XGT PRO | MANUAL
v1.1
Injection moulded polyurethane grips
Aluminum alloy rear enclosure and carbon fiber panel
0.96 inches IPS LCD with 160x80 pixels and 60 fps
RGB LED rpm bar and buttons
Non contact Hall paddles
Clutch with adjustable bite point
Up to 48 buttons and 2 axes
70mm quick release holes and bolt holes
Advertisement
Table of Contents
Related Manuals for LEOXZ XGT PRO
Summary of Contents for LEOXZ XGT PRO
- Page 1 XGT PRO | MANUAL v1.1 Injection moulded polyurethane grips Aluminum alloy rear enclosure and carbon fiber panel 0.96 inches IPS LCD with 160x80 pixels and 60 fps RGB LED rpm bar and buttons Non contact Hall paddles Clutch with adjustable bite point...
- Page 2 This racing wheel is designed for simulation use only. • Leoxz is responsible for revising and explaining this manual, and reserves the right to make changes or corrections to the information and explanation provided without prior notice and without any responsibility.
-
Page 3: What's Included
What's included • XGT Pro Steering Wheel • USB-GX12 Cable • Custom Stickers • Nylon Tweezers... - Page 4 Interface 9 RGB LED Bar compatible with Simhub 18 RGB LED Buttons compatible with Simhub 160x80 IPS LCD compatible with Simhub 14 Momentary button 2 Thumb rotary encoder 4 Front rotary encoder with push button 2 Multi-directional joystick with integrated encoder 2 Non-contact hall shifter paddle 2 Optional non-contact hall clutch paddle *Keep in mind that on the page for the Windows USB Gaming device, some of the buttons will not show.
-
Page 5: Quick Controls
Quick Controls long-pressing the first encoder allows you to access the quick control menu, enabling you to switch the steering wheel between different modes(USB mode, 2.4G mode and Fanatec mode). After entering the quick control menu, you can use the left and right buttons on the right multi- directional joystick to select different menus. -
Page 6: Wheel Mode
Wheel Mode USB Mode： In this mode, you must use the included USB-GX12 cable to connect the steering wheel to a USB 2.0 port on the PC. Once the steering wheel is connected to the PC, you can use Simbridge to control the screen and LED on the steering wheel. Due to the substantial power requirements of numerous RGB LEDs and the screen, it is essential to use a USB hub with an external power supply. -
Page 7: Usb Connection
USB Connection XGT Pro can only be connected via USB cable and requires a minimum input power of 5V 1.0A to ensure proper operation. Otherwise, unexpected errors may occur. The USB-GX12 cable will ensure a stable and reliable connection. Note: Make sure that the USB-GX12 cable is aligned... - Page 8 Wheel Mode 2.4G Mode： <2.4G Pair>: An additional step is required to use the XGT 2.4G Link as a USB dongle connected to the PC. Afterward, long-press the XGT 2.4G Link button to enter pairing mode, simultaneously switching the quick control menu to the <2.4G Pair> menu. Press and hold down the right Multi-directional joystick to initiate pairing for the steering wheel.
- Page 9 Wheel Mode Fanatec Mode： In this mode, the steering wheel does not require a USB connection, it can communicate directly with the Fanatec base.. You can use the steering wheel to access the Fanatec Tuning Menu and configure settings on the Fanatec base. Fanatec Mode Button Mapping Due to the limited number of Fanatec buttons, only a subset of buttons on the steering wheel is functional.
- Page 10 SimBridge Plugin For Simhub XGT Pro will be compatible with simhub through simbridge, enabling dashboard and LEDs customization. To use it, you need to place SimBridge in the Simhub installation directory and restart Simhub for it to take effect. Note: You can download the latest version on the website www.leoxz.com.
- Page 11 Simhub Compatibility XGT Pro is a plug-and-play device, so you can connect it to SimHub without having to complicatedly install any drivers. You can display various dashboards on screen and change brightness through SimHub, and you can also achieve various lighting effects by creating...
- Page 12 Paddles Functionality The optional clutch paddles can be configured for axis mode and bite point mode. All paddles have self-calibrate functionality to ensure high accuracy. This function requires that the paddles be pressed once (from minimum position to maximum position) each time the steering wheel is started.
- Page 13 SimHub Controls By binding any controller or keyboard input, you can quickly control the XGT Pro dashboards switching, screen and LEDs brightness, clutch paddles and bite point value.
-
Page 14: Firmware Update
XGT Pro and update the latest firmware. Once the update is completed, XGT Pro will automatically restart. Note: You can download the latest firmware on the website www.leoxz.com. Do not operate the steering wheel during the update process, as it may cause unexpected errors. -
Page 15: Hardware Reset
Hardware Reset If the firmware update fails and the steering wheel cannot start normally, please try hardware reset to force the steering wheel to enter Bootload mode and update the firmware again. 1. Disconnect the power to the steering wheel to keep the steering wheel in a power-off state. - Page 16 Copyright © 2023 Leoxz® All Rights Reserved...
