Loading Roll Paper

1
Open the roll paper cover.
2
Push down the lock lever, then move the roll paper
holder to the left.
3
Place the roll paper on top of the printer.
4
If necessary, adjust the roll media adapters to fit the
core size of the roll paper. Then release the tension
lever on both adapters.
2-inch core
3-inch core
5
Push the adapters into the paper core at both ends of
the roll. Then push down the tension levers to secure
them.
6
Move the roll paper all the way to the right.
7
Slide the roll paper holder to align the left adapter
with the on the holder.
8
Roll the paper slowly into position.
2
