ProNav JMR-5410-4X User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
ProNav AS
Hovlandsveien 52
4374 Egersund
+47 51464300
www.pronav.no
mail@pronav.no
JMR-5400 User Manual 20201214 temp
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JMR-5410-4X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ProNav JMR-5410-4X

  • Page 1 User Manual ProNav AS Hovlandsveien 52 4374 Egersund +47 51464300 www.pronav.no mail@pronav.no JMR-5400 User Manual 20201214 temp...

  • Page 2: Table Of Contents

    JMR-5400 Radar NB! Some menus depend on the setup during installation and what equipment is connected, so some menus may be missing from your radar. Symbols used in the manual  see more info in menu or page Index Power unit NQE-3167 for antenna power to JMR-5472 S and JMR-5482 S..................5 1.
  • Page 3 3.3 VRM / EBL fixed and floating T / R and unit ........................26 3.4 Own track ................................... 26 3.5 Pulse length..................................27 Radar Range ....................................28 Silence Alarm Sound ................................. 28 Acknowledge Alarm .................................. 28 Display resolution ..................................29 1280*1024 ....................................
  • Page 4 Anchor watch ................................48 Chart ....................................48 User Chart ..................................48 TT/AIS ....................................48 Tool box ..................................48 Setting ....................................49 Tools ....................................49 Views ....................................49 Alarm ....................................49 Hjelp ....................................50 Code ....................................50 Service menu .................................. 50 TT AIS target ..................................

  • Page 5: Power Unit Nqe-3167 For Antenna Power To Jmr-5472 S And Jmr-5482 S

    Service menu for user ..................................85 Kode ....................................85 Service meny ..................................85 Enter license codes..................................86 Operate channel selector on JHS-800 ............................86 VHF JHS800 Operation menus on radar ............................87 VHF MENYER ..................................... 87 DSC call with help of AIS ................................88 Power unit NQE-3167 for antenna power to JMR-5472 S and JMR-5482 S The circuit breaker disables in case of overvoltage or overload.

  • Page 6: Introduction

    1. Introduction 1.1 Radar types Radar Equipment Use the radar only as a navigation aid. The crucial decisions about navigation must always be made by the operator. Navigating only by radar can lead to accidents such as collisions or grounding. There are two technologies that apply to radar, pulse and solid state (Chirp) Pulse Radar Pulse radar uses a magnetron to create the transmitter pulse.

  • Page 7: Limitations In Radar Resolution

    Have tried to show this graphically in time axis, the lowest frequencies are delayed the most as it is the one that was sent out first and goes through all the delay circuits. Higher frequencies are delayed less so that the echoes with different frequency come through the receiver at the same time and at the end of the receiver are summed and mixed into one strong echo.

  • Page 8: Separation In Bearing

    Separation in bearing If there are two echoes next to each other, the radar «beam» must leave the first echo before it hits target no. 2 to be able to separate the echoes from each other. Minimum detection distance If the antenna is placed high, the echo approaching the boat will come under the radar beam and thus not appear in the radar image.

  • Page 9: Estimated Range On Radar

    Estimated range on radar Since the radar beam is not normally deflected much, it can be said that the height of the antenna and the height of the target determine the range (+ that the target gives a usable stable echo) ����...

  • Page 10: Echo Treatment / Filtration

    1.3 Echo treatment / filtration NB! In order for the filter to work optimally, the gyro signal should reach 50 times / sec as well as the correct speed indication from Log and GPS. Sea noise suppression (STC) and Gain amplification. These two functions are related to the fact that Gain indicates the maximum gain used and STC reduces this at short range.
  • Page 11 Echo magnification Echo magnification Enhance echo is selected level from Off to level3. this makes the echoes a little bigger. This happens both in distance detection and bearing [azimuth]. For distance, each measuring point is checked and compared with the nearest ones, in the drawing below the measuring point with echo is shown as X, echo that is magnified is shown with o.

