Summary of Contents for iTechworld X Series

  • Page 1 X RANGE WATERPROOF LITHIUM BATTERIES User Guide...
  • Page 2: Key Features

    USER GUIDE KEY FEATURES The iTechworld X range is the pinnacle of deep cycle lithium battery design. The X range has preinstalled Battery Management System that accepts charge from almost every charging system making it perfect for use in boats, caravans, motor-homes, RVs, and more.
  • Page 3: General Specifications

    Life Cycles 50%: 10000 + Life Cycles 30%: 16000 + IP67 Rated Waterproof and dustproof Terminal Type: M8 Case Material: ABS For more information on specifications please visit our website and select your iTechworld lithium battery. Scan to visit our website...
  • Page 4 SAFETY Please follow and understand these instructions before using the iTechworld battery; failure to do so can cause the battery to fail. It is strictly prohibited to disassemble the battery. Inside the battery are electrolytes. These electrolytes can be skin and eye irritants.
  • Page 5: Do's And Don'ts

    Exposure to sunlight can increase discharge rate of battery. If battery shows any shape change, colour change or any liquid seeping from battery stop using immediately and contact iTechworld. If the battery terminal screws are corroded, be careful not to bend the terminals when tightening or loosening.
  • Page 6: Wiring Diagram

    USER GUIDE WIRING DIAGRAM Caravan system:...
  • Page 7 USER GUIDE OPTIMISING YOUR CHARGING The iTechworld X range of batteries has a sophisticated Battery Management System, Cell Balancing and the Redback Operating System pre-installed. This hardware allows the batteries to be charged from almost all non-lithium charging profiles. We suggest following our guidelines below to optimise the system for charging systems where the parameters can be changed.
  • Page 8: Discharge Curve

    USER GUIDE DISCHARGE CURVE Please note that a lithium battery's discharge curve will differ from your previous lead acid batteries. Please study the discharge curve below to better understand how the lithium battery will perform.
  • Page 9: Safe Mode

    USER GUIDE SAFE MODE Inside each iTechworld battery is a Battery Management System that has several different safety features that you will not find in lead acid, calcium or even other lithium batteries. To ensure iTechworld batteries are the safest batteries available in the...
  • Page 10 USER GUIDE SAFE MODE The most common reason for an iTechworld battery to go into safe mode is from draining the battery to a voltage of 10v or less. We recommend the iTECHBC20 and iTECHBC40 AC chargers as they automatically bring iTechworld batteries out of safe mode. If you do not have an iTECHBC20 or iTECHB40, follow the methods below to bring your battery out of safe mode.
  • Page 11 50ah battery = 25amp charger 24ah battery = 12amp charger 7ah battery = 3.5amp charger Activate the jump starter to supply power to the iTechworld battery. The charger will now detect the battery and begin to charge. When the charger begins to charge the iTechworld battery, disconnect the Jump Starter from the battery.
  • Page 12 Disconnect all loads/inputs from the iTechworld battery. Disconnect the solar controller/regulator from the solar panel. Connect the unregulated solar panel to the iTechworld battery. Leave for 5 minutes. Disconnect the unregulated solar panel from the iTechworld battery.
  • Page 13 USER GUIDE ITECHWORLD LITHIUM BATTERY BYPASS SWITCH The bypass switch, allows the reset mechanism to be permanently wired to your X range lithium battery and allows for remote BMS resetting, both batteries must be on the same negative ground: Install the bypass switch connecting only the positive terminals of the X range lithium battery and your main starting battery, or any other battery.
  • Page 14 1. Install the bypass switch connecting only the positive cable of the iTECH120X battery and your main starting battery or any other battery. 2. Both batteries must share the same negative ground(iTechworld DCDC chargers have an internal common ground. Once the cable is installed, you can simply press and hold...
  • Page 15 USER GUIDE STORAGE Long-time storage in a hot or wet environment will damage the battery. The battery should be stored in dry and ventilated environment. The ideal storage temperature is below 25℃. If stored this way, it will extend the battery life. If the storage temperature surpasses 40℃...
  • Page 16 Do not store batteries with flammable, explosive goods of sharp metals. Upon delivery of the battery from iTechworld please inspect for openings in the casing or other damage that could have been caused in transit. Contact iTechworld immediately if the battery does not seem right after...
  • Page 17: Warranty

    USER GUIDE WARRANTY iTechworld warrants its X lithium battery range to be free of defects in material and workmanship for the following Applicable Warranty Period: 3 years full replacement for automotive applications in cycling and non-cycling applications (iTECH120X) 3 years full replacement & 2 years pro-rate (5 years) for...
  • Page 18 / amp-hours, regardless of the time the battery has been in service. Therefore, iTechworld reserves the right to deny a warranty claim if it determines the battery to be at its normal end of life, even if the claim is lodged within the applicable warranty period.
  • Page 19 The battery should not be left for more than 60-90 days without checking its charge state. iTechworld recommends that a battery left in a “storage state” should be checked and charged every 60-90 days to maintain the maximum life expectancy of the battery.
  • Page 20 USER GUIDE WARRANTY General Provisions: iTechworld has no obligation under the limited warranty herein in the event the battery is damaged or destroyed as a result of one or more of the following: •Wilful abuse, misuse, physical damage, neglect or if the decorative cover has been removed.
  • Page 21 •Failure to install the battery correctly will void the warranty. •Repair or attempted repair of the battery by anyone other than an authorized iTechworld representative shall void this warranty. •Normal or accelerated deterioration in the electrical qualities due to operating or application conditions.
  • Page 22 USER GUIDE WARRANTY Return and/or Repair Policy If you are experiencing any problems with your battery, please visit our help centre www.itechworld.com.au/helpcentre We provide FAQ, Troubleshooting and wiring diagrams. You can also contact our customer service team via the help centre.
  • Page 23 USER GUIDE WARRANTY Limitations This warranty does not cover damage or defects resulting from normal wear and tear (including chips, scratches, abrasions, discolouration or fading due to usage or exposure to sunlight and water), accidents, damage during shipping to our service facility, alterations, unauthorized use or repair, neglect, misuse, abuse, failure to follow instructions for care and maintenance, acts of god, fire, flood and force majeure.

This manual is also suitable for:

Itech120xItech240xItech100sx
