  • Page 1 O P E R A T I N G I N S T R U C T I O N S i17S Safety switches...
  • Page 2 Original document This document is an original document of SICK AG. O P E R A T I N G I N S T R U C T I O N S | i17S 8027215/1CY3/2022-10-24 | SICK Subject to change without notice...

  • Page 3: Table Of Contents

    Conformities and certificates............17 EU declaration of conformity..............UK declaration of conformity..............8027215/1CY3/2022-10-24 | SICK O P E R A T I N G I N S T R U C T I O N S | i17S Subject to change without notice...

  • Page 4: Scope

    These operating instructions are applicable to the i17S safety switch. These operating instructions are original operating instructions. O P E R A T I N G I N S T R U C T I O N S | i17S 8027215/1CY3/2022-10-24 | SICK...

  • Page 5: On Safety

    (ISO/TR 24119). 8027215/1CY3/2022-10-24 | SICK O P E R A T I N G I N S T R U C T I O N S | i17S Subject to change without notice...

  • Page 6: Correct Use

    Restrict access to replacement actuators, so they cannot be used for bypassing. O P E R A T I N G I N S T R U C T I O N S | i17S 8027215/1CY3/2022-10-24 | SICK...

  • Page 7: Mounting

    (see figure Insert the actuator into the actuating head. 8027215/1CY3/2022-10-24 | SICK O P E R A T I N G I N S T R U C T I O N S | i17S Subject to change without notice...

  • Page 8: Reversing The Actuating Direction

    Tighten the cover screws. Seal unused actuating slots with the enclosed slot covers. O P E R A T I N G I N S T R U C T I O N S | i17S 8027215/1CY3/2022-10-24 | SICK Subject to change without notice...

  • Page 9: Protection Against Surroundings

    Cover the control slot, the actuator and the type label when painting. 8027215/1CY3/2022-10-24 | SICK O P E R A T I N G I N S T R U C T I O N S | i17S Subject to change without notice...

  • Page 10: Electrical Installation

    !" !" " Figure 7: Contact assignments i17-SA214 O P E R A T I N G I N S T R U C T I O N S | i17S 8027215/1CY3/2022-10-24 | SICK Subject to change without notice...

  • Page 11: Commissioning

    Safety switches must be completely replaced after 1 million switching operations. 8027215/1CY3/2022-10-24 | SICK O P E R A T I N G I N S T R U C T I O N S | i17S Subject to change without notice...

  • Page 12: Disposal

    Always dispose of serviceableness devices in compliance with local/ national rules and regulations with respect to waste disposal. O P E R A T I N G I N S T R U C T I O N S | i17S 8027215/1CY3/2022-10-24 | SICK...

  • Page 13: Technical Specifications

    (0.57) 52 (2.05) Figure 8: Dimensional drawing actuator iE17-S1 8027215/1CY3/2022-10-24 | SICK O P E R A T I N G I N S T R U C T I O N S | i17S Subject to change without notice...
  • Page 14 4 x 5.5 Figure 10: Dimensional drawing actuator iE16-F1 O P E R A T I N G I N S T R U C T I O N S | i17S 8027215/1CY3/2022-10-24 | SICK Subject to change without notice...
  • Page 15 TECHNICAL SPECIFICATIONS Figure 11: Dimensional drawing i17-SA213 8027215/1CY3/2022-10-24 | SICK O P E R A T I N G I N S T R U C T I O N S | i17S Subject to change without notice...

  • Page 16: Minimum Door Radius

    60 mm 60 mm 60 mm 60 mm O P E R A T I N G I N S T R U C T I O N S | i17S 8027215/1CY3/2022-10-24 | SICK Subject to change without notice...

  • Page 17: Conformities And Certificates

    Equipment Regulations 2012 • Supply of Machinery (Safety) Regulations 2008 8027215/1CY3/2022-10-24 | SICK O P E R A T I N G I N S T R U C T I O N S | i17S Subject to change without notice...
  • Page 18 CONFORMITIES AND CERTIFICATES O P E R A T I N G I N S T R U C T I O N S | i17S 8027215/1CY3/2022-10-24 | SICK Subject to change without notice...
  • Page 19 CONFORMITIES AND CERTIFICATES 8027215/1CY3/2022-10-24 | SICK O P E R A T I N G I N S T R U C T I O N S | i17S Subject to change without notice...
  • Page 20 Phone +7 495 283 09 90 E-Mail info@sick.com E-Mail office@sick.com.gr E-Mail info@sick.ru Vietnam Hong Kong Singapore Phone +65 6744 3732 Phone +852 2153 6300 Phone +65 6744 3732 E-Mail sales.gsg@sick.com E-Mail ghk@sick.com.hk E-Mail sales.gsg@sick.com Detailed addresses and further locations at www.sick.com SICK AG  |  Waldkirch  |  Germany  |  www.sick.com...
