Summary of Contents for LEOXZ XF1 SPORT
- Page 1 XF1 SPORT MANUAL...
- Page 3 This racing wheel is designed for simulation use only. • Leoxz is responsible for the revision and explanation of this manual, and reserves the right to correct or change the information and explanation in this manual without prior notice and without any responsibility.
-
Page 4: What's Included
What's included • XF1 Sport Steering Wheel (Quick elease optional) • USB Cable (Type-C to Type-A) • Custom Stickers • User Manual LEOXZ... - Page 5 The change button is used to quickly switch screens, and the setting is used to set the XF1. Flag Led Rpm Led Status Led 38/Axis 3 39/Axis 4 LEOXZ 29-30 31-32 33-37 19-21 16-18 22-24...
- Page 6 Connection FX1 supports pc connection via USB 2.0 and BLE 5.0. Either way you connect, you get very low latency. We highly recommend you to use BLE connection, because most bases can power the steering wheel through the quick release, wireless BLE connection can bring a very amazing experience. If you connect via BLE, you need to ensure that the external antenna is installed firmly.
- Page 7 When BLE is disconnected, the first Flag Led will flash blue. On your PC, select Start > Settings > Devices > Bluetooth & other devices > Add Bluetooth or other device > Bluetooth. Choose Leoxz XF1 BLE, then select Done.
- Page 8 QR Installation XF1 has 12 mounting holes with a diameter of 70mm for quick release installation, of which 6 are through holes and 6 are threaded holes. The maximum diameter of the quick release is 88mm. Through Threaded Holes Holes （6X Φ...
- Page 9 Install QR From Outside For small size Qr, XF1 can install them from outside and without dismantling the XF1. There may be power or data cables in the quick release, please look for the direction of the cable plug, and then install the QR after inserting the cable firmly.
- Page 10 1, loosen the 14 bolts on the front panel, as shown in Figure 2 to install the QR. There may be power or data cables in the quick release, please look for the direction of the cable plug, and then install the QR after inserting the cable firmly. LEOXZ Figure 1 Figure 2...
-
Page 11: Menu Setting
There are more than 10 different styles of meters built-in, and the types will continue to increase with the firmware update. LEOXZ Through the <Setting> button, you can switch between different setting menus, including screen brightness, led bar brightness, dual - clutch bite point, axis mode, and other menus. -
Page 12: Paddle Adjustment
Paddle Adjustment All paddles can be adjusted to meet the size requirements of different people. By adjusting the 2 screws of the paddles, move the paddles outward or inward, and then tighten the screws. - Page 13 Benefiting from Simhub's powerful game compatibility, XF1 can support all Simhub compatible racing games. www.leoxz.com SimBridge can be downloaded at , you need to put SimBridge in the Simhub installation directory, and restart Simhub to take effect.
-
Page 14: Firmware Update
Firmware Update XF1 has built-in two powerful chips, one is responsible for screen display, ensuring that the screen can output full-color images at a high frame rate, and the other is responsible for button processing and communication. Through firmware upgrade, the two chips can be kept in the best working condition, and keep adding features. The XF1 supports firmware updates via USB or BLE. - Page 16 Copyright © 2022 Leoxz® All Rights Reserved...
