M-system M1EXV-4 Operating Manual page 24

[395] Ch4 User's table linearization
Enable / Disable Linearization function using a user specified table.
Press Set button and confirm that 'Cancel" is displayed with blinking.
Press Up or Down button to change to 'Set', and press Set button to shift to Ch4 Linearization mode.
Note: Be sure to set the Lockout setting to 'Unlock' before shifting to Ch4 Linearization mode.
Ch4 User's table linearization
ITEM
395
DATA (Setting)
Cancel
[398] Ch4 Loop test
Output signal can be simulated for performing loop test.
Press Set button and confirm that 'Cancel' is displayed with blinking.
Press Up or Down button to change to 'Set', and press Set button to shift to Loop test display.
The present value is indicated. Increase or decrease it by pressing Up or Down button.
Holding down each button changes the value continuously.
Hold down Mode button for ≥ 2 seconds or turn off the power to exit loop test.
Ch4 Loop test
ITEM
398
DATA (Setting)
Cancel
Note: While the loop test is performed, all input signals are disregarded.
When 'Display timeout' is activated and the display has been cleared (display off) during loop test, press any front button to
restore the display.
Ch4 User's table linearization
ITEM
Up/Down
395
button
DATA (Setting)
Set
Ch4 Loop test
Up/Down
ITEM
button
398
DATA (Setting)
Set
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
Ch4 Linearization enable
ITEM
395 - 001
Set button
Disable
Ch4 Loop test
4.000
Set button
mA
0.00
%
M1EXV-4
OUtput engineering value
Output % value
EM-6040-B Rev.2 P. 24 / 37
