Huawei UPS5000-H-200K-NTJ Quick Manual

01

Installing the Cabinet

1. Before installation, read the user manual carefully to get familiar with product information and safety precautions.
2. Use insulated tools when installing the equipment.
3. Only engineers certified by Huawei or its agent are allowed to install, commission, and maintain the UPS. Otherwise,
personal injury or equipment damage may occur, and the resulting UPS faults are beyond the warranty scope.
4. This document describes the installation procedure for a single UPS. For details about how to install a parallel system,
contact Huawei technical support.
Model Weight
UPS5000-H-200K-NTJ < 850 kg
Copper Bar Layout and Specifications (unit: mm)
Bypass input
PE Battery
Mains input
Item 50 kVA 100 kVA 150 kVA
Mains input current (A) 184 368
R1 100 2 x 100
Mains input Recommended cross- S1 100 2 x 100
sectional area (mm 2 ) T1 100 2 x 100
PE 38 2 x 38
Bypass input current (A) 144 289
R2 100 2 x 100
Bypass input S2 100 2 x 100
Recommended cross-
sectional area (mm 2 ) T2 100 2 x 100
PE 38 2 x 38
Output current (A) 144 289
U 100 2 x 100
Output Recommended cross- V 100 2 x 100
sectional area (mm 2 ) W 100 2 x 100
PE 38 2 x 38
Nominal battery discharge
225 450
current (A)
Maximum battery discharge
Battery input
270 539
current (A)
(lead-acid
+ 2 x 100 2 x 200
battery)
Recommended cross-
- 2 x 100 2 x 200
sectional area (mm 2 )
PE 2 x 38 2 x 100
Nominal battery discharge
104 208
current (A)
Battery input Maximum battery discharge
130 261
(SmartLi) current (A)
Recommended cross-sectional For details, see the IEC-60364-5-52
area specifications and
Equipotential Recommended cross-sectional
16
ground point area (mm 2 )
UPS5000-H-200K-NTJ Quick Guide
Dimensions (H x W x D)
2000 mm x 600 mm x 1000 mm
Space
Planning
Output
200 kVA Remarks
553 737
2 x 200 2 x 250
2 x 200 2 x 250
2 x 200 2 x 250
2 x 100 2 x 150
433 577
2 x 200 2 x 250
2 x 200 2 x 250
2 x 200 2 x 250
Connection method:
2 x 100 2 x 150
Crimped DT terminal
433 577
Bolt Specifications:
2 x 200 2 x 250
R/S/T/U/V/W/+/-:
2 x 200 2 x 250
M16 x 55 mm (120 N· m)
2 x 200 2 x 250
PE: M12 x 30 mm (47 N· m)
2 x 100 2 x 150
Equipotential ground point:
676 901 M6 x 20 mm (4.5 N· m)
NOTE:
809 1079
The currents listed in the
3 x 200 4 x 200
table are measured at a rated
3 x 200 4 x 200
voltage of 200 V. For other
2 x 150 2 x 200
data, see the user manual.
312 416
391 521
SmartLi User Manual .
Unpacking
Securing the Cabinet
Installation Not Against a Wall
M12 bolt
Spring washer
Flat washer
Expansion sleeve
unit: mm
Expansion nut
1
Issue: 02
Date: 2022-06-20
Installing Lifting Eyes
• When hoisting the
UPS, install lifting
eyes on the top of
the cabinet.
• Store the removed
screws. Reinstall
them after hoisting
the cabinet.
Iron bar
Lifting eye
Concrete floor
Without Antiseismic Requirements
With Antiseismic Requirements
Copyright © Huawei Technologies Co., Ltd. 2022. All rights reserved.
Use iron bars with a diameter not
•
greater than 20 mm to install
lifting eyes.
For safety, the lifting ropes for
•
hoisting a cabinet should be able
to withstand a weight that is more
than three times the maximum
weight of the cabinet.