  • Page 12: Fast Moving Targets And Sart

    1.4 Fast moving targets and SART Procedure for detecting moving echoes The radar has a feature for improving the detection of fast-moving radar echoes.  Fast Target Detection See menu under MENY + Setting Undermeny Oppsett Setting meny Echo Signal process Video Latitude Normal Receiver Band Width...

  • Page 13: Radar Settings, Enhancement And Data Processing Of The Radar Image

    2. Radar settings, enhancement and data processing of the radar image 2.1 Gain/Sea/Rain Adjust Rain, Sea and Gain with the buttons. Normally adjust Gain at long range and remove sea at short distance with sea, then you should normally be able to change the scale without having to readjust on these.
  • Page 14 Auto SEA Function Auto RAIN function Rain Auto + 40% with 30% Rain manual Auto Rain 40% manual Sea Note that Auto Sea do not reduce land echo as much as manual Sea. JMR-5400 User Manual 20201214 temp...

  • Page 15: Video Latitude

    2.2 VIDEO LATITUDE Sub Menu Setting Setting menu Echo Signal process Video Latitude Normal Video Noise Rejection Level1(low)  Auto Dynamic Range Control Process Switch Process Switch  2nd Proc mode Remain  Process Switch Range 3.0 NM  The band width of the receiver has a lot to say for noise reduction. In areas with a lot of heavy rain echo, try Super wide bandwidth.

  • Page 16: Video Noise Reduction

    2.3 Video Noise Reduction Sub Menu Setting Setting menu Echo Signal process Video Latitude Normal Video Noise Rejection Level1(low)  Auto Dynamic Rng Control Process Switch Process Switch  2nd Proc mode Remain  Process Switch Range 3.0 NM  ・...

  • Page 17: Auto Dynamic Range Control

    2.4 AUTO Dynamic Range Control ・ Automatically controls video bandwidth (dynamic range). ・ This function automatically sets the bandwidth to wide when you are in an area with strong sea or rain noise. . In other areas, the automatic bandwidth is set to narrow to increase sensitivity Sub Menu Setting Setting menu...

  • Page 18: Prosess Switch

    2.5 Prosess switch Sub Menu Setting Setting menu Echo Signal process Video Latitude Normal Video Noise Rejection Level1(low)  Auto Dynamic Rng Control Process Switch Process Switch  2nd Proc mode Remain  Process Switch Range 3.0 NM  Here you can choose whether to have different radar treatment processes in the long and short distance Do not select process switch range in an area with a lot of sea noise.

  • Page 19: Enhance, Amplification Of Small Echo

    2.7 Enhance, amplification of small echo ENH Off: Sets the target enhancement function to OFF. Set this function to Off when the resolution is especially needed. ENH Level1: Improves the radar echo by 1 level in the vertical and horizontal directions on the screen. Use for normal navigation ENH Level2: Improves the radar echo by 2 levels in the vertical and horizontal directions on the screen.

  • Page 20: Echo Processing

    2.8 Echo processing Process off, echo comes and goes Proc Processing Normal / Fast targets / No processing SART 3 Scan At strong Sea / RAIN Here, the intensity of the radar echo is built up echoes to see clearer per sweep (antenna rotations) so that sporadic 4 Scan echoes that are hidden...

  • Page 21: Preset Values In Function Setup

    2.9 Preset values in function setup: Switching between the preset function can be done by pressing the FUNC button or with the mouse in the indication field. Function COAST: Short area, many boats / echo and maximum resolution SEA: Relatively long area, such as in open sea Fishing: Small echoes, buoys at short range that can hide in sea echoes Storm:...
  • Page 22 2.9.2 Defalt setting for OBS Scene Obs scene Factory setting Target Enhance Echo process Rain   Auto Chg H-Up           Pulse length 0.75-1.5 NM 1.5 – 3 NM 3 – 6 NM 6 –...

