Quick Start - ECOVACS ROBOTICS DEEBOT M81 Pro Instruction Manual

3. Operating and Programming

3.2 Quick Start

Charging Dock Placement
1
Place the Charging Dock on a level
floor surface against the wall with the
base perpendicular to the ground. Keep
the immediate area 1.5m (5') in front
of the charger and 0.5m (1.6') on both
sides of the charger clear of objects and
reflective surfaces.
Plug the Charging Dock in.
Install the Battery Pack
2
Place the Battery Pack into the battery slot on the bottom of DEEBOT. Press the Battery Pack
into the slot until it clicks.
Install Side Brushes
3
Attach Side Brushes to the bottom of
DEEBOT by pressing a brush into each
slot with the matching color until it clicks.
10
EN
Power ON
4
Press and hold the
robot. DEEBOT is powered ON when the
glows a continuous BLUE.
button on the
3 3
ON
