4. ASSEMBLING

4.1 Install the Battery

•
Slide forward in the direction of the arrow, and the lock is fastened on the rack.
4.2 Install the Dust Cup
•
Align the protruding part of the main unit with the recessed part of the dust box, push it
forward.

4.3 Install the Machine

•
1: Connect the main body to the telescopic tube first, then install the brush.
•
2: Connect the main body to the brush directly.
EN 6
Ka da
Ka da
Ka da
Ka da
Ka da