  • Page 23: Turn On The Radar

    3 Turn on the radar Press the button to turn on, and to turn off, press both buttons Start-up screen where you can select Radar or data backup. Starts Radar automatically if no selection is made. If you have a map, you must accept the warning about map use before maps appear.
  • Page 24 Symbol Name Description On/OFF The buttons turn radar off and On Press the button to turn on, Switch off, press both buttons Rain Rain noise attenuator, press to switch between Auto and RAIN manual Auto/Man Sea noise limiter, pressure to switch between Auto and manual Auto/Man Gain...
  • Page 25 Symbol Name Description Parallel bearing ruler NB! Parallel index When activated, may appear as one or more "weird" lines see image. Displays MOB, Man Overboard, symbol on the screen, delete symbol by holding down the button. You can also activate MOB by pressing the MOB button in the right tool menu Menu for light adjustment Activates the function connected to the button.

  • Page 26: Pi Lines

    3.2 PI lines If the parallel index line setting goes awry and is forgotten, the line (s) can be displayed as a dash in any direction but can be easily removed with two clicks on [PI ] 3.3 VRM / EBL fixed and floating T / R and unit Center on measuring point No indication center locked to the boat's position C: Carried locks the starting point on the screen coordinate...

  • Page 27: Pulse Length

    3.5 Pulse length. Remember that the Gain button and adjusts the length of the transmitter heart rate in the areas where it is possible to change the transmitter heart rate. In short range only short pulse [SP1] is possible and in long range only long pulse [LP2] is possible, depending on which antenna is connected.

  • Page 28: Radar Range

    Radar Range Change the range with RANGE- /+ Or point to under distance in the upper left corner and select distance from the list. Silence Alarm Sound Point the cursor at the symbol and press Ent or press the SILENCE button on the scroll ball. Acknowledge Alarm To acknowledge the alarm, point the cursor at ACK and press ENT or press ALERT ACK on the scroll bar Alarm type...

  • Page 29: Display Resolution

    Display resolution Depending on the screen resolution, the menu choices and appearances on some menus are slightly different. The biggest difference is that the one with high resolution has room for one extra radar image (2nd.PPI). 1280*1024 1920*1200 or 1920*1080 With this resolution, you have access to an additional radar image with your own scale.

  • Page 30: Menues

    MENUES Radar Range Nav info Multi button Menu Button  page 30 Own ship nav data Right Toolbar, page 30 Other ships info Info-window Target info TT List AIS List/detailed info 2nd PPI Current/Wind Conning Expand Cursor View, Tools  side 69 Exp Cursor Off/On Alarm list...

  • Page 31: Adjust Screen Brightness And Control Panel

    Adjust screen brightness and control panel Brightness adjustment on the display and the control unit. Can be adjusted in the range from 0 to100. To adjust press  up for more light and  down for darker. Display and operation are adjusted separately.

  • Page 32: Man Over Bord Mob

    MAN OVER BORD MOB På radarbildet vises peiling og avstand til MOB punket MOB (Man Over Board) button when a person falls over board, use this button to mark the MOB position and show bearing and distance from own position . Press X to close info window Messages AIS and NAVTEX Message button, when this button is clicked, a dialog box related to the last message will appear among the...
  • Page 33 Eksempel på AIS melding Point the cursor at an ATON / AIS symbol: Cursor pop up info Next time cursor info Left mouse button is read out info Info that is displayed changes left to Cancel Press the right mouse button and you get more info Read out info Read out detailed info Property...
  • Page 34 Navtex message with area display, here shown with a dash through the message icon JMR-5400 User Manual 20201214 temp...

  • Page 35: Nav Data For Own Ship

    Nav data for own ship In the upper right corner, navigation data for the boat is displayed Heading HDG Gyro heading or manual. Magnetic can and is selected if one magnetic compass is mounted. STW speed waterlog, Manual or GPS if there is no log installed, NB! If GPS is used, only the along ship vector of GPS speed is used.

  • Page 36: Left Toolbox

    Left Toolbox Sets setting to factory setting Warning before reset. Map Off Turns off the heading / bow line as long as it is pressed Take a picture of the screen. The pictures are If a PC keyboard is connected, PrnScn can be used. saved in folders for manual pictures see Opens the favorite selection.

