Supply Fan; Multi-Speed/Erm; Variable Speed/Erm - Space Temperature Control - Trane Symbio 700 Controller Application Manual
With precedent packaged rooftop air-conditioners
Hide thumbs
Also See for Symbio 700 Controller:
- User manual ,
- Troubleshooting manual (210 pages) ,
- Application manual (44 pages)
Table of Contents
Advertisement
Appendix A
Supply Fan
Multi-Speed/ERM
Table 11. Multi-speed supply fan speeds (three stages of cooling)
Table 12. Multi-speed supply fan speeds (four stages of cooling)
Variable Speed/ERM — Space Temperature Control
Table 13. Variable speed space temperature control supply fan speeds (three stages of cooling)
Table 14. Variable speed space temperature control supply fan speeds (four stages of cooling)
ACC-APG002A-EN
Unit Operation
Off
Fan Only
Cooling Stage 1
Cooling Stage 2
Cooling Stage 3
Electric/Gas Heat 1
Electric/Gas Heat 2
Unit Operation
Off
Fan Only
Cooling Stage 1
Cooling Stage 2
Cooling Stage 3
Cooling Stage 4
Electric/Gas Heat 1
Electric/Gas Heat 2
Unit Operation
Off
Fan Only
Cooling Stage 1
Cooling Stage 2
Cooling Stage 3
Electric/Gas Heat 1
Electric/Gas Heat 2
Unit Operation
Off
Fan Only
Supply Fan Speed (%)
0
66
66
66
100
66
100
Supply Fan Speed (%)
0
66
66
66
66
100
66
100
Minimum Supply Fan Speed (%)
0
50
50
50
100
66
100
Minimum Supply Fan Speed (%)
0
50
51
