SensorLink is the desktop-based software produced by Titan Logix Corp which is available for free for every Titan
user. Use this guide to:
Create, and modify a strapping table on any TD Series transmitter
Set key operational parameters and tank variations
Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
Step 7
Step 8
Step 9
Step 10
Step 11
Step 12
Step 13
Step 14
Step 15
Step 16
Step 17
Step 18
Step 19
Programming and Configuration Guide
www.titanlogix.com
TD 100
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TD 100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Titan Logix TD 100

  • Page 1: Table Of Contents

    TD 100 Programming and Configuration Guide SensorLink is the desktop-based software produced by Titan Logix Corp which is available for free for every Titan user. Use this guide to: • Create, and modify a strapping table on any TD Series transmitter •...
  • Page 2: Initiate Programming

    TD 100 Programming and Configuration Guide INITIATE PROGRAMMING CHECKLIST Ensure no flammable gases and/or fumes are present before installation or repair. Turn the vehicle power off before any installation activity. Ensure the tank is drained of liquid and free of vapors.
  • Page 3: Connection Through The Finch

    TD 100 Programming and Configuration Guide CONNECT TO THE TD100 TRANSMITTER (CONT.) START HERE IF MAKING A CONNECTION THROUGH THE FINCH II DISPLAY: Use the SV Bus Programming Kit adapter to connect to the transmitter via the Finch II Display.
  • Page 4: Strapping Table Setup

    TD 100 Programming and Configuration Guide STRAPPING TABLE SETUP CHECKLIST Ensure the TD100 is connected to a computer using the SV Bus Programming Kit. Ensure SensorLink is installed and working on your computer. Ensure the appropriate COM Port Drivers are installed on your computer.
  • Page 5: Input Strapping Table Settings

    TD 100 Programming and Configuration Guide INPUT STRAPPING TABLE SETTINGS (STEP 2) a. Click on “Add Row” to add rows to the table or start entering the values and press enter after each entry. b. Manually enter depth and volume values in corresponding columns as given in the manufacturer-provided table.
  • Page 6: Input Offset Measurement Settings

    TD 100 Programming and Configuration Guide INPUT OFFSET MEASUREMENT SETTINGS (STEP 3) a. Ensure you have the following data as measured during the mechanical installation process: •Tank thickness measurement in the appropriate units •Probe offset measurement in the appropriate units b.
  • Page 7: Input Alarm Settings

    TD 100 Programming and Configuration Guide INPUT ALARM SETTINGS (STEP 4) a. Spill alarm level: i. For dual-rod probe, no setting is needed by the user. Please see Detection Modes in the SensorLink Help section to learn more about spill alarm settings.
  • Page 8: Input Display Settings

    TD 100 Programming and Configuration Guide INPUT DISPLAY SETTINGS (STEP 5) Select the number of decimal places used for the volume data under the "Precision Setting" drop-down menu. Note: It is recommended to maximize the display resolution or number of decimal places in the volume measurement.
  • Page 9: (Optional) Input Sump And Riser Settings

    TD 100 Programming and Configuration Guide (OPTIONAL) INPUT SUMP SETTINGS If you have a sump on your tank, go to 'Set Sump' and add the Sump depth value as applicable to the installation. Clicking the "Set Sump" button will open a new window box in which the user can enter the sump values. The sump value cannot be less than 0.
  • Page 10: Verify The Strapping Table

    TD 100 Programming and Configuration Guide VERIFY THE STRAPPING TABLE Click on the 'Verify' button from the top ribbon. If there are no errors, an OK message will be returned, otherwise, any errors will be highlighted for the user to make necessary corrections.
  • Page 11: Program The Transmitter

    TD 100 Programming and Configuration Guide PROGRAM Ensure that the TD100 is connected to the computer using the SV Bus programming kit and all appropriate fields are filled in SensorLink. a. Click on the 'Program' button from the top ribbon to open the program dialog box.
  • Page 12: Importing The Strapping Table

    TD 100 Programming and Configuration Guide IMPORTING THE STRAPPING TABLE CHECKLIST Ensure the TD100 is connected to a computer using the SV Bus Programming Kit. Ensure SensorLink is installed and working on your computer. Ensure the appropriate COM Port Drivers are installed on your computer.
  • Page 13: Import From .Csv Format

    TD 100 Programming and Configuration Guide IMPORT FROM .CSV FORMAT a. Open TD100 utility on Sensorlink software. b. Click on the 'File' button to open the menu. c. Click on the 'Import CSV File' option to select the strapping table file.
  • Page 14: Cloning The Strapping Table

    TD 100 Programming and Configuration Guide CLONING THE STRAPPING TABLE (TD80 to TD100) CHECKLIST Ensure the TD100 is connected to a computer using the SV Bus Programming Kit. Ensure SensorLink is installed and working on your computer. Ensure the appropriate COM Port Drivers are installed on your computer.
  • Page 15 TD 100 Programming and Configuration Guide CLONING EXISTING TD80 STRAPPING TABLE (CONT.) h. Choose a suitable location for the file. i. Name the file. j. Click 'Save' to save the strapping table to .stb file format. k. Click on TD100 from the sidebar to go to the TD100 utility.
  • Page 16: Configure (Post-Installation)

    TD 100 Programming and Configuration Guide CONFIGURE (POST-INSTALLATION) CHECKLIST Ensure no flammable gases and/or fumes are present before installation or repair. Turn the vehicle power off before any installation activity. Ensure the tank is drained of liquid and free of vapors.
  • Page 17: Set Fill Alarm (Through Finch Ii)

    TD 100 Programming and Configuration Guide SET FILL ALARM (THROUGH FINCH II) a. Use the 'COMP SELECT' button on Finch II to select the appropriate compartment. b. Press the 'Up' arrow for 3 seconds and release it to enter the Set Fill alarm mode.
  • Page 18: Testing

    TD 100 Programming and Configuration Guide TESTING CHECKLIST Visually inspect all mechanical installations. Visually inspect all electrical installations. Ensure all required tools are available for testing. INITIATE START-UP Apply power to the TD100 system. Finch II display will show and test: •...