  • Page 37: Radar Setup

    Radar setup Information about the actual radar settings is displayed on the left side of the screen At the top is the selected scale, In / Out change scale, TM true- / RM Relative motion, Off center / N UP / H UP screen orientation. Spacers Off or On and Sea or GND stabilization.

  • Page 38: X2 Zoom Knapp

    X2 Zoom knapp På Når Zoom er valgt vil du flytte senter slik at bilde «forstørres» 2 ganger i retning of the cursor symbolt Automatic Rain and Sea (STC) Filter) Automatic / manual Sea / Rain, press [MAN] or [AUTO] and the function changes. You can also press the adjustment buttons on the STC and Rain control panel and switch between Auto and Manual.

  • Page 39: Ebl/Reference Point

    Multi-function Setting Vector length / time Info of selected vector time Trials Length  For track Trails page 57 C Up Angle How much price change is needed before price-up is reset Color on own track Function and selected Own Track Color Color are displayed in Color on Mark&Line Mark/Line Color...

  • Page 40: Reading Of Distance In Nm / Km Or Sm

    Reading of distance in NM / km or SM Click on the device indicator to switch between NM / km / SM JMR-5400 User Manual 20201214 temp...

  • Page 41: Display Info

    Display info Acquisition/Activation Zone Zone for automatic target tracking, see Alert /Alarmer og varsler page 63 Alarm zone is set from start angle clockwise (right) to end angle. You put Distance, minimum distance to longest distance. NEW Target Alarm Use AZ1 Use AZ2 [ 1 ] [ 2 ] Make AZ1 (AZ2)
  • Page 42 Vector own ship Heading / STW vector is displayed with a simple top arrow  SOG / COG vector is displayed with double arrow Vectors are set in the on-screen menu L/L Grid Graticule C-MAP MAX page 70 © If this is on, the longitude-latitude degree grid will be displayed Undermeny View.

  • Page 43: Chart

    Chart  C-MAP MAX map on SD chip. What is to be displayed by map info is done in View Menu C-MAP MAX see page 68 © © Switch maps on and off by pressing [MAP] Pressing [DATA OFF] turns off all additional information except radar echo temporarily, including maps.

  • Page 44: Take A Picture, Screen Dump

    Take a picture, Screen dump Select to see more icons Touch the camera icon with the cursor to take a picture.  Screen capture page 61 where you set the auto image interval. >>> Copy picture to USB Press Menu then Tools and select File manager.

  • Page 45: Automatic Image Storage

    Automatic image storage. It is possible to store the car part automatically at a fixed interval, normally 2% of the hard disk's 16GB is used for storage. Each image is around 160kB. When you use the Auto Capture set  Auto Erase on, you do not have to receive an alarm every minute after you have used up the storage capacity.

  • Page 46: Cursor Symbols

    Cursor symbols Cursor Name Description Pointer Standard mouse pointer Cross Shows position on map or radar screen Used for manual activation of radar targets Editing Movet objekt in chart modus Offset Offset position o screen  Center. Select/Velg Select Objects for editering Merke Used to create / move custom tags Arrow Cursors...

  • Page 47: General Menu

    General menu Press the MENU button in the upper right corner The MENU screen opens Minimum menues  What is shown here you decide in the menu View Kontroll page 70 You also have options to turn off submenus that you do not use in the control menu. ...

  • Page 48: Menu Icones

    MENU Icones ICON Icon menu Anchor Guard Radius Anchor Guard Polygon Anchor watch MENU> Chart Info om hvilke kartdata som benyttes   Chart Information more info page 48. Menu on/off page Chart MENU>User Map Bruker Kart File Operation User Mark/Line List Chart Delete by Type/Colour...

  • Page 49: Setting

    IKON Ikon meny MENU> Setting   Setting page 56. Menu page on/off Setting Echo Signal processing Trails Trails TXRX PRF pulse rep. frequency and antenna speed Network Video Simple ISW(LAN) Combining TT/AIS Common Alarm setting Radar target and AIS Radar target setting AIS filter setting Target Track...

