamp x 4pcs x 12pcs F. European G. Nickel I. Allen key H. Handle hinge x 4 Screws x 24 x 1 pcs x 2 set PARTS (2).
  • Page 3 (9). Shelf 2 (10).Left (11).Right × 1 pcs door × 1 pcs door × 1 pcs STEP ONE 1.The connection string B lock to the side plates (3), (4) on (such as map location), using a wrench I lock STEP TWO 1.By three in one connector A and connection column B the floor (2) plate (8) and the side lock up, after a wrench I...
  • Page 4 STEP THREE 1.The backplane (5) (6) installed (alignment side behind slotting.) STEP FOUR 1. Lock up a self-tapping screw E right and left back, with a wrench with self- tapping screws E right and left back to lock up, with wrench STEP FIVE 1.The connection string B lock to the top (1) on (such as map location), using a wrench I lock...
  • Page 5 STEP SIX 1.The glass clip D mounted to the side plate (3) (4), such as map location 2.Laminated column C mounted to the side plate (3) (4), such as map location STEP SEVEN 1.The glass (7) installed, such as map location 2.Laminated ((9) installed, such as map location STEP EIGHT 1.The door hinge lock around door and cabinet...
  • Page 6 STEP NINE 1.The left and right panels installed, adjust to the best position LATERAL FRONT-TO-BACK VERTICAL STEP TEN 1.To handle group H fitted to the left and right panels Page 6 of 7...
  • Page 7 NOTE: Wall fixings are not included. Source suitable fixings for your wall type, if in doubt consult a qualified YOUR CONSOLE IS NOW READY FOR USE Next Retail Ltd, Desford Road, Leicester, LE19 4AT Page 7 of 7...
