Summary of Contents for Retevis RA86
- Page 1 RA86 Mobile Radio USER’S MANUAL...
-
Page 2: Table Of Contents
--------------------------------------------------------09 CTCSS/DCS Frequency Table ---------------------------------------------------10 Technical Specifications -----------------------------------------------------------12 WARNING -----------------------------------------------------------------------------13 For downloading further resources: Brochures, Software/Firmware, Manual etc, Pls contact your direct reseller first OR go to website retevis.com and check “support” in the each product link to download it. -
Page 3: Users Safety Information
RA86 is designed for General Mobile Radio Service (GMRS) operation. All Retevis GMRS radios can communicate with each other freely. The frequency of GMRS is a shared frequency, and the possibility of interference is relatively high. So the RA86 factory frequency setting is with CTCSS/DCS. -
Page 4: Installing Your Radio
Connecting the Microphone Insert the RJ45 connector into the front of the RA86. The microphone mounting bracket can be attached to the vehicle dash or other convenient location in a manner similar to the radio’s mounting bracket. -
Page 5: Radio Introduction
Radio Introduction Speaker Mic Name Short Press Function Long Press Function Speaker Speaker Microphone Menu Enter menu, confirm selection and exit menu Volume+ Raise volume during standby, Raise volume during standby, Function selection during menu Function selection during menu Enter weather mode Call/Lock Press to send a call signal Keypad Lock... - Page 6 Rear panel ① ② ③ ④ Functions Antenna connector Connect a 50 ohm antenna Connect external speaker Ex-Speaker Jack Power cable Connect a standard DC power cable Microphone Jack Connect Handheld Speaker Mic LCD Display Indicates when the radio is in the Indicates KEY LOCK mode is on.
- Page 7 With the radio off, press and hold the Power Button for three seconds. You will hear a tone when the radio is on. ▪The LCD display will show Retevis icons for one second and then display the most recently selected channel.
-
Page 8: Menu Function Introduction
8.NOAA Weather forecast:WX Retevis RA86 has a NOAA Weather Radio function, to enable the user to receive weather reports from designated NOAA stations. Your radio also has a NOAA Weather Scan function, to enable the user to scan all 10 channels for the NOAA National Weather Service. - Page 9 When the transmission ends the channel is muted again. Transmissions that do not have the correct tone are not heard. The RA86 has 260 Privacy Codes (50 CTCSS, 105 DCS-N and 105 DCS-I ), which can be applied to any channel. If desired, you can select a different Privacy Code for each channel. See CTCSS/DCS frequency Chart for lists of available Privacy Codes.
- Page 10 REPEATER Your RA86 has the ability to access repeater channels. The use of a repeater can significantly increase a radio’s range and coverage area. Prior to using a repeater you must coordinate with the owner of the repeater to gain permission to use the repeater.
- Page 11 LCD will still display normally. SPEAKER SELECT The RA86 has two speakers. You can choose which speaker you would like to use for your audio. ▪ Short press the MENU button in standby mode until the Speaker Sel menu is displayed；...
-
Page 12: Ctcss/Dcs Frequency Table
CH NO. TX Frequency(MHz) RX Frequency(MHz) Code(Hz) Power 467.6875 D065N 467.7125 D116N 462.5500 462.5500 123.0 High 462.5750 462.5750 D743I High 462.6000 462.6000 D332I High 462.6250 462.6250 127.3 High 462.6500 462.6500 D243I High 462.6750 462.6750 D606N High 462.7000 462.7000 D731I High 462.7250 462.7250 136.5... - Page 13 Code Code Code Code Code DCS-169 DCS-001 D023N DCS-043 D251N DCS-085 D532N DCS-127 D131I D371I DCS-170 DCS-002 D025N DCS-044 D252N DCS-086 D546N DCS-128 D132I D411I DCS-003 D026N DCS-045 D255N DCS-087 D565N DCS-129 D134I DCS-171 D412I DCS-172 DCS-004 D031N DCS-046 D261N DCS-088 D606N DCS-130...
-
Page 14: Technical Specifications
Technical Specifications GENERAL Frequency Range GMRS Number of Channels 30 channels Channel Spacing 20K (Wide Band) 12.5K (Narrow band) Operating Voltage DC 13.8V (Standard version) DC 12.6-14.4V (Optional version) Frequency Stability ±2.5ppm Operating Temperature -30℃-+55℃ RECEIVER Adjacent Channel Selectivity ≥60dB Receiving sensitivity ≤-122m@SINAD=12dB Audio distortion... - Page 15 Your Retevis two-way radio has a RF Exposure Product Label. Also, your Retevis user manual, or separate safety booklet includes information and operating instructions required to control your RF exposure and to satisfy compliance requirements.
- Page 16 When operating in front of the face, worn on the body, always place the radio in a Retevis approved clip, holder, holster, case, or body harness for this product. Using approved body-worn accessories is important because the use of Non-Retevis approved accessories may result in exposure levels, which exceed the IEEE/ICNIRP RF exposure limits.
-
Page 17: Warning
•The adapter shall be installed near the equipment and shall be easily accessible Approved Accessories •This radio meets the RF exposure guidelines when used with the Retevis accessories supplied or designated for the product. Use of other accessories may not ensure compliance with the RF exposure guidelines and may violate regulations. - Page 18 1.This guarantee card should be kept by the user, no replacement if lost. 2.Most new products carry a two-year manufacturer’s warranty from the date of purchase. Further details, pls read http://www.retevis.com/after-sale/ 3.The user can get warranty and after-sales service as below: ・Contact the seller where you buy.
- Page 19 Shenzhen Retevis Technology Co.,Ltd. 7/F, 13-C, Zhonghaixin Science&Technology Park, No.12 Ganli 6th Road, Jihua Street, Longgang District, Shenzhen, China Web:www.retevis.com E-mail:kam@retevis.com Facebook:facebook.com/retevis MADE IN CHINA...
- Page 20 说明书要求 尺寸：120*160mm 印刷：黑白印刷 装订：胶黏订 纸张材质：双胶纸 本页无需印刷...