  • Page 50: Hjelp

    IKON Ikon meny Route planning part of Plotter option Route monitoring, part of Plotter option Help Hjelp Code Kode 0 Code to enter setup/service menus For the user it is possible to enter a reduced service menu for simple setting/adjustment. Code Service meny Se Service meny for bruker side 85...

  • Page 51: Tt Ais Target

    TT AIS target  For AIS/NAVTEX Messages AIS and NAVTEX side 32 To display active AIS target with name it must be activated in View menu, select ship name or ship name & MMSI then MMSI is displayed if the name is missing JMR-5400 User Manual 20201214 temp...
  • Page 52 Ikon Meny MENU> TT/AIS target AIS Voyage Data Set in data for route and press ent for updating of the AIS Edit & send AIS Melding Send message to another ship using the AIS Safety or Routine message AIS folder for Sendt-, Storage and Received- AIS messages AIS Message Tray JMR-5400 User Manual 20201214 temp...
  • Page 53 Ikon Menu Navtex AIS Active alarmes AIS Message Tray Alarm history AIS own data JMR-5400 User Manual 20201214 temp...
  • Page 54 AIS last lost AIS Target Ikon Menu Highlighting Trial Maneuvering TT list TT/AIS list AIS list JMR-5400 User Manual 20201214 temp...
  • Page 55 Ikon Menu Own Ship AIS Data Last Lost AIS Target JMR-5400 User Manual 20201214 temp...

  • Page 56: Setting

    Setting Sub menu Setting Setting menu Echo Signal process Video Latitude Normal Receiver band width Video Noise Rejection Level1(low) Noise reduction / Processing  Auto Dynamic Range Auto Dyn. Control, for control Automatic distance, but you can choose different Process Switch processing types at short Process Switch ...
  • Page 57 Sub menu Setting Setting menu 0.125<MID <= 0.250 NM 0.25 < Long Obs Scene Short Standard  Standard  Long Standard   Trails Automatic / manual Sea / Rain, press [MAN] or [AUTO] and the function changes. You can also press the adjustment buttons on the STC and Rain control panel and switch...
  • Page 58 Sub menu Setting Setting menu Simple ISW(LAN)  Own Scanner Scanner Name Antenna 1 Other Scanner Selectable Scanner Name Antenna 2  Antenna 3  TT/AIS Common Association  Association Priority Threshold Bearing 1.0° Range 100m Course 30° Speed 10.0kn Applicable AIS Target Ship’s Dynamic treat Reach...
  • Page 59 Sub menu Setting Setting menu Target Track Target Track  Target Track Function View for Target Track File Load/Save Navtex Navtex  Show NAVTEX Highlightning of msg list  Navigational Alarm  Weather Alarm  Ice Warning SAR Information  Extended Nav Info [Display Filter For NAVTEX msg] Plotter Event Mark...
  • Page 60 Sub menu Setting Setting menu SBAS Cursor,EBL,VRM Tools  Change dist to «m» with less Kun for Expand Expand Cursor Cursor, EBL/VRM than 1NM kursor info av/på se Tools side 69 Change dist to «m» with less Når ikke valgt than 1NM vises NM EBL/VRM control Cursor...
  • Page 61 Sub menu Setting Setting menu EBL/VRM/PI Level4(Light) Own Symbol/HL/Vector Level4(Light) Chart Level2(Light) User Map/Track Level5(Light) Graticule/Gradenett Level Dark/ Light Panel Level4(Light) Display Sounds Is this menu missing  side 72 [Volume] [Volume] Melody Page 2/2 Key ACK Level 3  Misoperation Level 3 ...

  • Page 62: Menu>Toolbox

    Menu>Toolbox Sub menu Tools Box Menu Position 58°26.922N Displays MOB position, bearing, distance and time to MOB point and how long ago 5°58.646E MOB was enabled. Bearing 000.0 ° Range 0.000 NM TTG 0h00m00s Time0h00m00s Display for All Lines ON Mode All ...

  • Page 63: Alert

    Sub menu Tools Box Menu Distance 0.500 NM Tool Help Size : EBL/VRM Dial Rotation: Multi Deal Move : Cursor Move Enter : Left Click File type Screen Shot (Auto) File manager Screen shot User User Map Own Track Target Track Preferences Copy >>>...

