- Page 1 SL40E INSTALLATION INSTRUCTIONS Version 3...
- Page 2 SL40E INSTALLATION INSTRUCTIONS Introduction Thank you for choosing Sylvan, this lock is for Residential use only, and its two year warranty (mechanical and electronic) only applies for locks being used for residential use. To ensure you get the best out of your purchase we ask that you follow the below: •...
-
Page 3: Product Specifications
SL40E INSTALLATION INSTRUCTIONS Lock Dimensions Product specifications: SL40E Model number SL40E Door thickness 35mm - 60mm range Material of Aluminum alloy IP rating IP55 Manufacture Weight 3 kg Type of use Residential use only Options of Passcode Blue tooth App unlocks infinite... -
Page 4: Installation
SL40E INSTALLATION INSTRUCTIONS Installation: SL40E Packing List IMPORTANT ONLY ROTATE THE HANDLE Check handing of the lever UPWARDS IN THE DIRECTION SHOWN BELOW - DAMAGE CAUSED WILL VOID WARRANTY Below are the instructions to change handing. • Front panel •... - Page 5 SL40E INSTALLATION INSTRUCTIONS Installation: Step 3: Install Inside Lock Panel Align rubber boot mounting plate to the exterior door Step 1: Install Latch (see latch instructions included) face and fit the latch screws. IMPORTANT 1. Mark and crop door using installation template provided...
- Page 6 1. Holes drilled and aligned as per drilling template. 2. Ensure the rubber boot is aligned correctly with a The SL40E Smart Lock has a mechanical key override to unlock it. good seal on the door, also making sure the lugs are The lock location is under the front panel.
- Page 7 7. If you have downloaded the app and loaded your lock on your front door device you are now the administrator of this lock, from here you can now add or delete users / passcodes / RFID card etc. 6. The lock is now successfully added to the app. www.sylvan.co.nz www.sylvan.co.nz...
-
Page 8: Setting A Passcode
We suggest day and week. naming each PIN with the • To lock the door when in passage mode, press name of the person using it. and hold the # key on the lock. E.g. Bobs PIN www.sylvan.co.nz www.sylvan.co.nz... - Page 9 • This lock can accept up to 200 Unique finger prints • This can be done using a smart hub SLG02 (sold separately) see ‘sylvan.co.nz/smart-hub-slg02/’ 1. From main screen click on 2. Then add finger print 4. Name the finger print 1.
-
Page 10: Privacy Lock
TTLock App Privacy Lock: 1. New feature with the SL40E is a privacy lock. To use it, enable in the lock settings and use sliding button on inside panel of the Smart Lock as shown. Red means only the Key Override or Master Admin can enter, all other pincodes and RFID cards won’t unlock the... -
Page 11: Product Warranty
1. Please keep this booklet and receipt so that you can use it when you need warranty service. 2. We provide you with a two-year warranty from the date of purchase. 127 Diana Drive Glenfield Auckland 0627 Ph: +64 9 444 5359 Email: sales@gdrutter.co.nz Web: www.sylvan.co.nz...
