XF1 SPORT
|
MANUAL
Injection moulded polyurethane grips
Construction made of metal and carbon fiber
4.3-inch IPS LCD with 480x272 pixels
3 LED bars for displaying RPM, flag, and status.
Up to 15 different LCD dashboards
Optional non-contact clutch and optional paddles
70mm quick release holes and bolt holes
Advertisement
Table of Contents
Related Manuals for LEOXZ XF1 SPORT
Summary of Contents for LEOXZ XF1 SPORT
- Page 1 XF1 SPORT MANUAL Injection moulded polyurethane grips Construction made of metal and carbon fiber 4.3-inch IPS LCD with 480x272 pixels 3 LED bars for displaying RPM, flag, and status. Up to 15 different LCD dashboards Optional non-contact clutch and optional paddles...
- Page 2 This racing wheel is designed for simulation use only. • Leoxz is responsible for revising and explaining this manual, and reserves the right to make changes or corrections to the information and explanation provided without prior notice and without any responsibility.
-
Page 3: What's Included
What's included • XF1 Sport Steering Wheel • USB-XS9 Cable • Custom Stickers • M3 Allen Key Note: The M3 allen key can only be used to adjust the paddle and remove the front knob for easy sticking of stickers. - Page 4 Connection The XF1 Sport supports PC connection via USB 2.0 and BLE 5.0. Both options provide low latency. It is highly recommended to use the BLE connection, as most bases can power the steering wheel through the quick release, providing an immersive experience. When using BLE, it is important to ensure that the external antenna is securely installed.
-
Page 5: Usb Connection
USB Connection For USB wired connection, use the USB-XS9 cable. The attached spring cable should be used for connection. Please be mindful of the USB cable winding and avoid excessive pulling, as it may cause permanent damage to the XS9 interface. Note: Make sure that the USB-XS9 cable is aligned with the raised mark of the XS9 interface, otherwise it will cause permanent damage to the socket if it is... - Page 6 PC. Subsequent connections will occur automatically. On your PC, select Start > Settings > Devices > Bluetooth & other devices > Add Bluetooth or other device > Bluetooth. Choose “Leoxz XF1 BLE”, then select Done.
- Page 7 QR Installation The XF1 Sport has 12 mounting holes with a diameter of 70mm for quick release installation, including 6 through holes and 6 threaded holes. It supports a maximum diameter of 88mm for the quick release. Through Holes Threaded Holes （6XΦ5)
- Page 8 Install QR From Outside Note: Using any QR must and can only be powered and signaled to the XF1 Pro via the USB-XS9 cable.
-
Page 9: Menu Setting
Menu Setting As shown in the figure, the XF1 Sport can quickly switch the screen dashboard through the “Change” button. It has over 15 built-in dashboard and more types will be added with firmware updates. The “Setting” button allows you to switch... -
Page 10: Paddle Adjustment
Paddle Adjustment All paddles can be adjusted to meet the size requirements of different people. By adjusting the two screws of the paddles, move the paddles outward or inward, and then tightened securely with the screws. Note: The operating torque of the bolts should not exceed 3Nm. - Page 11 SimBridge Plugin For Simhub XF1 Sport will be compatible with simhub through simbridge and enabling LEDs customization. To use it, you need to place SimBridge in the Simhub installation directory and restart Simhub for it to take effect. Note: You can download the latest version on the website www.leoxz.com.
-
Page 12: Firmware Update
Firmware Update Through the “Setting” menu of Simbridge, you can check the current firmware version of XF1 Sport( V15 as shown in the image below ) and update the latest firmware. Once the update is completed, XF1 Sport will automatically restart. - Page 13 Copyright © 2023 Leoxz® All Rights Reserved...