  • Page 64: Menu Maintenance

    Menu Maintenance Maintn. menu Sub menu Setting Dato/Time/ Zone choose date Set local time LMT Set Time Zone Select Date Format  Select sync. with GPS for Date / Clock  Select sync. with GPS for Time Zone System [Software] [Functionality][Specification] Information Application...
  • Page 65 Maintn. menu Sub Menu Sensor Select/Status Sensor Select Diagnosis Monitor Test All Red All Green All Blue All White Pattern 1 Pattern 2 Pattern 3 Grey Skala Sound Test Sound Test Start Playing the following volume Light Test Light Test Start Magnetron |||||||_______ current...

  • Page 66: View

    View Sub menu Oppsett View. menu Type [Minimised Symbol] Own Ship  Stern Line Vector Ground stabilised Vector Sea Stabililised Vector Time 6min  Stabilisation indicator  Vector Time Mark Interval 1 min Setting AIS Filter Setting of AZ Own Track Clear Clear By Colour Track Colour All ...
  • Page 67 Track Colour ALL  [Clear] Clear By Number Track Number ALL  [Clear] Plot Plot Color  For All Targat Track White   For individual Target Track Track 1 White  Track 8 RED   Plot Interval 3 S  3 sek -60min, 0.1NM –...
  • Page 68 Sub Menu Oppsett View. menu Chart View  Display Fishing Area Special Line Type ------- C-MAP © C-Map Max page 1/4 Depth Shading Depth Shading Mode OFF Mode Normal Mode Dynamic Mode Dynamic Inverted Mode SAFE  Highlight Depth Area Minimum Depth 5m Max Depth 30m Safety Contour 5m...
  • Page 69 Sub Manu View. menu C-Map Max page 4/4 Chart Setting Chart Setting  VAD (Value Added Data)  Chart boundaries AUTO  Under Water Setting Under Water Setting  Wreck Depth Label  Diffuser Depth Label  Obstruction depth Label ...

  • Page 70: Kontroll

    Undermeny Oppsett View. menu This menu determines what is displayed when Top Level Screen Information you open Menu and inside the menus. Some Kontroll menus are license dependent. Display Meny  Show own track Control Kontroll Side 2/3 Anchor Watch Anchor watch Chart Kart...
  • Page 71  Positions Integrity  Integrity  AMS JMR-5400 User Manual 20201214 temp...
  • Page 72 Sub menu Setting Info View. menu  Setting Setting  Signal Processing  Obs. Scene Present  Obs. Scene Common  Trials  Trials Masking  TXRX  Associating  Skips dynamic  Setup same fleet  TT Test  Filter ...

  • Page 73: Inter Switch

    Inter switch The menu is only available when the interswitch is connected The open interswitch menu can only be opened in STANDBY mode Sett radaren i Standby Press the Interswitch button The name of the connected antenna is at the top, Mode below, here ant 1 is only connected to the display as a slave.

  • Page 74: Change Isw Setup

    Most often incorrect operation, eg Master processor is not turned on and then you try to connect another processor as a slave and operating voltage to the antenna is set up so that only paired antenna / Display has power supply to the antenna. Change ISW setup Remember that the devices you are going to change must be on standby.

  • Page 75: List Of Icons Used In The Radar

    List of icons used in the radar Name Function Icon Image Activ indicator On the menu button there is an indicator • «ball» which changes position and shows that the processor is running and working normally Delete Delete object Update Update information Indicator for selection Displays operating options,...
  • Page 76 Name Function Icon Image Wright tool Used in user maps to write info Cursor modus Skifter kursor til AUTO modus Undo Undo Button Screenshot Screenshot of display Favorites List of favorites Delete tools Used for erasing / erasing in user maps Silence Stops alarm sound Multibutton (small)
  • Page 77 Name Function Icon Image Standard AIS Displays the default AIS window Exspanded AIS Viser utvidet AIS vindu. window Registration of Registration / Deletion of favorites favorites, which includes [a] Unregistered [b] Registered [c] favorites that cannot be registered Plan routes Opens the route planning menu Monitor Route...
  • Page 78 Name Function Icon Image Password Password to open service settingsr Service Service setup Back Backspace Left Arrow Moves the insertion point to the left Right Arrow Moves the insertion point to the right Hjelp menu Displays operation guide Search Opens text search box. List or icon Switches between List or Icon (thumbnail) view...

