  • Page 1 O P E R A T I N G I N S T R U C T I O N S i110P, i110R Safety position switch...
  • Page 2 Original document This document is an original document of SICK AG. O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 8027232/1CY6/2022-09-14 | SICK Subject to change without notice...

  • Page 3: Table Of Contents

    EU declaration of conformity..............UK declaration of conformity..............8027232/1CY6/2022-09-14 | SICK O P E R A T I N G I N S T R U C T I O N S | i110P, i110R Subject to change without notice...

  • Page 4: Scope

    These operating instructions are original operating instructions. O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 8027232/1CY6/2022-09-14 | SICK Subject to change without notice...

  • Page 5: On Safety

    8027232/1CY6/2022-09-14 | SICK O P E R A T I N G I N S T R U C T I O N S | i110P, i110R Subject to change without notice...

  • Page 6: General Protective Notes And Protective Measures

    Do not override safety position switches (by bridging contacts), turn them from their protective position, remove them or defeat them in any other way. O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 8027232/1CY6/2022-09-14 | SICK...

  • Page 7: Mounting

    Take note of the data in the switch-path diagram when mounting the radial cam. 8027232/1CY6/2022-09-14 | SICK O P E R A T I N G I N S T R U C T I O N S | i110P, i110R Subject to change without notice...

  • Page 8: Change Actuator Entry Direction

    Set direction required (4 × 90°). Tighten screws to 1.2 Nm. O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 8027232/1CY6/2022-09-14 | SICK Subject to change without notice...

  • Page 9: Protection Against Surroundings

    Cover the control slot, the actuator and the type label when painting. 8027232/1CY6/2022-09-14 | SICK O P E R A T I N G I N S T R U C T I O N S | i110P, i110R Subject to change without notice...

  • Page 10: Electrical Installation

    Check sealing at conduit entry. Close switch lid and tighten screws. O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 8027232/1CY6/2022-09-14 | SICK Subject to change without notice...
  • Page 11 Figure 2: Switching position diagram RA = roller lever, PA = roller tappet) 8027232/1CY6/2022-09-14 | SICK O P E R A T I N G I N S T R U C T I O N S | i110P, i110R Subject to change without notice...

  • Page 12: Commissioning

    It is not permitted to exchange individual components or modules! Safety switches must be completely replaced after 1 million switching operations. O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 8027232/1CY6/2022-09-14 | SICK...

  • Page 13: Disposal

    8027232/1CY6/2022-09-14 | SICK O P E R A T I N G I N S T R U C T I O N S | i110P, i110R Subject to change without notice...

  • Page 14: Technical Specifications

    Jam screws contacts 1.0 Nm Head screws 1.2 Nm O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 8027232/1CY6/2022-09-14 | SICK Subject to change without notice...

  • Page 15: Dimensional Drawings

    Figure 3: Dimensional dawing i110-R Figure 4: Dimensional dawing i110-P 8027232/1CY6/2022-09-14 | SICK O P E R A T I N G I N S T R U C T I O N S | i110P, i110R Subject to change without notice...

  • Page 16: Conformities And Certificates

    Electrical Equipment (Safety) Regulations 2016 • Supply of Machinery (Safety) Regulations 2008 O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 8027232/1CY6/2022-09-14 | SICK Subject to change without notice...
  • Page 17 CONFORMITIES AND CERTIFICATES 8027232/1CY6/2022-09-14 | SICK O P E R A T I N G I N S T R U C T I O N S | i110P, i110R Subject to change without notice...
  • Page 18 CONFORMITIES AND CERTIFICATES O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 8027232/1CY6/2022-09-14 | SICK Subject to change without notice...
  • Page 19 CONFORMITIES AND CERTIFICATES 8027232/1CY6/2022-09-14 | SICK O P E R A T I N G I N S T R U C T I O N S | i110P, i110R Subject to change without notice...
  • Page 20 Phone +7 495 283 09 90 E-Mail info@sick.com E-Mail office@sick.com.gr E-Mail info@sick.ru Vietnam Hong Kong Singapore Phone +65 6744 3732 Phone +852 2153 6300 Phone +65 6744 3732 E-Mail sales.gsg@sick.com E-Mail ghk@sick.com.hk E-Mail sales.gsg@sick.com Detailed addresses and further locations at www.sick.com SICK AG  |  Waldkirch  |  Germany  |  www.sick.com...
