- Page 1 XF1 SPORT | MANUAL...
-
Page 2: Table Of Contents
CONTENTS • Notes • What's included • Function • Connection • BLE Connection • QR Installation • Menu Setting • Firmware Update • SimBridge Plugin • Paddle Adjustment... - Page 3 • Mount device securely to a rigid platform before use. XF1-sport to a proper table mount or a racing rig that is XF1-sport compatible with all four fixings screws that are included. Do not use other types of fixings. For further help, refer to User Guide leoxz.com website. Never operate the product without fixing it first as instructed.
-
Page 4: What's Included
What's included • XF1 Sport Steering Wheel (Quick release optional) • 6x M5x10 Bolts • USB Cable (Type-C to Type-A) • Custom Stickers • Quick Guide LEOXZ... -
Page 5: Function
A 4.3-inch, 60fps ips screen, up to 39 button inputs, 2 input axis that can be set as clutch bits points, 3 led bars for indicating vehicle status, flag and rpm. The change button is used to quickly switch screens, and the setting is used to set the XF1. Flag Led Rpm Led Status Led LEOXZ 29-30 31-32 33-37 19-21 22-24... -
Page 6: Connection
Connection FX1 supports pc connection via USB 2.0 and BLE 5.0. Either way you connect, you get very low latency. We highly recommend you to use BLE connection, because most bases can power the steering wheel through the quick release, wireless BLE connection can bring a very amazing experience. If you connect via BLE, you need to ensure that the external antenna is installed firmly. -
Page 7: Ble Connection
When BLE is disconnected, the first Flag Led will flash blue. On your PC, select Start > Settings > Devices > Bluetooth & other devices > Add Bluetooth or other device > Bluetooth. Choose Leoxz XF1 BLE, then select Done. -
Page 8: Qr Installation
QR Installation XF1 has 12 mounting holes with a diameter of 70mm for quick release installation, of which 6 are through holes and 6 are threaded holes. The maximum diameter of the quick release is 88mm. Through Holes Threaded Holes （... -
Page 9: Menu Setting
There are more than 10 different styles of meters built-in, and the types will continue to increase with the firmware update. LEOXZ Through the <Setting> button, you can switch between different setting menus, including screen brightness, led bar brightness, dual - clutch bite point, axis mode, and other menus. -
Page 10: Firmware Update
Firmware Update XF1 has built-in two powerful chips, one is responsible for screen display, ensuring that the screen can output full-color images at a high frame rate, and the other is responsible for button processing and communication. Through firmware upgrade, the two chips can be kept in the best working condition, and keep adding features. -
Page 11: Simbridge Plugin
Benefiting from Simhub's powerful game compatibility, XF1 can support all Simhub compatible racing games. SimBridge can be downloaded at www.leoxz.com, you need to put SimBridge in the Simhub installation directory, and restart Simhub to take effect. -
Page 12: Paddle Adjustment
Paddle Adjustment All paddles can be adjusted to meet the size requirements of different people. By adjusting the 2 screws of the paddles, move the paddles outward or inward, and then tighten the screws. - Page 13 Copyright © 2020 Leoxz® All Rights Reserved...