  • Page 79: Ais And Target Symbols

    Name Function Icon Image End point Lag ende veipunkt eller editer rute Make end waypoint or edit route Parallell indeks/ Adjust the direction and peileskive distance on the bearing lines Individual guidelines Adjust the bearing lines individually with direction and distance Track PI bearing line locked to boat...
  • Page 80 Color Symbol Definition Comments Sort Active AIS target COG is shown with a dotted line, while the course line is shown with a solid line, At the end of the course line, the direction the boat turns is shown. The turn indicator does not need to be displayed.
  • Page 81 Regarding physical and virtual AIS AtoN (Aids to Navigation) Physical whole line Virtual is a dotted line Real AIS AtoN is used e.g. when there is poor visibility to display symbols such as light buoys, radarbeacon etc. Virtual AIS AtoN is used if it is difficult to place a normal sea mark, or to change the sailing route in the event of a breakdown. Color Symbol Definisjon...
  • Page 82 AIS SAR aitcraft & helicopter & boat Color Symbol Definisjon Kommentar black AIS SAR aircraft black Numeric info on SAR aircraft Black Lost contact with AIS The alarm activates Red X SAR aircraft The alarm message (LOST) Flashes red a red X appears above the target black AIS SAR Skip black...

  • Page 83: Normal" Alarm Messages

    «Normal» alarm messages Alarm Advarsler Forsiktighetsadvarsel ‘ Alarm message given if max speed is not confirmed/set during installation. The speed is used for filtrering position jumps.  : Feil! Fant ikke referansekilden. og Acknowledge Alarm side 28 For full oversikt sjekk engelsk manual Message Forklaring AIS ACT Max...
  • Page 84 New Target(AIS) New AIS target has been activated New Target(TT) New TT target here has been activated OPU1(Communication error) Error against control unit 1 OPU1(Keyboard Connection) Button or encoder error in kayboard 1 Position(doubtful) Questionable quality of position data Position(invalid) Format error or status error on position data Position(not plausible) Position is off scale...

  • Page 85: Service Menu For User

    Service menu for user These are menus that can both adjust the radar settings and others are just info If you adjust something here, note before and after values. Code Kode 0 Code to enter setup/service menus For the user, it is possible to open a reduced Code service menu for simple settings / adjustments.

  • Page 86: Enter License Codes

    Enter license codes. Some features are optional and can be unlocked with a license file. The file of the licenses must be copied to USB. Insert USB in the control or possibly in the radar processor. When you are in the radar image, end the radar with and select code input t enter 9999 to quit the radar menu.

  • Page 87: Vhf Jhs800 Operation Menus On Radar

    You can also add it to your favorite tap the favorite symbol to highlight it To open favorites go to the Menu bar on the right edge and select favorite symbol and click on VHF Call. If you check the box in front of the  check box, the delete button is activated and you can delete the favorite that is selected. VHF JHS800 Operation menus on radar VHF MENYER Name of active VHF...

  • Page 88: Dsc Call With Help Of Ais

    NB! If you activate double / triple guard from the radar, you lose control of the VHF. With dual operation on the VHF, it will not be possible to operate the VHF from the radar, and all functions will be grayed out.
  • Page 89 JMR-5400 User Manual 20201214 temp...
  • Page 90 ProNav AS Hovlandsveien 52 4374 Egersund Norway +47 51464300 www.pronav.no mail@pronav.no JMR-5400 User Manual 20201214 temp...

This manual is also suitable for:

Jmr-5410-6xJmr-5410-6xhJmr-5425-6xhJmr-5425-7xJmr-5425-9xJmr-5430-s ... Show all
