- Page 1 Paper Feed Unit Type TK1110 Machine Code: J307 Field Service Manual 29 December, 2009...
-
Page 3: Safety And Symbols
Safety and Symbols Replacement Procedure Safety • Turn off the main power switch and unplug the machine before beginning any of the replacement procedures in this manual. Symbols Used in this Manual This manual uses the following symbols. : See or Refer to : Screws : Connector : Clamp... -
Page 4: Table Of Contents
TABLE OF CONTENTS Safety and Symbols............................1 Replacement Procedure Safety........................1 1. Replacement and Adjustment Common Procedures............................3 Cassette Tray, Rear Unit Removal.........................3 Covers................................4 Chassis Removal.............................6 Paper Feed Motor Mount..........................7 Sensors, Switch..............................10 Relay Sensor..............................10 Paper End Sensor............................11 Rear Unit Switch............................13 PFU Control Board............................15 Paper Feed Motor............................16 Paper Feed Clutch, Rollers..........................17 Gears, Paper Feed Clutch...........................17... -
Page 5: Replacement And Adjustment
1. Replacement and Adjustment Common Procedures Cassette Tray, Rear Unit Removal 1. Switch the main machine off and disconnect the power cord from the machine and power outlet. 2. Lift the machine off the PFU and set it aside. 3. Place the PFU on a flat clean surface. Two sensors are visible: [1] Relay sensor [2] Paper end sensor... -
Page 6: Covers
1. Replacement and Adjustment 5. Remove paper cassette [1]. 6. Remove rear unit [2]. Covers Right Cover, Cross-Piece 1. Remove the right cover ( x3). 2. Remove the cross-piece. - Page 7 Common Procedures Left Cover 1. Remove the left cover ( x3). 2. Lift the left cover up and disconnect the top connectors ( x2). 3. Disconnect the connectors below ( x2).
-
Page 8: Chassis Removal
1. Replacement and Adjustment Chassis Removal The chassis must be removed to service the electrical components and rollers. Preparation Remove: • Paper cassette, rear unit • Right cover, cross-piece • Left cover 1. Disconnect the chassis on the left side ( x2). 2. -
Page 9: Paper Feed Motor Mount
Common Procedures 3. Lift the chassis off the frame of the PFU. 4. Place the chassis on a clean, flat surface. 5. With the chassis removed you can see the friction pad that prevents double-feeding from the paper cassette. Clean this pad with a damp cloth to prevent double-feeding. Paper Feed Motor Mount Preparation Remove:... - Page 10 1. Replacement and Adjustment 1. Disconnect the motor mount ( x3). 2. Pull the motor mount slightly away from the chassis.
- Page 11 Common Procedures 3. Disconnect the paper feed motor [1] and paper feed clutch [2]. 4. Remove the motor mount.
-
Page 12: Sensors, Switch
1. Replacement and Adjustment Sensors, Switch Relay Sensor Preparation Remove: • Paper cassette, rear unit • Right cover, cross-piece • Left cover • Chassis With the chassis top side up, you can see the relay sensor. 1. Turn the chassis over (bottom side up). 2. -
Page 13: Paper End Sensor
Sensors, Switch 4. Disconnect and remove the sensor ( x1). Re-installation • After re-attaching the relay sensor, make sure that the feeler moves freely up and down. Paper End Sensor Preparation Remove: • Paper cassette, rear unit • Right cover, cross-piece •... - Page 14 1. Replacement and Adjustment With the chassis top side up, you can see the paper end sensor. 1. Turn the chassis over (bottom side up). 2. Use the tip of a small screwdriver to release the sensor tabs.
-
Page 15: Rear Unit Switch
Sensors, Switch 3. Turn the chassis over (top side up). 4. Disconnect and remove the sensor [1] ( • After re-attaching the relay sensor, make sure that the feeler [2] moves freely up and down. Rear Unit Switch Preparation Remove: •... - Page 16 1. Replacement and Adjustment 1. Remove the push-switch collar ( x1). 2. Depress the top tab [1] and bottom tab [2] to release the switch. 3. Remove the switch ( x1).
-
Page 17: Pfu Control Board
PFU Control Board PFU Control Board Preparation Remove: • Paper cassette, rear unit • Right cover, cross-piece • Left cover • Chassis The PFU control board [1] is mounted next to the motor mount [2] 1. Remove the PFU control board ( x All, x2, Standoffs x2). -
Page 18: Paper Feed Motor
1. Replacement and Adjustment Paper Feed Motor Preparation Remove: • Paper cassette, rear unit • Right cover, cross-piece • Left cover • Chassis • Motor mount 1. Pull the motor mount [1] and heat sink away from the machine. 2. Place the motor mount face down [2] and disconnect it ( x4). 3. -
Page 19: Paper Feed Clutch, Rollers
Paper Feed Clutch, Rollers Paper Feed Clutch, Rollers Gears, Paper Feed Clutch Preparation Remove: • Paper cassette, rear unit • Right cover, cross-piece • Left cover • Chassis • Motor mount 1. Remove the harness cover plate [1] ( x1, Tabs x4). The harness cover plate is fastened by four tabs at the locations shown by the arrows. - Page 20 1. Replacement and Adjustment 3. Disconnect all harnesses from the PFU control board ( x All). 4. Disconnect paper feed clutch [1] and gear [2] ( x 2). 5. Remove the gears in order as shown above. • Be sure to re-install them in reverse order.
-
Page 21: Paper Feed Roller
Paper Feed Clutch, Rollers 6. Remove the paper feed clutch. Re-installation When you re-install the paper feed clutch: • Rotate the clutch until it slides over the end of the shaft. • Make sure that the notch of the clutch arm [2] is locked onto the stud [3]. Paper Feed Roller Paper Feed Roller Preparation... - Page 22 1. Replacement and Adjustment • Paper cassette, rear unit • Right cover, cross-piece • Left cover • Chassis • Motor mount • All gears, paper feed clutch 1. Remove the shaft mount plate [1] ( x4). 2. Remove the bearing [1] from the shaft of the paper feed roller. •...
-
Page 23: Pick-Up Roller
Paper Feed Clutch, Rollers 3. Remove the paper feed roller. Pick-up Roller Preparation Remove: • Paper cassette, rear unit • Right cover, cross-piece • Left cover • Chassis • Motor mount • All gears, paper feed clutch • Shaft mount plate (see previous procedure) 1. - Page 24 1. Replacement and Adjustment 3. Remove the bushing from the tip of the shaft [1]. 4. Remove the pick-roller shaft [2]. 5. With the tip of your finger, pull the Teflon tab [1] to release the roller. 6. Pull the pick-up roller [2] off the shaft.
